2007 Mercedes-Benz G-class Cabriolet (W463, facelift 2007) Dimensions, Size & Specs

The curb weight of the Mercedes-Benz G-class Cabriolet facelift (2007) ranges between 2175 kg and 2185 kg (approximately 4796 to 4816 lbs). The vehicle's maximum permissible weight is 2850 kg (6283 lbs), allowing it to carry payload and passengers while maintaining its off-road and towing capabilities. This relatively heavy weight is due to its robust frame, luxury features, and convertible mechanisms.

With rear seats in place, the Mercedes-Benz G-class Cabriolet (W463 facelift 2007) offers a luggage capacity of 238 liters (8.4 cubic feet). When the rear seats are folded down, this capacity significantly increases to 1580 liters (55.8 cubic feet), providing generous space for larger cargo loads. This versatility makes the vehicle practical even with the cabriolet configuration.

The G-class Cabriolet facelift 2007 boasts a ground clearance of 205 mm (8.1 inches). This elevated ride height enhances the vehicle's off-road capability by allowing it to navigate rough terrain, rocks, and obstacles without damage to the undercarriage. The balance of luxury and ruggedness is a hallmark of the G-class, complemented by its 4WD system.

The 2007 G-class Cabriolet comes equipped with rim sizes of 7.5 J x 16, and optionally 7.5 J x 18. The corresponding tire sizes include 265/70 R16 and 265/60 R18, which provide a combination of durability and traction suited for both on-road comfort and off-road adventures. These wide tires contribute to the vehicle's stability and rugged aesthetic.

The G-class Cabriolet's dimensions, particularly its height of 1941 mm (76.4 inches) and width with mirrors extended at 2007 mm (79 inches), can make fitting into a standard residential garage somewhat tight. Many garages typically have widths around 2400 to 2700 mm (94 to 106 inches) and heights around 2100 to 2400 mm (83 to 94 inches), so while it is generally possible to park the vehicle inside a standard garage, careful maneuvering is necessary, especially considering mirror clearance and taller height.

Compared to its predecessor models, the 2007 facelift of the W463 G-class Cabriolet maintains very similar overall dimensions, with a length of 4257 mm and width of 1760 mm (without mirrors). Minor refinements in styling and details occurred, but the dimensions largely stayed consistent to preserve the characteristic rugged yet luxurious proportions. The facelift mainly improved interior luxury and performance rather than changing size significantly.

The G-class Cabriolet of 2007 is unique in the off-road convertible segment due to its blend of luxury, robust build, and serious off-road capability. Dimensionally, it is larger and heavier than many competitors like the Jeep Wrangler or Land Rover Defender convertible variants. Its 2175-2185 kg curb weight and more substantial dimensions afford superior towing and load capacities, while offering a premium interior and advanced 4WD system. This positions it as a high-end option designed for both rugged terrain and open-air luxury cruising.

The typical ride height or ground clearance of the 2007 G-class Cabriolet is 205 mm (8.1 inches). This generous clearance contributes to improved handling over uneven and off-road surfaces by preventing underbody damage and enabling the vehicle to clear obstacles. While it may lead to a higher center of gravity compared to lower vehicles, the G-class's robust suspension and electronic stability controls help maintain stable handling on and off-road.

With mirrors opened, the 2007 G-class Cabriolet measures a width of 2007 mm (79 inches). This wider footprint requires extra caution when maneuvering through narrow streets, tight parking spaces, or gated entrances. Drivers should account for the mirrors especially in urban or confined environments. However, the mirrors can often be folded when parking to reduce width, facilitating navigation in tighter spaces.
