2015 Seat Alhambra II (7N, facelift 2015) Dimensions, Size & Specs

Production
Model Year:2015
Production Years:2015 - 2020 discontinued in 2020
1720 - 1740 mm67.7 - 68.5 in5.6 - 5.7 ft
L: 4854 mm191.1 in15.9 ft | W: 2081 mm81.9 in6.8 ft
Length
4854 mm191.1 in15.9 ft
Width
2081 mm81.9 in6.8 ft
Height
1720 - 1740 mm67.7 - 68.5 in5.6 - 5.7 ft
Trunk Capacity
300 - 955 liter10.6 - 33.7 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2015 Seat Alhambra II, engineered for optimal performance and comfort

Dimensions
Length:4854 mm191.1 in15.9 ft
Width:1904 mm75.0 in6.2 ft
Width (Opened Mirrors):2081 mm81.9 in6.8 ft
Height:1720 - 1740 mm67.7 - 68.5 in5.6 - 5.7 ft
Trunk Capacity:300 - 955 liter10.6 - 33.7 cu ft
Trunk Capacity (Max):2297 - 2430 liter81.1 - 85.8 cu ft
Weight Specifications
Curb Weight:1628 - 1877 kg3589 - 4138 lbs
Maximal permitted Weight:2300 - 2590 kg5071 - 5710 lbs
Roof Load:100 kg220 lbs
Tire Specifications
Rims Sizes:16, 17, 18, 6.5J x 16, 7J x 17, 7.5J x 18, 7.0J x 17
Tire Sizes:205/60 R16 (W:205 | H:60 | D:16)
215/60 R16 (W:215 | H:60 | D:16)
225/50 R17 (W:225 | H:50 | D:17)
225/50 R18 (W:225 | H:50 | D:18)
225/45 R18 (W:225 | H:45 | D:18)
225/50 R17 98H (W:225 | H:50 | D:17)
225/50 R17 98V (W:225 | H:50 | D:17)
225/45 R18 95W (W:225 | H:45 | D:18)
Useful Information

About 2015 Seat Alhambra II

The Seat Alhambra II (7N) facelift, produced from 2015 to 2020, represents a well-balanced minivan that combines spaciousness with practical features, making it a versatile choice within its segment. Measuring 4854 mm (190.9 inches) in length, it provides ample interior room for families and cargo alike. The vehicle's width is 1904 mm (75 inches) without mirrors and extends to 2081 mm (81.9 inches) with the mirrors opened, ensuring a solid road presence while remaining manageable in urban environments. Its height ranges between 1720 mm to 1740 mm (67.7 to 68.5 inches), offering a comfortable cabin headroom and ease of entry. Weight-wise, the curb weight varies from 1628 kg to 1877 kg (3589 to 4138 lbs), reflecting the range of configurations and trim levels, while the maximum allowable weight ranges between 2300 kg and 2590 kg (5071 to 5708 lbs), underlining its robust build suited for family use or transporting heavier loads. The luggage capacity underscores the Alhambra's practicality, with a minimum of 300 liters (10.6 cubic feet) available behind the rear seats, expandable up to 955 liters (33.7 cubic feet), and with the rear seats folded down, an impressive cargo volume between 2297 liters and 2430 liters (81.1 to 85.8 cubic feet) can be utilized. This makes it especially convenient for longer trips or bulky items. Additional practical features include a roof load capacity of 100 kg (220 lbs), suitable for roof boxes or sports equipment. The Alhambra II rides on a variety of rims ranging in sizes from 16 to 18 inches, paired with tire sizes such as 205/60 R16 to 225/45 R18, balancing comfort and road handling. Overall, the Seat Alhambra II facelift offers a spacious and flexible solution within the competitive minivan market, ideal for those seeking a family vehicle with versatile size and cargo capabilities.

Exceptional Features

2015 Seat Alhambra II Highlights

Discover the standout features that make the 2015 Seat Alhambra II a leader in its class

Spacious Seven-Seater Layout

The 2015 Seat Alhambra II offers a flexible and spacious seven-seat configuration, making it ideal for families and group travel with ample room for passengers and luggage.

Efficient Engine Options

This model comes with a range of efficient petrol and diesel engines, including a 2.0 TDI diesel engine known for good fuel economy and balanced performance.

Advanced Safety Features

Equipped with multiple airbags, Electronic Stability Control (ESC), Anti-lock Braking System (ABS), and optional driver assistance technologies to enhance passenger protection.

Modern Infotainment System

The facelift introduced upgraded infotainment options including touchscreen displays, Bluetooth connectivity, and USB ports to keep passengers connected and entertained.

