2016 Tesla Model X Dimensions, Size & Specs

The Tesla Model X has an overall width of 1999 mm (78.7 inches) excluding mirrors. When mirrors are folded, the width extends between 2017 mm and 2072 mm (79.4 to 81.5 inches), and with mirrors opened, it measures between 2271 mm and 2272 mm (89.4 to 89.4 inches). This wider mirror stance is important to consider for parking and navigating narrow streets, reflecting the SUV's broad road footprint and ensuring good visibility.

The Model X stands 1684 mm tall (66.3 inches), providing a balanced SUV height that contributes positively to interior headroom and ease of entry/exit. This height also benefits aerodynamics and overall vehicle stability. While this is somewhat taller than typical passenger sedans, the Model X’s height remains within the range that fits comfortably inside standard residential garages, although the door and mirror widths should still be checked for clearance.

The Tesla Model X from the 2016 generation has a curb weight ranging between 2352 kg and 2562 kg (5187 to 5649 pounds). This heavier weight is mainly due to its large battery pack and electric drivetrain components, which contribute to its extended range and performance. The substantial mass affects handling dynamics by increasing inertia, though the low center of gravity due to the battery placement helps maintain excellent stability and ride comfort. Additionally, it impacts energy consumption but is balanced by regenerative braking systems.

The maximum weight of the 2016 Tesla Model X ranges from 2985 kg to 3120 kg (about 6585 to 6877 pounds). This figure includes the vehicle’s curb weight plus passengers, cargo, and any optional equipment. Knowing the maximum weight is vital for safe loading, ensuring the vehicle does not exceed its designed capacity, which could affect handling, braking, and tire wear. It also helps in complying with transport regulations and maintaining warranty coverage.

The Tesla Model X provides 357 liters (approximately 12.6 cubic feet) of luggage space with all rear seats in use, suitable for daily groceries and smaller suitcases. When the rear seats are folded flat, the capacity expands significantly to 2166 liters (76.5 cubic feet), large enough to accommodate bulky items like sports gear, furniture, or multiple large suitcases, making it highly versatile for family trips or transporting large cargo.

Yes, the Tesla Model X typically fits into a standard residential garage, although clearance can be tight. The SUV’s height of 1684 mm (66.3 inches) is generally well below standard garage door heights, which usually range from 1981 mm (78 inches) to 2134 mm (84 inches). The challenging dimension for some users could be the width: with mirrors open, the width can reach approximately 2272 mm (89.4 inches), whereas most single garage door widths are around 2440 mm (96 inches). Folding the mirrors reduces width significantly, making parking easier in narrow spaces.

The 2016 Tesla Model X is actually the first generation of the Model X itself, with no direct predecessor as the Model X was a new addition following the Model S sedan. It shares many drivetrain and technology components with the Model S but is larger in dimensions due to its SUV design. Compared to the Model S, the Model X is longer, taller, and wider, catering to customers needing more interior space, utility, and SUV styling, while maintaining electric performance and range credentials.

The Tesla Model X (2016) is generally larger and offers more interior and cargo space compared to competitors such as the Audi e-tron and Jaguar I-Pace. With lengths over 5 meters (about 198 inches), it is longer than the Audi e-tron (~4901 mm) and Jaguar I-Pace (~4682 mm). Its cargo capacity, especially with rear seats folded, also surpasses many rivals, providing up to 2166 liters (76.5 cubic feet), which is significantly more than the Jaguar I-Pace's approximate 1453 liters (51.3 cubic feet) or Audi e-tron's 1750 liters (61.8 cubic feet). This makes the Model X ideal for buyers prioritizing utility, range, and passenger space in the electric SUV segment.

The Tesla Model X (2016) supports various rim sizes, including 9.5J x 20, 10J x 20, 10J x 22, 9J x 20, and 9J x 22, combined with several tire options such as 275/45 R20, 285/35 R22, 255/45 R20, 265/45 R20, and 265/35 R22. Larger rims (22-inch) with lower-profile tires typically enhance the sporty appearance and improve cornering response but can reduce ride comfort on rough surfaces. Conversely, 20-inch rims with higher-profile tires provide a smoother ride with better cushioning against road imperfections. Buyers can select these options based on their preference for ride smoothness or sportiness.
