2015 Mazda CX-5 (facelift 2015) Dimensions, Size & Specs

The width of the 2015 facelift Mazda CX-5 with mirrors opened is 2168 mm (85.3 inches). This measurement is critical for everyday usability such as parking, navigating narrow streets, and fitting in garage spaces. Wider mirror spans can make tight spaces more challenging, so it's essential to consider this when planning parking and driving in congested urban environments.

With a height of 1710 mm (67.3 inches) and a ground clearance (ride height) of 210 mm (8.3 inches), the facelifted Mazda CX-5 offers a good balance between urban practicality and off-road capability. The relatively high ground clearance improves its ability to handle rough terrain, speed bumps, and potholes, while the moderate overall height ensures it remains stable during highway driving and easy to maneuver in most parking structures.

The curb weight of the 2015-2017 Mazda CX-5 facelift ranges between 1315 kg to 1495 kg (2899 to 3297 lbs), depending on the variant and equipment level. A lighter curb weight generally results in better fuel efficiency, improved acceleration, and nimble handling, while a heavier curb weight can contribute to enhanced ride comfort and stability. This range strikes a balance appropriate for a compact SUV.

The maximum permissible weight (gross vehicle weight rating) for the facelifted Mazda CX-5 ranges from 1995 kg to 2125 kg (4399 to 4685 lbs). This figure represents the maximum combined weight of the vehicle including passengers, cargo, and tow load. Staying within this limit ensures safe driving dynamics, braking performance, and longevity of vehicle components.

With the rear seats raised, the 2015 facelift Mazda CX-5 offers a luggage capacity of 503 liters (17.8 cubic feet). Folding the rear seats down dramatically increases cargo space to 1620 liters (57.2 cubic feet). This flexible cargo capacity makes the CX-5 practical for everyday shopping, family trips, or transporting larger items, showcasing its versatility as a compact SUV.

A standard residential garage typically measures about 2440 mm (96 inches) wide and 5180 mm (204 inches) deep. Given the CX-5's width of 1840 mm (72.4 inches) without mirrors but 2168 mm (85.3 inches) with mirrors open, it can fit within garage width if mirrors are folded. The length of 4555 mm (179.3 inches) is well within typical garage depths. Therefore, the CX-5 can fit in a standard garage comfortably as long as the side mirrors are folded in.

The facelifted 2015 Mazda CX-5 maintained very similar exterior dimensions compared to its predecessor (2012-2015). The length remained close to 4555 mm (179.3 inches), and width and height saw nominal changes. The main updates were aesthetic and feature-based rather than resizing. This means owners of the earlier CX-5 generation will find familiar spatial characteristics and usage practicality in the facelifted model.

Compared to other compact SUVs around the 2015 model year, the Mazda CX-5 facelift has competitive dimensions. Its length of 4555 mm (179.3 inches) and width of 1840 mm (72.4 inches) place it comfortably in the mid-range within the segment, comparable to rivals like the Honda CR-V and Toyota RAV4. Additionally, its ground clearance of 210 mm (8.3 inches) is slightly higher than some competitors, giving a slight advantage in light off-road conditions and rough terrain handling.
