2009 Mini Clubman (R55) Dimensions, Size & Specs

Production
Model Year:2009
Production Years:2010 - 2014 discontinued in 2014
1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
3937 - 3961 mm155.0 - 155.9 in12.9 - 13.0 ft
1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
1683 mm66.3 in5.5 ft
1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
1683 mm66.3 in5.5 ft
1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
3937 - 3961 mm155.0 - 155.9 in12.9 - 13.0 ft
1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
1683 mm66.3 in5.5 ft
1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
1683 mm66.3 in5.5 ft
Length
3937 - 3961 mm155.0 - 155.9 in12.9 - 13.0 ft
Width
1683 mm66.3 in5.5 ft
Height
1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
Trunk Capacity
260 liter9.2 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2009 Mini Clubman, engineered for optimal performance and comfort

Dimensions
Length:3937 - 3961 mm155.0 - 155.9 in12.9 - 13.0 ft
Width:1683 mm66.3 in5.5 ft
Height:1426 - 1432 mm56.1 - 56.4 in4.7 - 4.7 ft
Ground Clearance:118 - 138 mm4.6 - 5.4 in0.4 - 0.5 ft
Trunk Capacity:260 liter9.2 cu ft
Trunk Capacity (Max):930 liter32.8 cu ft
Weight Specifications
Curb Weight:1140 - 1235 kg2513 - 2723 lbs
Maximal permitted Weight:1640 - 1755 kg3616 - 3869 lbs
Tire Specifications
Rims Sizes:6.5J x 16 LM, 5.5J x 15, 5.5J x 15 LM, 5.5J x 15 ST, 7J x 17 LM
Tire Sizes:195/55 R16 87V (W:195 | H:55 | D:16)
175/65 R15 84H (W:175 | H:65 | D:15)
195/55 R16 87V RSC (W:195 | H:55 | D:16)
205/45 R17 84W RSC (W:205 | H:45 | D:17)
Useful Information

About 2009 Mini Clubman

The Mini Clubman (R55), produced from 2010 to 2014, is a compact station wagon that blends iconic Mini design with increased practicality and space. Measuring between 3937 mm and 3961 mm (155 to 156 inches) in length, 1683 mm (66.3 inches) in width, and a height ranging from 1426 mm to 1432 mm (56.1 to 56.3 inches), this model maintains a compact footprint ideal for urban driving while offering enhanced interior room compared to traditional Mini hatchbacks. Weighing between 1140 kg and 1235 kg (2513 to 2722 lbs) with a maximum weight ranging from 1640 kg to 1755 kg (3616 to 3868 lbs), the R55 is engineered for a balanced driving experience. The vehicle’s ground clearance varies from 118 mm to 138 mm (4.6 to 5.4 inches), providing sufficient ride height for varied road conditions. The Mini Clubman R55 offers a versatile luggage capacity of 260 liters (9.2 cubic feet) with rear seats in place, which expands significantly to 930 liters (32.8 cubic feet) when the rear seats are folded down, supporting diverse cargo needs. Wheel options include rims sized from 5.5J x 15 up to 7J x 17, matching tire sizes such as 175/65 R15, 195/55 R16, and 205/45 R17, balancing aesthetics and performance. Overall, the Mini Clubman R55 station wagon delivers a compact yet spacious option for drivers seeking Mini’s charm combined with practical utility, making it suitable for city navigation and weekend getaways alike.

Exceptional Features

2009 Mini Clubman Highlights

Discover the standout features that make the 2009 Mini Clubman a leader in its class

Unique Split-Rear Door Design

The 2009 Mini Clubman (R55) features a distinctive split-rear door design, providing easier access to the cargo area and enhanced practicality compared to the traditional hatchback.

Compact Yet Spacious Interior

Despite its compact exterior dimensions, the Clubman offers a spacious cabin with increased rear legroom and cargo capacity, making it a comfortable option for passengers and luggage.

Engine Options and Performance

Available with a range of engines including 1.6L naturally aspirated and turbocharged variants, the Clubman delivers peppy performance with the Cooper S model providing sporty acceleration.

