1992 Opel Astra F Caravan Dimensions, Size & Specs

The Opel Astra F Caravan offers 500 liters (17.7 cubic feet) of luggage capacity with the rear seats upright, making it suitable for everyday cargo like groceries and luggage for a small family. When the rear seats are folded down, the capacity expands significantly to 1630 liters (57.5 cubic feet), allowing for the transport of larger items or increased cargo loads, which greatly enhances its practicality for diverse cargo needs.

The curb weight of the Opel Astra F Caravan ranges between 995 kg (2194 lbs) and 1185 kg (2613 lbs), depending on the configuration and equipment level. Its maximum permissible gross vehicle weight ranges from 1515 kg (3340 lbs) to 1655 kg (3648 lbs), specifying the total weight including passengers and cargo. This moderate weight range contributes to the vehicle's fuel efficiency and nimble handling.

The ride height or ground clearance of the Opel Astra F Caravan is 135 mm (5.3 inches). This clearance allows the vehicle to handle typical road conditions well, including minor speed bumps and uneven pavement without scraping the undercarriage. However, it is not suited for off-road driving or very rough terrain. The modest clearance balances aerodynamics and accessibility, contributing to stability and fuel economy.

Given its dimensions — 4278 mm (168.5 inches) length, 1688 mm (66.5 inches) width excluding mirrors, and 1475 mm (58 inches) height — the Opel Astra F Caravan should comfortably fit into a standard garage. Typical single-car garage widths start at about 2.4 meters (94.5 inches) with heights exceeding 2 meters (78 inches), so there will be ample space for the car itself and room for opening doors and moving around, though care might be needed when mirrors are extended.

The Opel Astra F Caravan followed the Opel Kadett E Caravan, which was slightly smaller in overall dimensions. The Astra F Caravan increased in length and width to improve interior space and luggage capacity. Specifically, the Astra F offers a more modern design with an extended length of around 4278 mm (168.5 inches) versus roughly 4270 mm in the Kadett E, but with improved packaging and interior volume, reflecting a trend toward more spacious yet compact family cars during the early 1990s.

With mirrors opened, the Opel Astra F Caravan measures 1795 mm (70.7 inches) in width, which is a key consideration in tight parking spaces or narrow city streets. This width is wider than the cabin itself but remains manageable for urban driving. Drivers need to be mindful when navigating tight spaces or parking side by side. Mirror folding options or careful maneuvering can mitigate potential issues, making it reasonably practical compared to other compact station wagons of its era.

The Opel Astra F Caravan comes with rim sizes ranging from 5.5J x 13 ET49, 5.5J x 14 ET49, to 6J x 14 ET49, with tire sizes including 175/70 R13 82T, 175/65 R14 82T, 175/65 R14 82H, and 195/60 R14 V. These dimensions provide a good balance between comfort and handling. Smaller rims with taller tire profiles generally enhance ride comfort by absorbing road shocks, while larger rims with lower-profile tires improve handling and road grip. The options allow users to prioritize either smoothness or sportiness depending on preference.

In comparison to other compact station wagons from the early 1990s, such as the Volkswagen Golf Variant or Ford Escort Wagon, the Opel Astra F Caravan offers competitive dimensions with a length of approximately 4278 mm (168.5 inches) and good luggage capacity (up to 1630 liters/57.5 cubic feet). Its moderate curb weight and ground clearance provide a balance between efficiency and practicality. While some rivals might offer more advanced features or slightly larger cargo spaces, the Astra F Caravan maintains a strong reputation for reliability, affordability, and user-friendly design.

The Opel Astra F Caravan, produced from 1991 to 1994, is a compact station wagon known for its practicality and versatility. It features a spacious interior with flexible luggage capacity (500 liters standard and 1630 liters with seats folded), moderate curb weight (995-1185 kg), and compact exterior dimensions that make it suitable for both city driving and longer trips. The car also offers a range of rim and tire options to balance comfort and handling, along with a ride height of 135 mm for everyday usability. This generation marks a solid step forward from its predecessor with improved space utilization and modern styling.
