2017 Porsche Panamera (G2) Executive Dimensions, Size & Specs

Production
Model Year:2017
Production Years:2016 - 2020 discontinued in 2020
1432 mm56.4 in4.7 ft
5199 mm204.7 in17.1 ft
1432 mm56.4 in4.7 ft
5199 mm204.7 in17.1 ft
1432 mm56.4 in4.7 ft
2165 mm85.2 in7.1 ft
1432 mm56.4 in4.7 ft
2165 mm85.2 in7.1 ft
1432 mm56.4 in4.7 ft
5199 mm204.7 in17.1 ft
1432 mm56.4 in4.7 ft
2165 mm85.2 in7.1 ft
1432 mm56.4 in4.7 ft
2165 mm85.2 in7.1 ft
Length
5199 mm204.7 in17.1 ft
Width
2165 mm85.2 in7.1 ft
Height
1432 mm56.4 in4.7 ft
Trunk Capacity
405 - 500 liter14.3 - 17.7 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2017 Porsche Panamera Executive, engineered for optimal performance and comfort

Dimensions
Length:5199 mm204.7 in17.1 ft
Width:1937 mm76.3 in6.4 ft
Width (Opened Mirrors):2165 mm85.2 in7.1 ft
Height:1432 mm56.4 in4.7 ft
Ground Clearance:133 - 138 mm5.2 - 5.4 in0.4 - 0.5 ft
Trunk Capacity:405 - 500 liter14.3 - 17.7 cu ft
Trunk Capacity (Max):1395 - 1490 liter49.3 - 52.6 cu ft
Weight Specifications
Curb Weight:1935 - 2410 kg4266 - 5313 lbs
Maximal permitted Weight:2470 - 2885 kg5445 - 6360 lbs
Tire Specifications
Rims Sizes:10.5 J x 19, 9 J x 19, 11.5 J x 20, 9.5 J x 20, 10.5J x 19, 9J x 19, 11.5J x 21, 9.5J x 21, 10.5J x 19 ET62, 9J x 19 ET64, 11.5J x 20 ET68, 9.5J x 20 ET71, 11.5J x 21 ET69, 9.5J x 21 ET71
Tire Sizes:295/40 ZR19 (W:295 | H:40 | D:19)
265/45 ZR19 (W:265 | H:45 | D:19)
315/35 ZR20 (W:315 | H:35 | D:20)
275/40 ZR20 (W:275 | H:40 | D:20)
295/40 R19 (W:295 | H:40 | D:19)
265/45 R19 (W:265 | H:45 | D:19)
325/30 R21 (W:325 | H:30 | D:21)
275/35 R21 (W:275 | H:35 | D:21)
295/40 ZR19 108Y (W:295 | H:40 | D:19)
265/45 ZR19 105Y (W:265 | H:45 | D:19)
315/35 ZR20 110Y (W:315 | H:35 | D:20)
275/40 ZR20 106Y (W:275 | H:40 | D:20)
295/45 ZR19 108Y (W:295 | H:45 | D:19)
315/30 ZR21 108Y (W:315 | H:30 | D:21)
275/35 ZR21 103Y (W:275 | H:35 | D:21)
Useful Information

About 2017 Porsche Panamera Executive

The Porsche Panamera (G2) Executive, produced from 2016 to 2020 with model years starting in 2017, represents a luxurious and spacious hatchback in the Panamera lineup. This generation features an extended wheelbase version of the standard Panamera, offering enhanced rear legroom and comfort primarily suited for executive transport. The exterior dimensions highlight a length of 5199 mm (204.5 inches), a width of 1937 mm (76.3 inches) excluding mirrors, and an extended width of 2165 mm (85.2 inches) with mirrors opened. The vehicle height ranges between 1428 and 1432 mm (56.2 to 56.3 inches), providing a sleek yet statuesque stance typical of Porsche's design ethos.

The curb weight varies from 1935 to 2410 kg (4267 to 5313 lbs), depending on configuration and equipment, while maximum weight capacities range from 2470 to 2885 kg (5447 to 6358 lbs), reflecting the robust platform underpinning this luxury hatchback. Ground clearance sits low at 133 to 138 mm (5.2 to 5.4 inches), contributing to the car's sporty handling characteristics and aerodynamic profile.

Luggage capacity is practical and versatile, offering between 405 and 500 liters (14.3 to 17.7 cubic feet) with seats upright, and expanding significantly to a range of 1395 to 1490 liters (49.2 to 52.6 cubic feet) when the rear seats are folded down. These volumes place the Panamera Executive well above typical sports sedans, making it a functional choice for those who require both performance and everyday usability.

The vehicle is equipped with a variety of rim sizes ranging from 19 up to 21 inches, including widths from 9 to 11.5 inches, allowing for tailored tire and rim setups depending on the owner's preference for performance or comfort. Tire sizes vary from 265/45 ZR19 and 275/40 ZR20 to more aggressive options like 325/30 R21, all designed to maximize grip and stability.

In summary, the Porsche Panamera (G2) Executive combines Porsche's signature performance and luxury with increased practicality and room, particularly for rear passengers. Its balanced dimensions, robust weight range, and flexible cargo capacity make it an exceptional choice within the full-size luxury hatchback segment.

