| Production | |
|---|---|
| Model Year: | 2010 |
| Production Years: | 2010 - 2012 discontinued in 2012 |
Precise measurements of the 2010 Renault Grand Espace IV, engineered for optimal performance and comfort
| Dimensions | |
|---|---|
| Length: | 4861 mm191.4 in15.9 ft |
| Width (Opened Mirrors): | 1894 mm74.6 in6.2 ft |
| Height: | 1801 mm70.9 in5.9 ft |
| Ground Clearance: | 175 mm6.9 in0.6 ft |
| Trunk Capacity: | 456 liter16.1 cu ft |
| Trunk Capacity (Max): | 3050 liter107.7 cu ft |
| Weight Specifications | |
| Curb Weight: | 1815 - 2038 kg4001 - 4493 lbs |
| Maximal permitted Weight: | 2530 - 2665 kg5578 - 5875 lbs |
| Roof Load: | 80 kg176 lbs |
| Tire Specifications | |
| Rims Size: | 17 |
| Tire Size: | 225/55 R17 (W:225 | H:55 | D:17) |
The Renault Espace Grand Espace IV (Phase III, 2010), produced from 2010 to 2012, is a versatile and spacious minivan designed to comfortably accommodate families while offering notable cargo capabilities. Measuring 4861 mm (191.5 inches) in length and 1894 mm (74.5 inches) in width with mirrors opened, this vehicle strikes a balance between roomy interior space and manageable exterior dimensions for urban and highway driving. The height stands at 1801 mm (70.9 inches), providing ample headroom for passengers and contributing to an elevated driving position. With a curb weight ranging between 1815 kg (approximately 4004 lbs) and 2038 kg (approximately 4493 lbs), the Grand Espace IV maintains stability and robustness without sacrificing maneuverability. The maximum allowable weight varies between 2530 kg (5577 lbs) and 2665 kg (5875 lbs), supporting passengers and cargo effectively. The minivan’s ground clearance is 175 mm (6.9 inches), which is sufficient for typical road conditions and light off-road use, ensuring comfortable ride height and vehicle stability. Equipped with 17-inch rims and tires sized 225/55 R17, the vehicle contributes to a smooth and controlled driving experience. The luggage compartment offers a capacity of 456 liters (16.1 cubic feet) with all rear seats in place, ideal for daily grocery runs or small luggage. When the rear seats are folded down, the cargo space dramatically increases to 3050 liters (107.7 cubic feet), making it suitable for large items, bulky equipment, or extended travel needs. The roof can carry loads up to 80 kg (176 lbs), allowing for additional storage options such as roof boxes or sports equipment. Overall, the 2010 Renault Espace Grand Espace IV Phase III stands out as a practical and spacious minivan choice within its class, blending comfort, size, and utility for families and active lifestyles.
Discover the standout features that make the 2010 Renault Grand Espace IV a leader in its class
Have a question? Please check our knowledgebase first.
The Renault Grand Espace IV (Phase III, 2010) measures 4861 mm (191.3 inches) in length, 1894 mm (74.5 inches) in width with mirrors open, and 1801 mm (70.9 inches) in height. These dimensions contribute to its spacious minivan profile, designed to offer ample interior space while maintaining comfortable maneuverability for family and cargo needs.
The curb weight of the Renault Grand Espace IV (Phase III, 2010) ranges between 1815 kg (3,999 lbs) and 2038 kg (4,492 lbs), depending on the specific configuration and optional equipment. The maximum authorized weight spans from 2530 kg (5,579 lbs) to 2665 kg (5,876 lbs), reflecting the vehicle’s capacity to carry passengers and cargo safely within designed limits.
With all seats in their normal positions, the Renault Grand Espace IV offers 456 liters (16.1 cubic feet) of luggage capacity. When the rear seats are folded flat, this capacity dramatically increases to 3050 liters (107.7 cubic feet), making the vehicle highly versatile for transporting bulky items or larger volumes of cargo.
The Grand Espace IV has a ground clearance or ride height of 175 mm (6.9 inches). This moderate clearance allows for comfortable urban and highway driving, offering a balance between ease of passenger access and the ability to handle uneven roads or mild off-road conditions without scraping the undercarriage.
The standard rim size fitted on the Renault Grand Espace IV (Phase III, 2010) is 17 inches, paired with tire dimensions measuring 225/55 R17. This setup provides a blend of ride comfort, road grip, and handling characteristics designed for a minivan of its class.
Standard home garages typically have door widths around 2400 mm (94.5 inches) and lengths close to 4800-5000 mm (189-197 inches). With a width of 1894 mm (74.5 inches) including mirrors and a length of 4861 mm (191.3 inches), the Grand Espace IV fits lengthwise comfortably but widthwise you must fold mirrors if the garage opening is tight. Overall, it fits in most standard garages but care is required with mirrors open.
Compared to its predecessor, the Grand Espace III, the Phase III Grand Espace IV (2010) maintains similar overall dimensions but includes refinements in interior space utilization and cargo capacity. While exact predecessor dimensions vary by specific model year, the 2010 version tends to offer improved luggage volume when rear seats are folded, enhancing its practicality. The updated design also improved aerodynamics and ride comfort without significantly altering the external size.
In comparison with similarly sized European and international minivans like the Citroën C8, Peugeot 807, or Volkswagen Sharan, the Grand Espace IV is competitively sized. Its length of 4861 mm (191.3 inches) and generous cargo space of up to 3050 liters (107.7 cubic feet) with seats folded stands out for versatility. Its moderate height and width make it easier to handle in urban settings relative to some bulkier alternatives, while still accommodating seven passengers comfortably, a key consideration for large families or group travels.
The roof load capacity for the Renault Grand Espace IV (Phase III, 2010) is rated at 80 kg (176 lbs). This means you can install roof racks, carriers, or boxes but must ensure the combined weight of these accessories and cargo does not exceed this limit to maintain vehicle safety, stability, and structural integrity. It's ideal for carrying lightweight equipment like bicycles or luggage boxes within this capacity.
The Renault Grand Espace IV Phase III is designed primarily as a spacious family minivan, offering seating for up to seven passengers, generous luggage capacity, and comfortable ride quality. Its versatile seat folding mechanism maximizes cargo volume to over 3,000 liters when needed, making it suitable not only for family vacations but also for transporting bulky goods. The vehicle features an elevated ride height that facilitates easy entry and exit, and safety equipment typical for a vehicle of its class, making it ideal for daily commuting and long trips with family or groups.
