| Production | |
|---|---|
| Model Year: | 2017 |
| Production Years: | 2016 - 2019 discontinued in 2019 |
Precise measurements of the 2017 Opel Zafira Tourer C, engineered for optimal performance and comfort
| Dimensions | |
|---|---|
| Length: | 4666 mm183.7 in15.3 ft |
| Width: | 1884 mm74.2 in6.2 ft |
| Width (Folded Mirrors): | 1928 mm75.9 in6.3 ft |
| Width (Opened Mirrors): | 2100 mm82.7 in6.9 ft |
| Height: | 1660 mm65.4 in5.4 ft |
| Trunk Capacity: | 152 - 710 liter5.4 - 25.1 cu ft |
| Trunk Capacity (Max): | 1792 - 1860 liter63.3 - 65.7 cu ft |
| Weight Specifications | |
| Curb Weight: | 1553 - 1740 kg3424 - 3836 lbs |
| Maximal permitted Weight: | 2285 - 2470 kg5038 - 5445 lbs |
| Roof Load: | 100 kg220 lbs |
| Tire Specifications | |
| Rims Sizes: | 16, 17, 19, 7J x 17, 8J x 18 |
| Tire Sizes: | 215/60 R16 (W:215 | H:60 | D:16) 225/50 R17 (W:225 | H:50 | D:17) 235/40 R19 (W:235 | H:40 | D:19) 235/45 R18 (W:235 | H:45 | D:18) 255/50 R17 (W:255 | H:50 | D:17) |
The Opel Zafira Tourer C facelift (2016-2019) represents a practical and versatile minivan option, offering a blend of spaciousness and moderate footprint suitable for families and daily commuters. With an exterior length of 4666 mm (183.5 inches), this model balances interior roominess with manageable dimensions for urban driving. Its width measures 1884 mm (74.2 inches), excluding mirrors, which extend the full width to 2100 mm (82.7 inches) when open, and 1928 mm (75.9 inches) when folded, providing flexibility in tight parking situations. The height stands at 1660 mm (65.3 inches), contributing to a comfortable cabin space and ease of entry and exit. Depending on configuration, the curb weight ranges between 1553 kg (3424 lbs) and 1740 kg (3836 lbs), with maximum authorized weights from 2285 kg (5038 lbs) up to 2470 kg (5444 lbs), highlighting its robust chassis capable of carrying family and cargo loads safely. Inside, the luggage capacity spans from a modest 152 liters (5.4 cubic feet) with all seats in use, up to an impressive 710 liters (25.1 cubic feet) with partial rear seat adjustment. For extensive cargo needs, folding the rear seats expands the capacity dramatically to between 1792 liters (63.3 cubic feet) and 1860 liters (65.7 cubic feet), making it well-suited for larger items and extended journeys. Passengers can also benefit from up to 100 kg (220 lbs) of roof load, allowing for additional storage solutions such as roof boxes or carriers. The Opel Zafira Tourer C is equipped with a variety of rim sizes, from 16 to 19 inches, matched to tire sizes including 215/60 R16 and 235/40 R19, supporting both ride comfort and dynamic performance. Overall, the 2017 Opel Zafira Tourer C facelift aligns functionality, size versatility, and family-friendly features, fitting well into the mid-sized minivan segment during its production from 2016 to 2019.
Discover the standout features that make the 2017 Opel Zafira Tourer C a leader in its class
Have a question? Please check our knowledgebase first.
The Opel Zafira Tourer C (facelift 2016) measures 4666 mm (183.6 inches) in length, with a width of 1884 mm (74.2 inches) excluding mirrors. The width changes when mirrors are folded to 1928 mm (75.9 inches) and expands to 2100 mm (82.7 inches) with mirrors open. The vehicle stands 1660 mm (65.4 inches) tall. These exact dimensions contribute to the minivan’s spacious but manageable size, making it suitable for family use while providing enough room for passengers and cargo.
Yes, the Opel Zafira Tourer C (2016 facelift) generally fits comfortably into a standard home garage. Standard garage door widths typically range from 2400 mm to 2700 mm (94.5 to 106 inches), and since the Zafira’s width is 1884 mm (74.2 inches) without mirrors, and even with mirrors folded it remains under 2000 mm (78.7 inches), it leaves ample space. The height of 1660 mm (65.4 inches) is also well within standard garage height clearances. This makes it practical for daily use and parking at home without tight squeezing or risk of damage.
