2005 Nissan Patrol V 5-door (Y61, facelift 2004) Dimensions, Size & Specs

Production
Model Year:2005
Production Years:2004 - 2016 discontinued in 2016
1855 mm73.0 in6.1 ft
L: 5010 - 5080 mm197.2 - 200.0 in16.4 - 16.7 ft | W: 1840 - 1940 mm72.4 - 76.4 in6.0 - 6.4 ft
Length
5010 - 5080 mm197.2 - 200.0 in16.4 - 16.7 ft
Width
1840 - 1940 mm72.4 - 76.4 in6.0 - 6.4 ft
Height
1855 mm73.0 in6.1 ft
Trunk Capacity
183 - 810 liter6.5 - 28.6 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2005 Nissan Patrol V 5-door, engineered for optimal performance and comfort

Dimensions
Length:5010 - 5080 mm197.2 - 200.0 in16.4 - 16.7 ft
Width:1840 - 1940 mm72.4 - 76.4 in6.0 - 6.4 ft
Height:1855 mm73.0 in6.1 ft
Ground Clearance:210 - 220 mm8.3 - 8.7 in0.7 - 0.7 ft
Trunk Capacity:183 - 810 liter6.5 - 28.6 cu ft
Trunk Capacity (Max):2226 liter78.6 cu ft
Weight Specifications
Curb Weight:2295 - 2410 kg5060 - 5313 lbs
Maximal permitted Weight:3080 - 3200 kg6790 - 7055 lbs
Roof Load:100 kg220 lbs
Tire Specifications
Rims Sizes:16, 8J x 16, 8J x 17, 6J x 16
Tire Sizes:265/70 R16 (W:265 | H:70 | D:16)
275/70 R16 (W:275 | H:70 | D:16)
275/65 R17 (W:275 | H:65 | D:17)
235/80 R16 (W:235 | H:80 | D:16)
Useful Information

About 2005 Nissan Patrol V 5-door

The Nissan Patrol V 5-door (Y61) facelift introduced in 2004 and produced until 2016 represents a robust and versatile off-road vehicle designed for both rugged terrain and comfort. With a length ranging from 5010 mm to 5080 mm (197.2 to 200 inches), a width between 1840 mm and 1940 mm (72.4 to 76.4 inches), and a height around 1850 mm to 1855 mm (72.8 to 73 inches), it offers commanding road presence and spacious cabin accommodation. The Patrol V's curb weight varies from 2295 kg to 2410 kg (5060 to 5313 lbs), indicating a solid build capable of handling tough driving conditions while maintaining respectable maneuverability.

Its maximum weight capacity sits between 3080 kg and 3200 kg (6792 to 7055 lbs), underscoring its utility for carrying passengers and cargo over challenging surfaces. The luggage capacity ranges from 183 liters (6.5 cubic feet) with all seats in use, up to an expansive 810 liters (28.6 cubic feet) behind the rear seats, while folding the rear seats opens a massive storage volume of 2226 liters (78.6 cubic feet). This makes the Y61 Patrol highly practical for long trips and off-road adventures requiring ample gear.

Ground clearance is a strong 210 mm to 220 mm (8.3 to 8.7 inches), providing excellent off-road capability to navigate obstacles and uneven trails with confidence. The vehicle also supports a roof load of up to 100 kg (220 lbs), allowing for additional cargo like roof boxes or equipment racks.

The Patrol V features versatile rim sizes including 16 and 17 inches with wheel widths of 6J to 8J, paired with tire sizes such as 265/70 R16, 275/70 R16, 275/65 R17, and 235/80 R16, optimized for traction and durability in off-road conditions.

Overall, the Nissan Patrol V Y61 facelift (2004-2016) stands out as a powerful, spacious, and reliable off-road vehicle. Its size and weight balance ruggedness with practicality, making it a favorite for off-road enthusiasts, families, and professional use across demanding environments.

Exceptional Features

2005 Nissan Patrol V 5-door Highlights

Discover the standout features that make the 2005 Nissan Patrol V 5-door a leader in its class

Engine Options

The 2005 Nissan Patrol V 5-door (Y61 facelift) offers various engine choices, including a 4.8-liter inline-six petrol engine and a reliable 3.0-liter turbocharged diesel inline-four engine, known for durability and off-road performance.

Four-Wheel Drive System

Equipped with a part-time four-wheel drive system with low-range gearing, the Patrol V excels in off-road conditions, providing excellent traction and control on rugged terrains.

Suspension

Features a solid front and rear axle with coil springs, enhancing durability and providing a comfortable ride both on and off-road, ideal for rough and uneven surfaces.

