2018 Mercedes-Benz Sprinter Panel Van Compact (W907/W910) Dimensions, Size & Specs

With the rear seats folded, the Sprinter Panel Van Compact offers a substantial luggage capacity between 7500 and 7800 liters (264.9 to 275.4 cubic feet). This expansive cargo volume makes it ideal for transporting bulky items, large equipment, or high volumes of goods, catering well to the needs of delivery services, tradespeople, and adventure enthusiasts.

The curb weight of the Sprinter Panel Van Compact ranges from 1920 kg to 2245 kg (4233 to 4950 pounds), depending on specific configurations and options. The maximum gross vehicle weight rating (GVWR) spans from 3000 kg up to 4100 kg (6614 to 9039 pounds), allowing the van to carry heavy payloads while maintaining safety and performance standards suitable for commercial use.

The Sprinter Panel Van Compact features a ground clearance of 143 mm (5.6 inches). This ride height strikes a balance between providing adequate clearance over rough or uneven surfaces and maintaining a low center of gravity for driving stability. The ground clearance is optimal for urban and highway driving conditions common in commercial applications.

This generation of the Sprinter Panel Van Compact is equipped with 6.5J x 16 rims paired with 225/65 R16 tires. This combination offers a reliable balance of load capacity, ride comfort, and traction required for varied driving conditions ranging from city streets to highways and light off-road surfaces.

The Sprinter Panel Van Compact's width is 2020 mm (79.5 inches) and its height ranges between 2356 mm and 2388 mm (92.8 to 94 inches). Typical single-car garages have widths around 2400 mm (94.5 inches) and heights around 2100-2300 mm (82.7-90.5 inches). While the width easily fits within most standard garages, the van's height might pose a challenge for garages with lower ceiling clearance, especially due to the upper height range. It's recommended to measure your garage's dimensions, focusing on height clearance, to confirm fit.

Compared to previous Sprinter generations, the W907/W910 compact variant introduces a more refined and efficient use of space, with the length at 5267 mm often slightly shorter than some earlier long-wheelbase variants, focusing on maneuverability. The width at 2020 mm is comparable, but with modernized styling and improved aerodynamics. Height adjustments accommodate better roof load options and internal cargo space. Overall, this generation maintains practical van dimensions but improves packaging, load capacity, and driving dynamics versus its predecessor.

The Sprinter Panel Van Compact competes strongly in the medium commercial van segment. Its cargo capacity of up to 7800 liters surpasses many rivals such as the Ford Transit Custom and VW Transporter, which typically offer less volume. The maximum payload and GVWR up to 4100 kg (9039 lbs) are robust for the category. This van also boasts a comfortable cabin, advanced safety features, and efficient drivetrains, placing it among the top choices for businesses needing a balance of space, durability, and innovation.

The Mercedes-Benz Sprinter Panel Van Compact has a roof load capacity of 300 kg (661 lbs). This significant load rating enables mounting roof racks or carrying substantial equipment on the roof, such as ladders, construction materials, or cargo boxes. It increases the vehicle's versatility for tradespeople and logistics operations that require additional storage options beyond the internal cargo area.

Introduced in 2018, the W907/W910 Sprinter Panel Van Compact benefits from modern engineering, including improved chassis rigidity, advanced safety systems like Active Brake Assist, and more efficient engines that balance power with fuel economy. The ergonomic interior design enhances driver comfort, and the van's modularity allows numerous configurations tailored to specific business needs. Additionally, connectivity and telematics options provide fleet management advantages, making this generation both practical and technologically advanced.
