2005 Volkswagen Passat (B6) Dimensions, Size & Specs

The curb weight of the Volkswagen Passat B6 varies depending on the configuration and equipment, ranging from 1268 kg (2795 lbs) to 1614 kg (3559 lbs). Its maximum permissible weight (gross vehicle weight rating) ranges between 1950 kg (4299 lbs) and 2270 kg (5002 lbs). This range in weights accommodates different engine types, drivetrains, and optional equipment, influencing the vehicle’s performance, fuel efficiency, and handling characteristics.

The luggage capacity of the Volkswagen Passat B6 is quite practical for a sedan in its class. With the rear seats in their upright position, the trunk space ranges from 485 liters (17.1 cubic feet) to 565 liters (19.9 cubic feet), offering plenty of room for daily and longer trips. When the rear seats are folded down, this capacity increases significantly to between 1011 liters (35.7 cubic feet) and 1091 liters (38.5 cubic feet), allowing for larger or bulkier cargo to be transported with ease.

A standard home garage width typically ranges from 2400 mm (94.5 inches) to 3000 mm (118 inches), with a length of about 4800 mm (189 inches) or more. Given the Volkswagen Passat B6's width of 1820 mm (71.7 inches) and length of 4765 mm (187.6 inches), it fits comfortably within most standard garage dimensions, allowing space for door clearance and ease of parking. However, the width with mirrors extended (up to 2004 mm or 78.9 inches) is marginal and should be considered when maneuvering in tighter garage spaces.

The Volkswagen Passat B6 has a ground clearance of 114 mm (4.5 inches), which is typical for mid-size sedans optimized for on-road use. This relatively low ride height ensures good aerodynamics and road handling on smooth pavement but can limit the ability to navigate rough or uneven terrain without risking underbody contact. Drivers in areas with poorly maintained roads or occasional off-road driving should exercise caution and consider this clearance limitation.

The Volkswagen Passat B6 supports a variety of rim sizes ranging from 16 to 18 inches, including sizes 6.5J x 16, 7J x 16, 7.5J x 17, and 8J x 18. The compatible tire sizes include 215/55 R16, 205/55 R16, 235/45 R17, 205/55 R16, 235/40 R18, and 215/55 R16. These options offer a balance between ride comfort, handling, and aesthetics, allowing owners some flexibility in customizing their vehicle to suit preferences or driving needs.

Compared to the Volkswagen Passat B5, the B6 generation is generally larger and more refined in dimensions. The B5's length was approximately 4748 mm (186.9 inches), slightly shorter than the B6's 4765 mm (187.6 inches). The B6 also offers a wider body at 1820 mm (71.7 inches) compared to the B5, which measured around 1775 mm (69.9 inches) wide. Height remains comparable, but the B6 advanced in interior space and modern design cues. This evolution resulted in a roomier, more comfortable car with improved driving dynamics and an updated appearance.

Within the mid-size sedan segment, the Volkswagen Passat B6 offers competitive dimensions. For example, models like the Honda Accord and Toyota Camry from the same era have lengths generally between 4800 mm (189 inches) and 4850 mm (191 inches), making the Passat slightly shorter. Its width of 1820 mm (71.7 inches) is roughly on par with competitors, though some rivals may be marginally wider. The Passat’s trunk volume and interior space are comparably generous, offering a balance of comfort and practicality typical for its class, with European styling and driving characteristics appealing to buyers seeking a premium feel.

The Volkswagen Passat B6 has a roof load capacity of 100 kg (220 lbs), which indicates the maximum weight that can safely be placed on the roof, including the weight of any roof racks or carriers. This capacity allows users to carry additional cargo such as bikes, luggage boxes, or sporting equipment. However, when using a roof rack, it’s important to distribute the load evenly and secure it properly to avoid damage to the vehicle or safety hazards during travel. Exceeding the roof load limit can negatively affect vehicle stability and roof integrity.

The Volkswagen Passat B6, produced from 2005 to 2010, introduced a more modern design with sharper lines and a refined interior compared to previous models. It offered enhanced safety features, improved build quality, and advanced technology for its time, including more efficient engines and better fuel economy. The B6 emphasized ride comfort and handling, thanks in part to updated suspension systems and chassis tuning. Overall, it cemented the Passat’s reputation as a premium mid-size sedan with a strong blend of practicality, style, and driving dynamics.