Interior and Space

Spacious interior with seating for up to eight passengers across three rows, offering versatile cargo space and including modern amenities like air conditioning and upgraded audio systems in the facelift model.

Safety Features

Includes driver and passenger airbags, anti-lock braking system (ABS), and seat belts for all seats, improvements introduced in the 2004 facelift enhance overall occupant safety.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Nissan Patrol V 5-door (Y61 facelift 2004) has a length ranging from 5010 to 5080 mm (197.2 to 200 inches), a width between 1840 and 1940 mm (72.4 to 76.4 inches), and a height from 1850 to 1855 mm (72.8 to 73 inches). These dimensions make it a robust off-road vehicle with a commanding road presence, suitable for both rugged terrains and urban environments.

The curb weight of the Nissan Patrol V 5-door (Y61 facelift 2004) ranges from 2295 to 2410 kg (5059 to 5313 lbs), while its maximum weight lies between 3080 and 3200 kg (6788 to 7055 lbs). This substantial weight contributes to the vehicle's stability and traction, especially in off-road conditions, but may impact fuel efficiency and agility. The robust build supports heavy loads, towing, and rugged terrain handling.

With the rear seats in place, the Nissan Patrol V 5-door (Y61 facelift 2004) provides a luggage capacity ranging from 183 to 810 liters (6.5 to 28.6 cubic feet). When the rear seats are folded down, this capacity expands significantly to 2226 liters (78.6 cubic feet). This makes it versatile for carrying anything from daily groceries to large, bulky items or camping gear, catering well to both family use and adventurous expeditions.

The Nissan Patrol V 5-door (Y61 facelift 2004) offers a ground clearance ranging from 210 to 220 mm (8.3 to 8.7 inches). This substantial clearance is crucial for off-road driving as it allows the vehicle to navigate rocky terrain, deep ruts, and uneven surfaces without damaging the undercarriage. The elevated ride height also enhances approach, departure, and breakover angles, contributing to impressive off-road capability and versatility.

A standard residential garage in many regions typically measures around 2400 to 3000 mm (7.9 to 9.8 feet) in width and 4800 to 6000 mm (15.7 to 19.7 feet) in length. Given the Nissan Patrol V’s length of up to 5080 mm (200 inches) and width up to 1940 mm (76.4 inches), it generally fits within these parameters. However, the tight width and height of 1850-1855 mm (72.8-73 inches) mean that maneuvering and parking may require care, particularly in narrower or smaller garages.

This Patrol generation comes with rim sizes including 16,8J x 16,8J x 17,6J x 16 inches, paired with tire sizes such as 265/70 R16, 275/70 R16, 275/65 R17, and 235/80 R16. Larger rims and tires improve off-road traction and ground clearance but may reduce ride comfort on paved roads. The variety allows customization for optimal performance, whether prioritizing road comfort or rugged terrain handling.

Compared to the earlier Nissan Patrol Y60 generation, the Y61 facelift model offers similar exterior dimensions but with subtle refinements. The length increased slightly to a range of 5010-5080 mm (197.2-200 inches) compared to the Y60, which was typically shorter. Width and height have been fine-tuned for a more contemporary and robust look. Overall, the Y61 facelift provides improved internal space, better ride quality, and enhanced off-road capabilities, making it a notable evolution from its predecessor.

In comparison to other large off-road SUVs like the Toyota Land Cruiser 100 series or the Mitsubishi Pajero of the same era, the Nissan Patrol V 5-door (Y61 facelift 2004) is competitive in size, with a length around 5 meters and a width close to 1.9 meters. Its versatile luggage space, high ground clearance, and substantial weight capacity offer excellent utility for both off-road adventures and family use. The Patrol's rugged design and size make it slightly larger than some rivals, providing an edge in interior space and cargo versatility.

The Nissan Patrol V 5-door (Y61 facelift 2004) supports a maximum roof load of 100 kg (220 lbs). This capacity enables users to carry rooftop cargo such as luggage boxes, roof racks for sports equipment, camping gear, or even light rooftop tents. It enhances the vehicle’s practicality for long journeys and outdoor adventures by effectively increasing overall cargo capacity without compromising vehicle safety or performance.

The Nissan Patrol V 5-door (Y61 facelift 2004) is renowned for its rugged build, spacious interior, and reliable off-road capabilities. With a reinforced ladder frame, high ground clearance up to 220 mm, and strong suspension, it handles tough terrain with ease. Its generous cargo capacity, substantial roof load allowance, and variety of tire options complete a well-rounded package. The Patrol is cherished by both off-road enthusiasts and families seeking a dependable, versatile vehicle capable of daily use and extreme adventures.