Sliding Rear Doors

The Alhambra II features convenient sliding rear doors on both sides, providing easy access to the rear seats, especially useful in tight parking spaces.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Seat Alhambra II (7N, facelift 2015) measures 4854 mm (191.1 inches) in length, 1904 mm (74.96 inches) in width without mirrors, and 2081 mm (81.93 inches) with mirrors opened. The height ranges between 1720 and 1740 mm (67.72 to 68.5 inches), depending on specific trim and equipment. These dimensions make the Alhambra a spacious and practical minivan suited for families, offering ample room inside while maintaining manageable external proportions for its class.

The curb weight of the Seat Alhambra II ranges from 1628 to 1877 kg (3588 to 4138 lbs), depending on the engine, trim level, and optional equipment. The maximum permissible weight (gross vehicle weight rating) is between 2300 and 2590 kg (5071 to 5709 lbs). This weight range reflects the vehicle’s robust build designed to support a full passenger load and cargo, ensuring safety and stability, especially important for a family-oriented minivan.

With all seats in use, the Seat Alhambra II offers a luggage capacity ranging from 300 to 955 liters (10.6 to 33.7 cubic feet), which is adequate for everyday family needs or grocery runs. When the rear seats are folded down, the luggage capacity dramatically increases to between 2297 and 2430 liters (81.1 to 85.8 cubic feet), allowing for the transport of larger items such as furniture or multiple suitcases. This flexibility makes the Alhambra highly versatile for both passenger transport and cargo hauling.

A standard garage typically ranges around 2.4 to 2.7 meters (7.9 to 8.9 feet) in width. The Seat Alhambra II has a width of 1904 mm (74.96 inches) without the mirrors, which fits comfortably in most garages. However, with the mirrors opened, the width extends up to 2081 mm (81.93 inches), which may require careful maneuvering or possibly folding the mirrors in to fit within a narrower garage. Overall, the Alhambra II should fit most standard garages, but owners should consider mirror clearance for convenience.

The height of the Seat Alhambra II ranges from 1720 to 1740 mm (67.72 to 68.5 inches). This is fairly typical for a minivan, allowing it to comfortably fit into standard residential garages, which often have heights of at least 2 meters (78.74 inches). The moderate height ensures that the vehicle offers good headroom for passengers while maintaining ease of access when entering or exiting garages without hitting ceiling fixtures. It balances interior space with practicality for everyday use.

The Seat Alhambra II comes equipped with a variety of rim sizes including 16, 17, and 18 inches with widths from 6.5J to 7.5J. Tire options vary from 205/60 R16 and 215/60 R16 to 225/50 R17 and 225/45 R18, among others. Larger rims and lower profile tires generally improve handling and aesthetics but might reduce ride comfort slightly. Conversely, smaller rims with higher profile tires can enhance ride comfort and absorb road irregularities better, which is beneficial for this family minivan’s primary urban and suburban use.

Compared to the first-generation Seat Alhambra (produced before 2010), the Alhambra II (7N facelift 2015) is slightly larger in length and width, providing increased interior space and cargo capacity. The first generation was about 4855 mm in length and narrower in width overall, but the Alhambra II improved upon these dimensions with a wider stance (1904 mm vs. slightly less in the predecessor) for enhanced stability and roominess. Height is similar, but the newer generation features more modern styling and functional design tweaks to optimize interior volume and comfort.

The Seat Alhambra II aligns closely with competitors such as the Volkswagen Sharan and Ford S-Max in both size and capacity, as these vehicles share similar platforms. It offers competitive exterior dimensions with a length of 4854 mm (191.1 inches), width of 1904 mm (74.96 inches), and a height around 1720 to 1740 mm (67.7 to 68.5 inches). Its luggage capacity with seats folded (up to 2430 liters or 85.8 cubic feet) is on par or slightly better than some competitors, making it a strong contender for families needing flexible space without compromising drivability.

The Seat Alhambra II has a maximum roof load capacity of 100 kg (220 lbs), which allows for the mounting of various roof accessories such as roof boxes, bike racks, or ski racks. This load rating ensures that owners can safely add practical cargo extensions for outdoor activities or travel without compromising vehicle stability or roof integrity. It is important to evenly distribute the load and adhere strictly to this maximum limit to maintain driving safety and vehicle performance.

The 2015 facelift of the Seat Alhambra II (7N) brought several updates focused on styling, technology, and comfort. Exterior updates included refreshed front grille and bumper designs, along with modernized lighting elements. The interior incorporated enhanced infotainment systems, improved materials for better comfort, and additional driver assistance features. Mechanically, the facelift maintained efficient engines while improving suspension tuning for a smoother ride. Overall, the 2015 update modernized the Alhambra to remain competitive in the family minivan segment.
