Volkswagen2017 Volkswagen Golf VII Sportsvan (facelift 2017) Dimensions, Size & Specs| Production | |
|---|---|
| Model Year: | 2017 |
| Production Years: | 2017 - 2019 discontinued in 2019 |
Precise measurements of the 2017 Volkswagen Golf VII Sportsvan, engineered for optimal performance and comfort
| Dimensions | |
|---|---|
| Length: | 4351 mm171.3 in14.3 ft |
| Width: | 1807 mm71.1 in5.9 ft |
| Width (Opened Mirrors): | 2050 mm80.7 in6.7 ft |
| Height: | 1613 mm63.5 in5.3 ft |
| Trunk Capacity: | 590 liter20.8 cu ft |
| Trunk Capacity (Max): | 1520 liter53.7 cu ft |
| Weight Specifications | |
| Curb Weight: | 1335 - 1535 kg2943 - 3384 lbs |
| Maximal permitted Weight: | 1850 - 2020 kg4079 - 4453 lbs |
| Roof Load: | 75 kg165 lbs |
| Tire Specifications | |
| Rims Sizes: | 6.5J x 16, 6J x 17 |
| Tire Sizes: | 205/55 R16 (W:205 | H:55 | D:16) 205/50 R17 (W:205 | H:50 | D:17) |
The Volkswagen Golf VII Sportsvan facelift, introduced between 2017 and 2019, represents a modernized iteration of Volkswagen's compact minivan offering. Measuring 4351 mm (171.3 inches) in length, 1807 mm (71.1 inches) in width, and standing 1613 mm (63.5 inches) tall, this model strikes a balance between spacious interior accommodation and manageable exterior dimensions suited for urban and suburban driving. With the side mirrors opened, the width extends to 2050 mm (80.7 inches), accounting for necessary parking and driveway clearances.
The vehicle's curb weight varies between 1335 kg to 1535 kg (2945 to 3385 lbs), reflecting different configurations and equipment levels, while the maximum permissible weight ranges from 1850 kg to 2020 kg (4082 to 4450 lbs). This weight capacity supports robust passenger and cargo loads, making the Sportsvan an adaptable family vehicle.
Luggage capacity is a notable highlight: the standard boot offers 590 liters (20.8 cubic feet) of space, which expands significantly to 1520 liters (53.7 cubic feet) when the rear seats are folded down, providing excellent flexibility for transporting larger items. Additionally, the roof can support a load up to 75 kg (165 lbs), ideal for roof boxes or carriers.
The Golf VII Sportsvan facelift rides on a choice of rim sizes from 6.5J x 16 inches to 6.6J x 17 inches, paired with tire sizes 205/55 R16 or 205/50 R17, tailored to optimize comfort, handling, and safety. The combination of these dimensions and specifications underlines the Sportsvan's role as a practical and versatile vehicle that meets the needs of drivers seeking the comfort of a minivan in a compact package.
Discover the standout features that make the 2017 Volkswagen Golf VII Sportsvan a leader in its class
Have a question? Please check our knowledgebase first.
The Volkswagen Golf VII Sportsvan facelift (2017-2019) has a length of 4351 millimeters (approximately 171.3 inches). This length provides a compact and practical footprint suitable for urban driving as well as comfortable interior space, balancing maneuverability with passenger room effectively.
The Volkswagen Golf VII Sportsvan measures 1807 millimeters (71.1 inches) in width without mirrors. With the side mirrors opened, the width extends to 2050 millimeters (80.7 inches). This information is crucial for parking and navigating through narrow streets or confined spaces.
The height of the Golf VII Sportsvan facelift is 1613 millimeters (63.5 inches). This slightly elevated height compared to regular hatchbacks translates into improved headroom and a more comfortable upright seating position, enhancing overall passenger comfort especially in the front and rear seating.
The curb weight of the Volkswagen Golf VII Sportsvan facelift varies between 1335 kilograms and 1535 kilograms (2945 to 3385 pounds). This weight range is typical for a compact minivan and balances fuel efficiency with stability and driving dynamics, ensuring the vehicle remains responsive and practical.
The maximum permissible weight (gross vehicle weight) of the Golf VII Sportsvan facelift ranges from 1850 kilograms to 2020 kilograms (4082 to 4452 pounds). Adhering to this limit is important for safety, legal compliance, and optimal vehicle performance, especially when fully loaded with passengers and cargo.
With all rear seats in place, the Volkswagen Golf VII Sportsvan facelift offers a generous luggage capacity of 590 liters (20.8 cubic feet). When the rear seats are folded down, this capacity expands substantially to 1520 liters (53.7 cubic feet), making it very versatile for carrying larger items or more luggage.
Yes, the Volkswagen Golf VII Sportsvan facelift fits comfortably into a standard residential garage. With a length of 4351 mm (171.3 inches), width of 1807 mm (71.1 inches) excluding mirrors, and height of 1613 mm (63.5 inches), it is within the typical garage space dimensions. However, care must be taken with mirror width (2050 mm or 80.7 inches) when opening doors in tighter spaces.
Compared to its pre-facelift predecessor, the Golf VII Sportsvan facelift (2017-2019) maintains similar overall dimensions. The facelift mainly focused on styling updates and minor feature enhancements rather than changes to car size. Both versions have comparable length and width, ensuring cabin space and luggage capacity remain largely unchanged.
The Volkswagen Golf VII Sportsvan facelift competes favorably with other compact MPVs like the Ford C-Max and Renault Scenic. Its length of 4351 mm (171.3 in) and luggage capacity of up to 1520 liters (53.7 cu ft) with folded seats position it well for family practicality. Compared to rivals, the Golf Sportsvan offers a refined balance of interior space, ease of driving in urban settings, and a high-quality feel.
The standard rim sizes for the Volkswagen Golf VII Sportsvan facelift range between 6.5J x 16 inches up to 6.5J x 17 inches. Tire sizes generally include 205/55 R16 and 205/50 R17 variants. These sizes contribute to ride comfort and handling precision suited to a compact minivan designed for versatile everyday use.
