2023 Volkswagen Amarok II Dimensions, Size & Specs

The curb weight of the Volkswagen Amarok II ranges from 2187 kg to 2383 kg (4821 to 5254 pounds). This variation depends on the specific trim level, equipment, and configuration. A heavier vehicle offers better stability and a robust feel, which is beneficial when hauling or driving on rough terrain, but it can influence fuel efficiency negatively. Despite its weight, Volkswagen has optimized the Amarok II's engineering to strike a balance between durability and fuel economy, leveraging modern engine tech and lightweight components where possible. Drivers can expect solid handling and strong road presence given this weight range, typical for a pickup in this segment.

The Amarok II boasts a ground clearance ranging from 217 mm to 237 mm (8.5 to 9.3 inches), which is quite advantageous for off-road driving conditions. This elevated stance helps the vehicle clear obstacles like rocks, uneven terrain, and deep ruts without damaging the undercarriage. Additionally, a higher ride height contributes to better water fording capacity and visibility over rough terrain. For a midsize pickup truck, this ground clearance marks it as a competent off-roader, balancing on-road comfort with rugged capability for outdoor and work uses.

Standard garage dimensions typically measure about 2.4 to 2.7 meters (8 to 9 feet) wide and around 5.4 to 6.0 meters (18 to 20 feet) deep. The Volkswagen Amarok II, with a width of approximately 1.91 to 1.92 meters (6.27 to 6.29 feet) without mirrors and a length between 5.35 to 5.39 meters (17.55 to 17.69 feet), generally fits lengthwise in a standard garage, though space is quite tight, especially depth-wise. The height of around 1.87 to 1.88 meters (6.14 to 6.17 feet) fits comfortably under most garage ceilings. However, the truck’s side mirrors, which push the width to around 2.2 meters (7.2 feet), can require careful maneuvering or folding mirrors. Overall, most single garages can accommodate this truck but with minimal clearance, so a larger or double garage is recommended for easier parking and door accessibility.

The maximum weight (gross vehicle weight rating, GVWR) for the Amarok II ranges from 3190 kg to 3350 kg (7026 to 7385 pounds). This rating indicates the total weight the vehicle can safely carry, including passengers, cargo, and itself. In comparison to other midsize pickups such as the Toyota Hilux or Ford Ranger, which have similar GVWRs typically between 2800 kg and 3300 kg (6173 to 7275 lbs), the Amarok II holds up well in capacity. It demonstrates an ability to handle tough hauling and towing tasks expected from a modern midsize pickup, making it competitive for both commercial and recreational purposes.

The Volkswagen Amarok II offers a range of tire sizes from 215/70 R16 up to 275/45 R21, fitted to rims sized between 16 and 21 inches. Rim widths include 7J (16-inch), 7.5J (17 and 18-inch), 8J (20-inch), and 8.5J (21-inch). Smaller rims with higher-profile tires like the 215/70 R16 provide softer ride quality and better off-road traction due to increased sidewall flex. Larger rims with lower-profile tires, such as the 275/45 R21, contribute to sportier handling, improved cornering, and a more aggressive appearance but may sacrifice some off-road smoothness. This variety allows buyers to select wheel configurations either geared toward rugged utility or on-road refinement according to their preferences.

The Amarok II stands between 1871 mm and 1884 mm (73.7 to 74.2 inches) tall. While a taller height generally increases air resistance affecting aerodynamics negatively, Volkswagen engineers have worked to design the Amarok II's body shape to optimize airflow and reduce drag as much as possible for a pickup truck. This height provides solid road presence and elevated seating, boosting driver visibility. The relatively tall stature also helps with ground clearance on rough terrain. From a stability standpoint, the design incorporates a low center of gravity chassis balance to offset the natural rollover risk that higher vehicles can experience, enhancing confidence and control on-road and off-road.

Compared to the previous Amarok I generation, which was produced from 2010 to 2022, the Amarok II is larger and more robust. The first generation Amarok had a length around 5082 mm (200 inches), making the second generation approximately 268 to 308 mm (10.6 to 12.1 inches) longer, enhancing cargo space and interior comfort. The width increased from about 1940 mm (76.4 inches) to a similar width but with wider mirror openings on Amarok II. The height also slightly increased to near 1871-1884 mm. The curb weight is higher due to added equipment and structural reinforcement, improving safety and capability. Overall, Amarok II presents as a more capable and modern pickup offering refined features while maintaining ruggedness, giving it an edge in payload, towing, and on/off-road capacity.

In terms of size, the Volkswagen Amarok II is generally comparable to other popular midsize pickups like the Ford Ranger and Toyota Hilux. It is slightly longer than most competitors, with a length exceeding 5.3 meters (around 210 inches), offering potentially more cargo bed space or cabin room. Its width at about 1.9 meters (75 inches) is typical of this segment, but the Amarok's wider mirrors widen its total footprint. The ground clearance and maximum weight capacity put it on par with these rivals, making it competitive for both off-road and work use. Feature-wise, the Amarok II brings Volkswagen's characteristic build quality, advanced driver assistance systems, and comfort touches that might appeal to buyers seeking a premium feel within a rugged pickup package.

The Volkswagen Amarok II has a roof load capacity of 85 kg (187 lbs). This weight limit refers to the maximum recommended static load on the roof, which includes roof racks, cargo boxes, tents, or any accessories mounted on the roof. While 85 kg is adequate for standard roof storage solutions such as luggage carriers or lightweight rooftop tents, it's important to consider this limit to avoid impairing vehicle handling or risking damage. Properly securing rooftop gear within this load limit ensures safe driving dynamics and prevents overloading stresses on the roof structure, especially when driving off-road or over uneven terrain.
