2016 Nissan Titan II XD Crew Cab Dimensions, Size & Specs

Production
Model Year:2016
Production Years:2015 - present in production since 2015
1981 mm78.0 in6.5 ft
6165 mm242.7 in20.2 ft
1981 mm78.0 in6.5 ft
6165 mm242.7 in20.2 ft
1981 mm78.0 in6.5 ft
2019 mm79.5 in6.6 ft
1981 mm78.0 in6.5 ft
2019 mm79.5 in6.6 ft
1981 mm78.0 in6.5 ft
6165 mm242.7 in20.2 ft
1981 mm78.0 in6.5 ft
2019 mm79.5 in6.6 ft
1981 mm78.0 in6.5 ft
2019 mm79.5 in6.6 ft
Length
6165 mm242.7 in20.2 ft
Width
2019 mm79.5 in6.6 ft
Height
1981 mm78.0 in6.5 ft
Technical Details

Exterior Dimensions

Precise measurements of the 2016 Nissan Titan II XD Crew Cab, engineered for optimal performance and comfort

Dimensions
Length:6165 mm242.7 in20.2 ft
Width:2019 mm79.5 in6.6 ft
Height:1981 mm78.0 in6.5 ft
Ground Clearance:206 mm8.1 in0.7 ft
Weight Specifications
Curb Weight:2724 - 3169 kg6005 - 6986 lbs
Maximal permitted Weight:3901 - 4078 kg8600 - 8990 lbs
Tire Specifications
Rims Sizes:7.5J x 17, 7.5J x 18, 7.5J x 20
Tire Sizes:245/75 R17 (W:245 | H:75 | D:17)
275/65 R18 (W:275 | H:65 | D:18)
265/60 R20 (W:265 | H:60 | D:20)
Useful Information

About 2016 Nissan Titan II XD Crew Cab

The Nissan Titan II XD Crew Cab, introduced for the 2016 model year and in production since 2015, stands as a robust full-size pickup truck designed to handle heavy-duty tasks while providing the comfort and utility expected of a large crew cab truck. Measuring a substantial 6165 mm (242.6 inches) in length and 2019 mm (79.5 inches) in width, this Nissan pickup asserts a commanding presence on the road. With a height of 1981 mm (78 inches), it delivers a tall, muscular stance suitable for both work and everyday driving.

Weighing between 2724 kg (6,005 lbs) to 3169 kg (6,986 lbs) when curb weight is considered, the Titan II XD Crew Cab is engineered to support demanding payloads and towing capacities. Its maximum weight ranges from 3901 kg (8,600 lbs) to 4078 kg (8,990 lbs), reflecting its capability for heavier loads. Ride height, or ground clearance, at a respectable 206 mm (8.1 inches), ensures that the truck can handle rough terrain and challenging road conditions, enhancing off-road performance.

The vehicle accommodates a variety of wheel and tire sizes to match different driving needs and preferences. Standard rim sizes include 7.5J x 17, 7.5J x 18, and 7.5J x 20 inches, paired with tire options ranging from 245/75 R17, 275/65 R18, to 265/60 R20. This flexibility allows owners to optimize for comfort, traction, and appearance.

Overall, the 2016 and newer Nissan Titan II XD Crew Cab blends size, strength, and functionality to serve both professional and personal use. Its size categorizes it firmly among full-size pickups, ideal for users who require impressive hauling capacity, towing power, and spacious interior accommodations. Whether navigating urban streets or rugged off-road environments, the Titan II XD Crew Cab remains a competitive choice in the large pickup truck market.

Exceptional Features

2016 Nissan Titan II XD Crew Cab Highlights

Discover the standout features that make the 2016 Nissan Titan II XD Crew Cab a leader in its class

Powerful Engine Options

The 2016 Nissan Titan XD Crew Cab offers strong engine choices including a 5.6L V8 gasoline engine producing 390 horsepower and a robust 5.0L Cummins V8 turbodiesel engine delivering 310 horsepower and 555 lb-ft of torque, providing excellent towing and hauling capabilities.

Towing and Payload Capacity

Designed for heavy-duty tasks, the Titan XD can tow up to approximately 12,640 pounds and has a maximum payload capacity of around 2,000 pounds, making it highly capable for both work and recreational hauling needs.

Spacious Crew Cab Interior

The Crew Cab configuration offers a roomy interior with comfortable seating for up to five passengers, featuring ample legroom and a well-designed cabin for long drives and worksite comfort.

Advanced Safety Features

Equipped with safety technologies such as multiple airbags, anti-lock brakes, vehicle dynamic control, and available rearview camera, the 2016 Nissan Titan XD ensures enhanced safety for driver and passengers.

