2009 Opel Insignia Hatchback (A) Dimensions, Size & Specs

Production
Model Year:2009
Production Years:2008 - 2013 discontinued in 2013
1498 mm59.0 in4.9 ft
L: 4830 mm190.2 in15.8 ft | W: 2084 mm82.0 in6.8 ft
Length
4830 mm190.2 in15.8 ft
Width
2084 mm82.0 in6.8 ft
Height
1498 mm59.0 in4.9 ft
Trunk Capacity
520 - 530 liter18.4 - 18.7 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2009 Opel Insignia Hatchback, engineered for optimal performance and comfort

Dimensions
Length:4830 mm190.2 in15.8 ft
Width:1858 mm73.1 in6.1 ft
Width (Opened Mirrors):2084 mm82.0 in6.8 ft
Height:1498 mm59.0 in4.9 ft
Ground Clearance:160 mm6.3 in0.5 ft
Trunk Capacity:520 - 530 liter18.4 - 18.7 cu ft
Trunk Capacity (Max):1465 - 1470 liter51.7 - 51.9 cu ft
Weight Specifications
Curb Weight:1428 - 1843 kg3148 - 4063 lbs
Maximal permitted Weight:2020 - 2365 kg4453 - 5214 lbs
Roof Load:100 kg220 lbs
Tire Specifications
Rims Sizes:16, 17, 18, 8.5 x 19, 6.5J x 16
Tire Sizes:215/60 R16 (W:215 | H:60 | D:16)
225/55 R17 (W:225 | H:55 | D:17)
245/45 R18 (W:245 | H:45 | D:18)
245/45R18 (W:245 | H:45 | D:18)
245/40 R19 (W:245 | H:40 | D:19)
Useful Information

About 2009 Opel Insignia Hatchback

The Opel Insignia Hatchback (A), produced from 2008 to 2013, represents Opel's mid-size hatchback offering with a balanced blend of style, space, and practicality. Measuring 4,830 mm (190.2 inches) in length, the Insignia Hatchback offers generous proportions within its segment, delivering roomy interior space and a sleek exterior design. The vehicle's width ranges between 1,856 mm (73.1 inches) and 1,858 mm (73.1 inches), expanding to 2,084 mm (82.0 inches) when the mirrors are opened, ensuring confident road presence and stability. Standing at a height of 1,498 mm (59.0 inches), the hatchback maintains a streamlined profile while providing comfortable headroom for passengers.

With a curb weight varying from 1,428 kg (3,147 lbs) to 1,843 kg (4,062 lbs), the Opel Insignia Hatchback balances solid build quality and drive dynamics, depending on the configuration and engine options. The maximum weight capacity ranges from 2,020 kg (4,452 lbs) to 2,365 kg (5,214 lbs), highlighting its ability to carry passengers and cargo efficiently. The luggage capacity is notably practical, offering between 520 and 530 liters (18.4 to 18.7 cubic feet) of boot space with the rear seats up. Folding down the rear seats expands the cargo volume substantially, to between 1,465 and 1,470 liters (51.7 to 51.9 cubic feet), catering to diverse load-carrying needs.

Additional functional specs include a roof load capacity of 100 kg (220 lbs) and a ground clearance of 160 mm (6.3 inches), suitable for standard road conditions and light roof storage options. The Insignia Hatchback is equipped with a variety of rim sizes, from 16 inches to 19 inches, supporting tire dimensions such as 215/60 R16, 225/55 R17, 245/45 R18, and 245/40 R19, enhancing both aesthetics and driving performance.

Overall, the Opel Insignia Hatchback (A) combines ample interior space, versatile cargo capacity, and solid dimensions for a comfortable and practical driving experience in the mid-size hatchback category during the late 2000s and early 2010s.

Exceptional Features

2009 Opel Insignia Hatchback Highlights

Discover the standout features that make the 2009 Opel Insignia Hatchback a leader in its class

Engine Options

The 2009 Opel Insignia Hatchback offers a variety of engine choices including petrol and diesel variants, with power outputs ranging from 115 to 325 horsepower, catering to both efficiency and performance needs.

Transmission

Available with both manual and automatic transmission options, including a six-speed gearbox, providing flexible driving experiences suited for different preferences.

Interior Comfort and Space

Designed with spacious seating and high-quality materials, the interior ensures comfort for both driver and passengers, complemented by a versatile hatchback design that provides ample cargo space.

Safety Features

Equipped with multiple airbags, ABS with Electronic Brakeforce Distribution (EBD), Electronic Stability Program (ESP), and traction control, offering enhanced safety and driving stability.