With all rear seats in their upright position, the Opel Zafira Tourer C (facelift 2016) offers a luggage capacity ranging between 152 and 710 liters (5.4 to 25 cubic feet). When the rear seats are folded down, the luggage space significantly increases to between 1792 and 1860 liters (63.3 to 65.7 cubic feet), providing ample room for larger cargo loads. This remarkable flexibility in cargo capacity underscores the Zafira's family-friendly and versatile character, ideal for everything from daily errands to long road trips with a full load of gear.
The curb weight of the Opel Zafira Tourer C (facelift 2016) ranges between 1553 kg and 1740 kg (3423 to 3836 pounds), depending on trim and equipment. This moderate weight helps balance sturdy road presence and fuel economy typical for a seven-seater minivan. A heavier vehicle provides more stability and comfort on the road but can slightly reduce fuel efficiency and agility. The Zafira’s weight is well managed to offer a smooth driving experience without sacrificing its family transport capabilities or economy.
The Opel Zafira Tourer C (facelift 2016) measures 1928 mm (75.9 inches) in width with the side mirrors folded, which is particularly useful when navigating narrow spaces such as tight parking areas or narrow city streets. With mirrors unfolded, the width increases to 2100 mm (82.7 inches), which is important to consider for lane positioning and passing other vehicles on wider roads. Understanding these width changes helps drivers make informed decisions in confined spaces and improves overall vehicle safety and convenience.
The Opel Zafira Tourer C (2016 facelift) has a maximum permissible weight between 2285 and 2470 kg (5039 to 5445 pounds), depending on specific configurations and equipment. This figure represents the total allowed weight including vehicle, passengers, cargo, and fuel. Properly observing this weight limit is crucial to ensure vehicle safety, performance, and brake effectiveness. It also provides a practical guideline for drivers to avoid overloading, ensuring the minivan maintains its handling balance while fully loaded.
Compared to its predecessor, the Opel Zafira Tourer B, the facelifted Tourer C (2016 model) is generally larger, with an increased length of 4666 mm (183.6 inches) versus the older model’s approximate 4520 mm (178 inches). It also features a wider body at 1884 mm (74.2 inches) excluding mirrors compared to earlier models. These dimensional enhancements provide more interior space, improved comfort, and better cargo capability, reflecting Opel’s efforts to evolve the minivan segment with a more family-oriented, spacious vehicle while maintaining agile handling dynamics.
The Opel Zafira Tourer C facelift (2016) falls comfortably within the compact minivan segment when compared to similar vehicles like the Ford S-Max or Volkswagen Touran. With a length of 4666 mm (183.6 inches) and width of 1884 mm (74.2 inches), it is somewhat more compact than larger minivans but offers competitive interior space and flexibility. Its luggage capacity with seats folded rivals that of its peers, making it a practical choice for families needing versatility without the bulk of larger vans. The design balances maneuverability with sufficient space to compete effectively in this segment.
The Opel Zafira Tourer C (2016 facelift) is equipped with a range of tire sizes including 215/60 R16, 225/50 R17, 235/40 R19, 235/45 R18, and 255/50 R17 paired with rims sized 16 to 19 inches in various widths such as 7J x 17 and 8J x 18. Larger rims and wider tires generally improve handling and cornering stability due to increased contact patches but may also slightly reduce ride comfort and fuel efficiency. Smaller tires, like the 16-inch options, offer a softer ride and often better fuel economy, making the Zafira adaptable to various driving preferences and conditions.
The roof load limit for the Opel Zafira Tourer C facelift (2016) is 100 kg (approximately 220 pounds), which is sufficient to support roof racks, cargo boxes, or bicycle carriers. This load rating ensures that the vehicle can safely carry additional cargo on top without negatively affecting handling or safety. To maximize this capability, it’s important to distribute weight evenly and secure loads properly to prevent shifting while driving. This roof load capacity adds to the Zafira’s versatility, making it well-suited for active families or travelers needing extra storage space.