Modern Infotainment System

The Titan XD includes a user-friendly infotainment system with available touchscreen display, Bluetooth connectivity, satellite radio, and navigation options, keeping drivers connected and entertained on the road.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Nissan Titan II XD Crew Cab from the 2016 model year measures 6165 mm (242.5 inches) in length, 2019 mm (79.5 inches) in width, and 1981 mm (77.9 inches) in height. These dimensions place it firmly in the full-size pickup category, offering substantial cabin space and cargo capacity ideal for heavy-duty work and comfortable driving. Its sizeable footprint ensures good road presence while providing ample interior room for passengers and equipment.

The curb weight of the Nissan Titan II XD Crew Cab ranges from 2724 kg to 3169 kg (6007 lbs to 6988 lbs), depending on trim and configuration. The maximum weight rating, which includes passengers, cargo, and towing load, varies between 3901 kg and 4078 kg (8599 lbs to 8989 lbs). This considerable load capacity highlights the Titan II XD's capability as a heavy-duty truck suitable for towing large trailers and carrying substantial payloads.

With a width of 2019 mm (79.5 inches), the Nissan Titan II XD Crew Cab is wider than many standard vehicles, which enhances stability and handling especially when fully loaded or towing. However, this width can make parking in tight urban areas or narrow spaces challenging. Drivers need to be cautious in narrow spots, but the size is typical for full-size pickups and balanced for both highway cruising and off-road conditions.

The 2016 Nissan Titan II XD Crew Cab features a ground clearance of approximately 206 mm (8.1 inches). This elevated ride height provides adequate clearance for off-road driving, allowing the truck to handle rough terrain, rocky paths, and uneven surfaces without damaging the underbody. It strikes a balance between easy loading and off-road capability, enhancing versatility for both work and recreational use.

The 2016 Nissan Titan II XD Crew Cab offers rim sizes of 7.5J x 17, 7.5J x 18, and 7.5J x 20 inches, paired with tire sizes 245/75 R17, 275/65 R18, and 265/60 R20 respectively. Larger rims with lower-profile tires generally provide better handling and aesthetics but may slightly reduce off-road comfort. Conversely, smaller rims with taller tires improve cushioning on rough terrain at the cost of some handling precision. This range offers a good mix for buyers prioritizing either on-road performance or off-road capability.

Standard residential garages typically measure about 2438 mm (8 feet) wide and 5182 mm (17 feet) deep. Given the Nissan Titan II XD Crew Cab's length of 6165 mm (20.3 feet) and width of 2019 mm (79.5 inches), it is slightly too long for many standard garages, especially when accounting for space to comfortably open doors and walk around the vehicle. While the width fits within average garage door widths, owners should consider their garage size or opt for specialized parking solutions to accommodate this full-size pickup.

Compared to the previous generation Titan (introduced in 2004), the Titan II XD Crew Cab from 2016 is significantly larger. It measures 6165 mm (242.5 inches) in length, which is substantially longer than the older Titan models usually ranging around 5800 mm to 5900 mm (228 to 232 inches). Width and height have also increased, offering improved interior space and a bolder exterior presence. This growth in size reflects Nissan’s focus on a more capable heavy-duty truck that better competes with other full-size pickups by providing enhanced payload, towing, and passenger comfort.

The Nissan Titan II XD Crew Cab is competitively sized within the heavy-duty pickup segment, with its 6165 mm length and curb weight ranging from 2724 to 3169 kg (6007 to 6988 lbs). Compared to rivals like the Ford F-250 or Chevrolet Silverado 2500HD, which have similar dimensions and curb weights, the Titan II XD offers a robust option with slightly different tuning and features. While slightly heavier than some competitors, it is designed for heavy towing and payload tasks. Its size ensures ample cabin space and bed length, making it practical for both work and family use in the heavy-duty truck market.

The Crew Cab configuration of the 2016 Nissan Titan II XD offers a spacious interior designed to comfortably seat five to six passengers with ample legroom and headroom thanks to the truck's generous overall dimensions. Though exact interior measurements vary by trim, the large dimensions of the vehicle translate into a roomy cabin that accommodates adults comfortably, enhances long-distance drive comfort, and provides versatile storage options, making it highly functional for both work and family use.

The 2016 Nissan Titan II XD Crew Cab was typically equipped with a powerful 5.0-liter Cummins turbodiesel V8 engine, emphasizing heavy-duty performance for towing and hauling. This engine delivers substantial torque and horsepower to tackle demanding jobs while maintaining durability and efficiency. Gasoline engine options were also available though less common in the XD trim. Overall, the Titan II XD blends strong performance metrics with practical capability, targeting buyers seeking a rugged truck capable of serious work tasks.
