2021 Mercedes-Benz S-class Long (V223) Dimensions, Size & Specs

The width of the Mercedes-Benz S-class Long (V223) ranges from 1921 mm to 1954 mm (75.6 to 76.9 inches) without considering the side mirrors. When the mirrors are extended, the width increases to 2109 mm (83.1 inches). This considerable width, especially with mirrors out, provides a commanding road presence and enhances stability but also means drivers should be cautious when navigating narrow spaces or parking.

The height of the 2021 S-class Long (V223) ranges from 1503 mm to 1515 mm (59.1 to 59.6 inches), providing a sleek and aerodynamic profile typical of a full-size luxury sedan. The ride height or ground clearance is 130 mm (5.1 inches), which balances road comfort and sufficient clearance for various driving conditions. This ground clearance is relatively low, optimized for on-road comfort rather than off-road utility.

The curb weight of the Mercedes-Benz S-class Long (V223) ranges between 1940 kg and 2520 kg (4277 to 5555 pounds), depending on specific trim levels, equipment, and options installed. The maximum permissible weight spans from 2765 kg to 3070 kg (6097 to 6769 pounds). This weight reflects the car’s advanced safety, luxury equipment, and structural reinforcement, emphasizing a balance of performance and safety in a flagship luxury sedan.

The S-class Long (V223) offers a luggage capacity ranging from 305 liters to 550 liters (approximately 10.8 to 19.4 cubic feet). The lower capacity applies when rear seats are in use, while the higher capacity is achievable by folding down rear seats or removing cargo separators. This luggage space is competitive for a full-sized luxury sedan, offering practical versatility for travel and everyday use.

Standard garages typically have a door width of about 2400 mm (94.5 inches) and length ranging from 5400 mm (213 inches). The S-class Long’s max width of 2109 mm (83.1 inches) with open mirrors fits within the door frame with some clearance, but mirrors require careful maneuvering. Its length up to 5336 mm (210 inches) comfortably fits into a standard garage, though tight garage dimensions or limited maneuvering space might require extra caution. Overall, the V223 fits standard garages but demands mindful parking techniques because of its size.

Compared to the previous generation S-class Long (V222), the V223 model is slightly longer, measuring up to 5336 mm (210 inches) versus about 5260 mm (207 inches) previously, offering more room primarily for rear passengers. Width has also increased marginally from roughly 1899 mm (74.8 inches) to up to 1954 mm (76.9 inches) with improvements in cabin space and comfort. The V223 also benefits from updated styling and a more aerodynamic profile, contributing to better efficiency despite the size increase. Weight has risen slightly to accommodate more advanced technology and safety features, but overall, the V223 represents an evolution toward even greater luxury and comfort.

In comparison to competitors like the BMW 7 Series Long Wheelbase and Audi A8 L, the S-class Long (V223) is generally similar or slightly larger in dimensions. For example, the BMW 7 Series Long is around 5267 mm (207.5 inches) long, slightly shorter than the longest S-class Long, while the Audi A8 L measures approximately 5302 mm (208.8 inches). The S-class Long typically offers more rear cabin space and luxurious appointments, which justifies the slight size edge. Width-wise, it remains competitive, but its feature set and rear passenger comfort are often regarded as class-leading in this segment.

The Mercedes-Benz S-class Long (V223) offers a wide variety of rim sizes including 10.5J x 20, 9.5J x 20, 8J x 18, 8.5J x 19, 10J x 19, 9J x 20, and up to 10J x 21 inches, tailored to different trims and performance packages. Tire sizes correspond accordingly, ranging from 255/50 R18, 255/45 R20, up to performance-oriented sizes like 285/30 R21. This variety ensures that buyers can balance between ride comfort and sporty handling, depending on their preferences and driving needs.

The Mercedes-Benz S-class Long (V223) falls into the full-size luxury sedan segment. Its main focus areas include supreme passenger comfort, especially for rear seat occupants, advanced safety technologies, cutting-edge infotainment, and smooth yet powerful performance. This generation places a significant emphasis on digital innovation with features such as augmented reality head-up displays and advanced driver assistance systems, making it a flagship model representing luxury and modern automotive technology.