Distinctive Retro Styling

The R55 Clubman retains Mini's classic retro-inspired styling with modern touches, featuring round headlights, a wide grille, and contrasting roof colors that stand out on the road.

Enhanced Handling and Driving Dynamics

Built on the BMW-derived platform, the 2009 Mini Clubman provides agile handling with precise steering and a firm suspension setup, ensuring an engaging driving experience.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Mini Clubman (R55) 2009 model has a length ranging from 3937 mm to 3961 mm (154.9 to 156 inches). This slight variation depends on specific trim levels and optional equipment. Its compact length makes it an excellent choice for urban driving and parking while maximizing interior space efficiency in a station wagon format.

The width of the Mini Clubman (R55) is 1683 mm, which equals approximately 66.3 inches (5 feet 6.3 inches). This width contributes to the vehicle’s nimble handling and ease of maneuverability, while also providing a comfortable cabin space for passengers without being too wide for narrow city streets.

The height of the Mini Clubman (R55) ranges between 1426 mm and 1432 mm (about 56.1 to 56.3 inches). This moderate height balances aerodynamics and interior space, ensuring ample headroom for most passengers. The slightly elevated station wagon body shape also improves cargo capacity while maintaining a sporty stance.

The curb weight of the Mini Clubman (R55) spans from 1140 kg to 1235 kg (2513 to 2723 lbs), while the maximum weight ranges from 1640 kg to 1755 kg (3616 to 3869 lbs). The relatively light curb weight supports agile handling and good fuel efficiency. The maximum weight includes passengers and cargo, which the Clubman (R55) can accommodate without compromising stability.

The Mini Clubman (R55) offers 260 liters (9.2 cubic feet) of luggage space with the rear seats in use, suitable for everyday errands or weekend trips. When the rear seats are folded down, the capacity expands dramatically to 930 liters (32.8 cubic feet), enabling the transport of larger items like sports equipment or furniture, enhancing versatility for small-family or active lifestyles.

The Mini Clubman (R55) has a ride height or ground clearance ranging from 118 mm to 138 mm (4.6 to 5.4 inches). This clearance is typical for a compact station wagon and offers a good balance between sporty handling and practicality. While it comfortably manages city streets and highways, it can handle mild rough roads though not designed for serious off-road use.

Yes, the Mini Clubman (R55) fits comfortably into a standard garage. With a maximum length of around 3961 mm (156 inches), width of 1683 mm (66.3 inches), and height up to 1432 mm (56.3 inches), it is smaller than many typical station wagons and SUVs. Most standard residential garages, which are generally at least 6 meters (20 feet) deep and 3 meters (10 feet) wide, can accommodate the Clubman (R55) without difficulty.

The Mini Clubman (R55) is the first generation Clubman model introduced in 2007 and produced until 2014, so it doesn't have a predecessor Clubman generation but rather stems from the original Mini Cooper line. Compared to the standard two-door Mini hatchbacks prior to it, the R55 Clubman is longer (about 3.94 meters versus approximately 3.66 meters for the hatchback), wider, and taller, offering increased interior space and practicality while maintaining the Mini's distinctive styling cues.

The Mini Clubman (R55) is relatively compact compared to other small station wagons. For example, it is shorter in length than many competitors such as the Volkswagen Golf Variant or Ford Focus Wagon, which typically exceed 4.3 meters (around 14 feet) in length. While those models offer larger cargo capacities overall, the Clubman's distinctive styling, compact footprint, and premium interior make it especially appealing for drivers focused on city driving with occasional hauling needs.

The Mini Clubman (R55) offers multiple tire and rim options, including rims sized 6.5J x 16 LM, 5.5J x 15 (various types), and 7J x 17 LM. Tire sizes available include 195/55 R16 87V, 175/65 R15 84H, 205/45 R17 84W RSC, among others. Smaller rims and tires tend to enhance ride comfort by absorbing road irregularities better, while larger rims offer sharper handling and a sportier driving feel. This range of options allows buyers to tailor the vehicle's driving characteristics to their preferences, balancing comfort with performance.
