2006 Peugeot 407 SW Dimensions, Size & Specs

Production
Model Year:2006
Production Years:2006 - 2008 discontinued in 2008
1486 mm58.5 in4.9 ft
L: 4763 mm187.5 in15.6 ft | W: 1811 mm71.3 in5.9 ft
Length
4763 mm187.5 in15.6 ft
Width
1811 mm71.3 in5.9 ft
Height
1486 mm58.5 in4.9 ft
Trunk Capacity
407 - 489 liter14.4 - 17.3 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2006 Peugeot 407 SW, engineered for optimal performance and comfort

Dimensions
Length:4763 mm187.5 in15.6 ft
Width:1811 mm71.3 in5.9 ft
Height:1486 mm58.5 in4.9 ft
Trunk Capacity:407 - 489 liter14.4 - 17.3 cu ft
Trunk Capacity (Max):1365 liter48.2 cu ft
Weight Specifications
Curb Weight:1455 - 1750 kg3208 - 3858 lbs
Maximal permitted Weight:2090 - 2275 kg4608 - 5016 lbs
Roof Load:80 kg176 lbs
Tire Specifications
Rims Sizes:6.5J X 16, 16, 17, 6.5 X 16, 7J x17, 7J x 17
Tire Sizes:205/60 R16 (W:205 | H:60 | D:16)
215/55 R17 (W:215 | H:55 | D:17)
Useful Information

About 2006 Peugeot 407 SW

The Peugeot 407 SW is a stylish station wagon produced between 2006 and 2008, offering a balanced mix of spaciousness and driving comfort. Measuring 4763 mm (187.5 inches) in length, 1811 mm (71.3 inches) in width, and 1486 mm (58.5 inches) in height, the 407 SW boasts a sleek yet practical profile suitable for family use or business needs. The station wagon configuration enhances cargo versatility with a standard luggage capacity ranging from 407 to 489 liters (14.4 to 17.3 cubic feet), which expands significantly to 1365 liters (48.2 cubic feet) when the rear seats are folded down.

The curb weight of the Peugeot 407 SW varies from 1455 kg to 1750 kg (3209 to 3858 lbs), while its maximum weight capacity lies between 2090 kg and 2275 kg (4609 to 5015 lbs), reflecting its robust build designed to handle a variety of loads. The roof load limit is set at a practical 80 kg (176 lbs), allowing additional cargo or roof box installation for extended hauling.

Rim sizes available for this generation include 16 and 17-inch options, specifically 6.5J x 16, 7J x 17, and configurations blending these measurements, fitted with tire sizes 205/60 R16 and 215/55 R17 to provide balanced handling and ride comfort. The Peugeot 407 SW combines practical dimensions and adaptability, making it an attractive choice for buyers seeking a mid-sized, efficient station wagon with ample cargo space.

Exceptional Features

2006 Peugeot 407 SW Highlights

Discover the standout features that make the 2006 Peugeot 407 SW a leader in its class

Engine Options

The 2006 Peugeot 407 SW offers a range of petrol and diesel engines, including 1.8L and 2.0L petrol engines and 2.0L and 2.2L HDi diesel engines, providing a balance of performance and fuel efficiency.

Spacious Estate Design

As an SW (station wagon) model, the 407 provides a large cargo area with flexible seating arrangements, making it ideal for families and long trips requiring extra luggage space.

Safety Features

The Peugeot 407 SW includes multiple airbags, ABS with Electronic Brakeforce Distribution (EBD), and Electronic Stability Program (ESP) for enhanced occupant protection and driving stability.

Comfort and Interior

The interior is equipped with comfortable seating, climate control, and high-quality materials, along with features such as electric windows, central locking, and an optional panoramic sunroof.

