2019 Mazda CX-30 Dimensions, Size & Specs

With the side mirrors opened, the Mazda CX-30 spans 2040 mm (80.3 inches) in width. This dimension is crucial when considering parking space clearance and maneuvering through tight spots, such as narrow city streets or parking garages, where mirror clearance can affect ease of use and risk of damage.

The Mazda CX-30 weighs between 1320 kg (2910 lbs) and 1592 kg (3510 lbs) depending on the trim and equipment options. Its maximum loaded weight ranges from 1927 kg (4248 lbs) to 2070 kg (4562 lbs), reflecting the combined total of vehicle weight plus passengers, cargo, and fuel. This weight capacity supports the vehicle's SUV versatility without compromising handling or performance.

The Mazda CX-30 offers a luggage capacity of 422 to 430 liters (14.9 to 15.2 cubic feet) with the rear seats in their normal upright position. Folding down the rear seats expands this space substantially to 1406 liters (49.6 cubic feet), providing ample room for larger items or significant cargo volume, making it flexible for various lifestyle needs.

The roof load capacity of the Mazda CX-30 is rated at 75 kg (165 lbs), suitable for luggage racks or roof boxes but important to not exceed for safety and performance. Ground clearance or ride height ranges between 175 mm (6.9 inches) and 203 mm (8 inches), allowing for confident handling on rough roads or light off-road conditions common for SUVs of this segment.

Yes, the Mazda CX-30 fits comfortably inside a standard residential garage. With a length of 4395 mm (172.8 inches) and width of 1795 mm (70.7 inches) without mirrors, it accommodates typical single-car garage dimensions, which usually measure at least 2440 mm (96 inches) wide by 5180 mm (204 inches) deep. However, note that with mirrors opened at 2040 mm (80.3 inches) width, careful folding or positioning may be needed.

Compared to the Mazda CX-3, the CX-30 is notably larger and more practical. The CX-3 is shorter at approximately 4275 mm (168.3 inches) in length and narrower around 1765 mm (69.5 inches). This added length and width in the CX-30 translate to more interior space for rear-seat passengers and greater cargo capacity, addressing practical needs without sacrificing maneuverability. The CX-30 also offers improved ground clearance, enhancing versatility compared to the CX-3.

The Mazda CX-30 sits competitively among compact SUVs like the Honda HR-V and Toyota C-HR. Dimensionally, the CX-30 is slightly longer than the Toyota C-HR (which measures about 4390 mm or 172.8 inches) and wider than the Honda HR-V (generally around 1790 mm or 70.5 inches). The CX-30 typically offers a more upscale interior and driving experience, with comparable cargo volumes—422 to 430 liters with seats upright—and versatile folding rear seats expanding capacity significantly. Its higher ground clearance (175-203 mm) favors rougher terrain handling compared to some rivals.

The Mazda CX-30 comes equipped with a range of tire sizes including 215/65 R16 and 215/55 R18, matched with corresponding rim sizes such as 16-inch and 18-inch wheels. Rim widths vary from 6.5J to 7J with an offset of ET45. Larger rims and tires can subtly affect ride height and handling dynamics but generally stay within the vehicle’s specified ground clearance range of 175 mm to 203 mm (6.9 to 8 inches), balancing comfort and road presence.

The Mazda CX-30 offers a ride height between 175 mm and 203 mm (6.9 to 8 inches), which strikes a practical balance for everyday urban driving and occasional light off-roading. This ground clearance helps drivers navigate uneven surfaces, speed bumps, and mild off-road paths without risking damage to the undercarriage. It also provides a commanding driving position enhancing visibility and confidence compared to lower-riding vehicles, while maintaining stability and efficient handling on paved roads.
