2019 Mazda MX-5 IV (ND, facelift 2018) Dimensions, Size & Specs

The Mazda MX-5 IV has a width of 1735 mm without mirrors, which converts to about 68.3 inches or 5.7 feet. With the mirrors opened, the width increases to 1918 mm, equating to roughly 75.5 inches or 6.29 feet. This difference is significant for parking or navigating tight spaces, as the mirror spread affects overall vehicle width when driving or stationary.

The vehicle's height ranges from 1225 mm to 1234 mm, equivalent to approximately 48.23 inches to 48.58 inches, or about 4.02 to 4.05 feet. This low height contributes to the MX-5's sporty roadster profile, enhancing aerodynamics and providing a low center of gravity, which benefits handling and driving dynamics.

The curb weight of the Mazda MX-5 IV ranges from 1000 kg to 1083 kg, which translates to about 2205 to 2387 pounds. This relatively low weight is a key element in the car's agility and performance, making it lighter and more responsive compared to many other sports cars in its class.

The Mazda MX-5 IV provides a luggage capacity of 130 liters. In cubic feet, this roughly equals 4.59 cubic feet. Despite the compact and sporty nature of the roadster, this luggage space is adequate for small bags, making it practical for short trips or weekend drives, though not suitable for large or bulky items.

The ride height or ground clearance of the Mazda MX-5 IV is 125 mm, approximately 4.92 inches. This low clearance enhances the car’s handling and sporty feel by reducing body roll and improving stability. However, it requires attention when driving over speed bumps or uneven terrain, as scraping the underside is more likely than with higher clearance vehicles.

Yes, the Mazda MX-5 IV fits comfortably into a standard garage. Its length of around 3.914 to 3.915 meters (about 12.85 feet), width without mirrors of 1.735 meters (5.7 feet), and low height (~1.23 meters or 4 feet) ensure it can be parked with ease within most typical residential garage spaces, which generally accommodate vehicles up to about 6 meters (20 feet) long and 2.4 meters (8 feet) wide.

Compared to the third-generation MX-5 (NC), the fourth-generation MX-5 IV is notably smaller and lighter. The NC measures approximately 4050 mm (159.4 inches) in length and 1745 mm (68.7 inches) in width, while the ND’s length of about 3914 mm (154.1 inches) and width of 1735 mm (68.3 inches) reflects downsizing for improved agility and handling. The curb weight of the ND is also significantly lower (about 1000 - 1083 kg) compared to the NC’s roughly 1100 - 1250 kg, evidencing Mazda’s focus on weight reduction and driving dynamics. This makes the ND more compact and nimble, with an even sportier feel.

The Mazda MX-5 IV is considerably smaller and lighter than the Toyota GR86 and Subaru BRZ, two popular sports coupes. The MX-5 measures roughly 3.914 meters (154.1 inches) in length and weighs around 1000 - 1083 kg (2205 - 2387 lbs), whereas the GR86 and BRZ are longer and heavier, with lengths exceeding 4.27 meters (168 inches) and weights in the range of 1250 - 1350 kg (2755 - 2976 lbs). The MX-5’s compact dimensions and lower weight emphasize agility and an engaging open-top driving experience, while the GR86 and BRZ offer a larger cabin and hatchback-like practicality but with slightly less nimbleness.

The Mazda MX-5 IV rides on 16-inch rims, sized 6.5J x 16, fitted with 195/50 R16 tires. These moderately sized rims and relatively narrow tires complement the lightweight design and help maintain responsive steering and road feedback. The tire profile of 50 indicates a balance between sporty handling and ride comfort, allowing the MX-5 to deliver precise cornering ability while ensuring everyday drivability on varying road surfaces.