Handling and Ride Quality

The 407 SW features a well-tuned suspension system offering a smooth ride and precise handling, aided by its front-wheel-drive layout and responsive steering.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Peugeot 407 SW produced between 2006 and 2008 measures 4763 mm (187.4 inches) in length, 1811 mm (71.3 inches) in width, and 1486 mm (58.5 inches) in height. This size positions the 407 SW comfortably in the mid-size station wagon segment, providing ample space for passengers and cargo while maintaining a streamlined profile on the road. These dimensions contribute to both a spacious interior and good road presence, making it a practical family car with versatile capabilities.

The curb weight of the Peugeot 407 SW ranges from approximately 1455 kg (3209 lbs) to 1750 kg (3858 lbs), depending on the trim and equipment level. The maximum allowable weight the vehicle can handle, which includes passengers, cargo, and the vehicle itself, spans from 2090 kg (4609 lbs) to 2275 kg (5016 lbs). This weight range reflects the car's robust build and capability to carry substantial loads without compromising safety or performance.

With all rear seats in place, the Peugeot 407 SW offers a luggage space of 407 liters (about 14.4 cubic feet), which is suitable for everyday family needs such as groceries and smaller luggage. When the rear seats are folded down, the cargo capacity greatly expands to 1365 liters (approximately 48.2 cubic feet), allowing larger items or significant amounts of gear to be transported, enhancing the vehicle's versatility for trips and bulky cargo.

The 407 SW came with several tire size options, primarily 205/60 R16 and 215/55 R17. Rim sizes compatible with these tires include 6.5J x 16, 7J x 16, 7J x 17, and 6.5J x 17. These specifications provide drivers with options balancing comfort, handling, and road grip, essential for a station wagon designed for both daily driving and longer journeys.

Yes, the Peugeot 407 SW can fit into most standard residential garages. With a width of 1811 mm (71.3 inches) and a height of 1486 mm (58.5 inches), the car is generally compatible with domestic garage dimensions, which typically measure about 2400 mm (94.5 inches) wide and 2100 mm (82.7 inches) tall. However, tight garages may require careful maneuvering due to the car’s mid-size width, and some extra space should be available for easy door opening and exit.

Compared to its predecessor, the Peugeot 406 station wagon, the 407 SW is notably larger in several aspects. It is approximately 128 mm (5 inches) longer and slightly wider, which translates into more interior space and enhanced cargo capacity. The 407 SW also features a more modern and aerodynamic design, improving both aesthetics and driving dynamics. These dimensional upgrades reflect Peugeot’s focus on comfort, practicality, and improved road presence in the newer generation.

When compared to similar mid-size station wagons from 2006-2008, such as the Volkswagen Passat Variant or the Ford Mondeo Estate, the Peugeot 407 SW stands competitively in terms of size. Its length of 4763 mm (187.4 inches) is roughly in line with these rivals, although the 407 SW tends to offer slightly more interior cargo volume, especially with rear seats folded. Width-wise, it is comparable as well, ensuring it offers comfortable cabin space without being cumbersome in urban settings.

The Peugeot 407 SW supports a maximum roof load of 80 kg (176 lbs). This means the vehicle can safely carry roof racks, bike carriers, or cargo boxes within this weight limit without compromising stability or safety. It is suitable for additional luggage when interior space is fully utilized, making the 407 SW an ideal choice for outdoor activities or family vacations requiring extra carrying capacity.

While specific ground clearance figures are not explicitly noted, typical mid-size station wagons like the Peugeot 407 SW generally offer ground clearance around 140-160 mm (5.5-6.3 inches). This clearance level provides a balance between comfortable on-road driving and the capability to handle mild rough roads or speed bumps without much difficulty, enhancing daily usability without sacrificing a smooth ride.

The Peugeot 407 SW’s curb weight varies between 1455 kg (3209 lbs) and 1750 kg (3858 lbs), contingent on the model and equipment. Heavier models may experience slightly reduced fuel efficiency due to increased mass, but the additional weight can contribute to a more planted and stable feel on the road. This weight range reflects a robust construction that balances performance, safety, and comfort. Drivers can expect a solid driving experience without excessive fuel consumption typically associated with heavier vehicles.