Exceptional Features

2017 Porsche Panamera Executive Highlights

Discover the standout features that make the 2017 Porsche Panamera Executive a leader in its class

Engine Performance

The 2017 Porsche Panamera Executive offers a range of engine options including V6 and V8 engines with turbocharging, delivering impressive horsepower and acceleration performance tailored for luxury and sportiness.

Extended Wheelbase

The Executive variant features an extended wheelbase, providing additional rear legroom and enhanced comfort for rear passengers, making it ideal for luxury chauffeur-driven experiences.

Advanced Interior Technology

Equipped with the Porsche Communication Management (PCM) system, touchscreen interface, navigation, and a premium sound system offering a sophisticated and connected in-car experience.

Adaptive Suspension System

Incorporates Porsche Active Suspension Management (PASM), which adjusts damping forces in real-time to improve ride comfort and handling performance dynamically based on driving conditions.

Safety and Driver Assistance

Includes multiple airbags, Porsche Stability Management (PSM), adaptive cruise control, lane-keeping assist, and optional night vision assist, enhancing driver and passenger safety.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Porsche Panamera (G2) Executive, produced between 2016 and 2020, has an overall length of 5199 mm (204.5 inches), a width of 1937 mm (76.3 inches) with mirrors folded, and 2165 mm (85.2 inches) with mirrors opened. The vehicle stands between 1428 mm to 1432 mm (56.2 to 56.3 inches) tall. These dimensions place it firmly in the full-size luxury hatchback segment, offering substantial road presence while balancing aerodynamic efficiency.

The Porsche Panamera (G2) Executive measures 1937 mm (76.3 inches) wide excluding mirrors, which makes it easier to maneuver in tighter spaces like parking garages. However, when the side mirrors are extended, the width increases to 2165 mm (85.2 inches). This near 23-centimeter (9-inch) increase is important to consider for narrow streets or confined parking spots, so drivers should be cautious when navigating in such environments.

The Porsche Panamera (G2) Executive has a ground clearance ranging from 133 mm to 138 mm (5.2 to 5.4 inches). This relatively low ride height enhances the car's stability and handling by lowering its center of gravity, which is typical for luxury performance-oriented vehicles. However, it may require extra caution when driving over speed bumps, steep driveways, or uneven terrain to avoid scraping the underside.

Depending on the specific configuration and equipment, the Porsche Panamera (G2) Executive weighs between 1935 kg and 2410 kg (4267 to 5313 pounds) curb weight. This relatively high weight reflects the car's size, luxury appointments, and advanced technological features. The combination of weight and performance engineering ensures both a smooth ride and solid road grip, but it's worth noting that greater mass can affect fuel efficiency compared to lighter sports cars.

The Porsche Panamera (G2) Executive offers versatile cargo space to accommodate both daily needs and longer trips. With the rear seats upright, luggage capacity ranges from 405 to 500 liters (14.3 to 17.7 cubic feet), which is quite spacious for a luxury hatchback. When the rear seats are folded down, the cargo volume expands significantly to between 1395 and 1490 liters (49.2 to 52.6 cubic feet), allowing for transporting larger or bulkier items with ease.

Given its dimensions, the Porsche Panamera (G2) Executive, with a length of 5199 mm (204.5 inches) and width including mirrors at 2165 mm (85.2 inches), fits into most standard residential garages, which typically measure about 5500 mm (216 inches) in length and 2400 mm (94.5 inches) in width. However, due to the car's considerable size, especially with mirrors extended, tight clearances may require careful maneuvering. Drivers with narrower or shorter garages should measure their spaces to ensure comfortable entry and exit.

Compared to its predecessor, the first-generation Panamera (970) which ran from 2009 to 2016, the G2 Executive model is notably larger in several key dimensions. The G2's length of 5199 mm (204.5 inches) is longer than earlier models, emphasizing a more spacious and executive-oriented design with extended wheelbase for increased rear legroom. Width and height have slight increases as well, contributing to a more imposing road presence. Overall, these changes reflect Porsche’s intent to enhance luxury and comfort in the second generation while maintaining sporty characteristics.

Within the luxury hatchback segment, the Porsche Panamera (G2) Executive is positioned as one of the larger and more executive-focused models. Its length of 5199 mm (204.5 inches) and width of 1937 mm (76.3 inches) surpass many rivals such as the Audi A7 and BMW 6 Series Gran Turismo, offering more rear passenger space and cargo capacity. The Panamera's hatchback design provides excellent practicality combined with Porsche’s signature sporty dimensions, making it a compelling option for buyers seeking luxury and versatility.

The Porsche Panamera (G2) Executive offers a wide range of rim sizes from 19 to 21 inches to suit different driving preferences and performance needs. Rim widths vary extensively, for example 10.5J x 19 up to 11.5J x 21, paired with tires ranging from 265/45 ZR19 to 325/30 R21. This flexibility in wheel and tire specifications allows owners to optimize handling, ride comfort, and aesthetics, depending on whether they prefer sportier drive characteristics or more luxurious cruising.

The Porsche Panamera (G2) Executive is a full-size luxury hatchback introduced in 2016 and produced until 2020. This generation features an extended wheelbase for rear passenger comfort and is packed with advanced technology, including state-of-the-art infotainment systems, driver assistance features, and powerful engine options ranging from V6 to V8 configurations. The G2 Executive emphasizes a balance of high performance, luxury, and practicality, making it a preferred choice among executives who desire Porsche’s sporty DNA combined with roominess and modern amenities.