Technology and Infotainment

Includes features such as a multifunction steering wheel, cruise control, and available navigation system, integrating modern technology for convenience and entertainment.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Opel Insignia Hatchback (A) from the 2008-2013 production period measures 4830 mm (190.2 inches) in length. The width varies slightly between 1856 mm and 1858 mm (73.1 - 73.2 inches) depending on the exact model specification, while with mirrors opened, the width extends to 2084 mm (82.0 inches). These dimensions place the Insignia Hatchback in the mid-to-large category for hatchbacks, providing a spacious cabin and ample road presence while maintaining manageable overall size for daily driving and parking.

The height of the Opel Insignia Hatchback (A) stands at 1498 mm (58.9 inches), giving it a sleek profile typical of a mid-sized hatchback. The ride height or ground clearance of this model is 160 mm (6.3 inches), which is quite standard for a passenger hatchback, balancing ease of entry and exit with adequate clearance to handle speed bumps and uneven urban road surfaces without scraping the underbody.

The curb weight of the Opel Insignia Hatchback (A) ranges between 1428 kg and 1843 kg (3150 - 4063 lbs) depending on the model variant, engine choice, and optional equipment. A vehicle's weight affects fuel efficiency, acceleration, and handling. Lighter models within this range tend to be more nimble and economical, while heavier versions may offer enhanced stability and safety features, though fuel consumption might be slightly higher.

The maximum permissible weight, or gross vehicle weight, of the Opel Insignia Hatchback (A) ranges from 2020 kg to 2365 kg (4453 - 5214 lbs). This figure indicates the maximum total weight of the vehicle including passengers, cargo, and fuel. Staying within this limit is crucial for safety, vehicle performance, and to avoid undue stress on components like brakes, suspension, and tires. It ensures legal compliance and optimal operation under different load conditions.

The luggage capacity of the Opel Insignia Hatchback (A) is between 520 liters and 530 liters (18.4 - 18.7 cubic feet) with the rear seats upright, offering ample space for everyday items such as groceries or suitcases. When the rear seats are folded down, the capacity significantly increases to between 1465 liters and 1470 liters (51.7 - 51.9 cubic feet), providing excellent flexibility for transporting larger items like furniture, sports equipment, or luggage for long trips.

Yes, the Opel Insignia Hatchback (A) fits comfortably in a standard residential garage. Standard garages typically measure around 2400 mm to 3000 mm (94.5 - 118 inches) wide and around 4800 mm (189 inches) deep. With a width of up to 1858 mm (73.2 inches) and length of 4830 mm (190.2 inches), it fits well within these dimensions, leaving adequate clearance for opening doors and walking around the vehicle. Its height of 1498 mm (58.9 inches) also poses no issues in most garages.

The Opel Insignia Hatchback (A), launched in 2008, succeeded the Opel Vectra as Opel's large family car. Compared to the Vectra, the Insignia Hatchback is notably larger, with increased length and width to offer more interior space and improved comfort. The 4830 mm length and approximately 1856-1858 mm width exceed the Vectra's dimensions, reflecting modern design trends prioritizing passenger room and cargo capacity. This size increase contributed to the Insignia's positioning as a more premium and spacious vehicle in Opel's lineup.

In its class, the Opel Insignia Hatchback (A) is relatively large. With a length of 4830 mm (190.2 inches) and width close to 1860 mm (73.2 inches), it tends to be bigger than many competitors like the Ford Mondeo Hatchback or Volkswagen Passat Variant (though the latter is technically a wagon). Its sizeable luggage capacity of up to 1470 liters with folded seats also places it among the more practical options. This makes the Insignia a strong contender for buyers seeking mid-to-large hatchbacks with good space and comfort.

The Opel Insignia Hatchback (A) offers various wheel sizes ranging from 16 to 19 inches. Rim sizes include 16, 17, 18 inches, and specialized sizes like 8.5 x 19 and 6.5J x 16, matched with tire dimensions such as 215/60 R16, 225/55 R17, 245/45 R18, 245/40 R19, among others. Larger wheels with lower profile tires often improve handling and road grip but can make the ride stiffer. Conversely, smaller wheels with taller tires usually provide a more comfortable ride but might reduce sharpness in handling.

The Opel Insignia Hatchback (A) has a roof load capacity of 100 kg (220 lbs), which is standard for vehicles of its type. This capacity allows for a variety of roof-mounted accessories such as roof boxes, bike racks, or kayak carriers, provided that the total weight of the load and mounting system does not exceed this limit. For frequent or heavy roof loads, it is important to observe the recommended limit to maintain vehicle stability, fuel efficiency, and avoid damage to the roof structure.
