2016 Mercedes-Benz E-class T-modell (S213) Dimensions, Size & Specs

The width of the Mercedes-Benz E-class T-modell (S213) varies from 1852 mm to 1907 mm (72.9 inches to 75.0 inches), depending on the model and trim. When including the side mirrors in their fully opened position, the width extends to 2065 mm (81.3 inches). This wider dimension must be considered for parking and garage space, as the mirrors significantly increase the vehicle's total width.

The height of the Mercedes-Benz E-class T-modell (S213) ranges from 1461 mm to 1475 mm (57.5 inches to 58.1 inches). This relatively low height for a station wagon contributes to the car’s sleek profile and aerodynamic efficiency while still maintaining comfortable headroom for passengers inside. The slight variation is typically due to different suspension setups or optional equipment such as roof rails.

The curb weight of the Mercedes-Benz E-class T-modell (S213) varies between 1630 kg and 2140 kg (3594 lbs to 4717 lbs). The lower end corresponds to lighter base models equipped with fewer features, while higher weights are associated with more powerful engine options and additional equipment. This weight range reflects the robust build quality and the luxury features typical for an E-class station wagon.

The maximum gross vehicle weight (GVW) of the E-class T-modell (S213) ranges between 2375 kg and 2800 kg (5239 lbs to 6173 lbs). GVW includes the vehicle itself, passengers, cargo, and fuel. This figure ensures the vehicle can safely carry heavy loads, especially important for a station wagon designed to offer ample cargo capacity.

The luggage capacity of the Mercedes-Benz E-class T-modell (S213) is 640 liters (22.6 cubic feet) with the rear seats up, providing ample space for everyday use or moderate luggage needs. When the rear seats are folded down, the capacity expands significantly to 1820 liters (64.3 cubic feet), enabling the transport of larger items or bulkier cargo, which highlights its versatility as a premium station wagon.

The ride height or ground clearance of the Mercedes-Benz E-class T-modell (S213) ranges from 112 mm to 126 mm (4.4 inches to 5.0 inches). This relatively low clearance contributes to better handling and a sporty driving feel by lowering the center of gravity. However, it might require careful navigation over speed bumps or rough terrain compared to higher-riding SUVs or crossovers.

Yes, the Mercedes-Benz E-class T-modell (S213) generally fits into a standard garage. Its length up to 5000 mm (196.9 inches) and height up to 1475 mm (58.1 inches) are within typical residential garage limits. However, width with mirrors opened (2065 mm or 81.3 inches) could be a tight fit in narrower garages, so it’s advisable to fold mirrors in, as the width without mirrors is a more common reference for parking. Overall, parking the E-class T-modell in a standard garage is practical for most owners.

Compared to its predecessor, the Mercedes-Benz E-class T-modell (S212), the S213 model maintains a similar footprint but offers some refinements. The S213 slightly increased its maximum length up to 5000 mm (196.9 inches) versus the S212, which was roughly up to 4875 mm (191.9 inches). Width and height are comparable, with minor improvements in aerodynamics and interior spaciousness. Regarding weight, the S213 builds on its predecessor’s curb weight range, with slightly heavier curb weights due to added safety features and technology but improved structural rigidity. Overall, the S213 enhances comfort and efficiency while maintaining practicality and size familiarity for E-class wagon enthusiasts.

The Mercedes-Benz E-class T-modell (S213) competes in the executive station wagon segment, where size and cargo capacity are key factors. It is generally similar in length and width to rivals such as the Audi A6 Avant and BMW 5 Series Touring, all of which fall into the roughly 4900-5000 mm (192.9-196.9 inches) length range. The E-class T-modell is notable for offering a generous 640 liters (22.6 cubic feet) of rear luggage space, which is competitive or superior compared to many rivals. Its ground clearance, while lower than some crossovers, emphasizes sporty handling, distinguishing it from more SUV-like competitors. Overall, the E-class T-modell balances luxury, size, and practicality effectively within its class.
