2005 Mazda 5 I Dimensions, Size & Specs

The Mazda 5 I has a width of 1755 mm (69.1 inches). Its height ranges from 1615 mm to 1665 mm (63.6 - 65.6 inches), depending on specific versions or optional roof configurations. The relatively modest width aids in navigating tight city streets and parking spaces, while the height allows for a comfortable interior headroom that's typical for minivans. This balance offers a spacious cabin while keeping the vehicle's profile fairly low, reducing aerodynamic drag and improving stability.

The Mazda 5 I weighs between 1395 kg and 1537 kg (3075 - 3389 lbs) in curb weight, which is the weight of the car without passengers or cargo. This weight range is moderately light for a minivan, contributing positively to its handling capabilities and fuel efficiency. A lighter vehicle mass helps improve acceleration, braking, and overall agility on the road. It also generally means better fuel consumption figures, making the Mazda 5 I an economical choice for families needing a versatile vehicle.

The maximum permissible weight—often called gross vehicle weight rating (GVWR)—for the Mazda 5 I ranges from 2074 kg to 2230 kg (4573 - 4916 lbs). This value indicates the maximum total weight the vehicle can safely carry, including the vehicle itself, passengers, cargo, and fuel. Paying attention to the GVWR is critical as overloading the vehicle can compromise safety, braking efficiency, and handling, besides potentially causing excessive wear or damage to the suspension and tires.

The Mazda 5 I provides a luggage capacity of 112 to 538 liters (3.95 - 19 cubic feet) with the rear seats up, which is sufficient for everyday shopping or small family trips. When the rear seats are folded down, the cargo space significantly expands to between 1566 and 1678 liters (55.3 - 59.2 cubic feet), allowing for the transport of bulky items such as furniture, large suitcases, or sports equipment. This flexible capacity is a strong benefit for buyers who need versatility for different passenger and cargo needs.

The Mazda 5 I has a ground clearance of 140 mm (5.5 inches). This moderate ride height is typical for minivans and provides a good balance between ease of entry and exit, aerodynamics, and the ability to handle uneven urban roads or mild off-road conditions like gravel or unpaved surfaces. However, it’s not intended for heavy off-roading, and drivers should be cautious over large obstacles or steep inclines.

Yes, the Mazda 5 I will generally fit comfortably into a standard residential garage. Typical garages have a width of about 2.4 to 2.7 meters (7.9 to 8.9 feet) and the Mazda 5 I’s width is approximately 1.755 meters (5.75 feet), providing enough clearance on both sides in most cases. Its length ranges from 4.505 to 4.610 meters (14.79 to 15.12 feet), which is also compatible with standard garage depths of about 5.5 to 6 meters (18 to 20 feet). It’s always a good idea to measure your garage regardless but dimension-wise, the Mazda 5 fits well in typical home garages.

The Mazda 5 I represented the first generation of the Mazda 5 model (2005-2007), so it did not have a direct predecessor under the same name. However, it essentially took over from the older Mazda Premacy (known as the Mazda 5 in some markets). Compared to the earlier Premacy, the Mazda 5 I offered a more modern and slightly larger profile, improved interior versatility, and updated styling. In terms of dimensions, it maintained compact minivan characteristics with an emphasis on efficient space usage, enhancing usability while staying easy to drive in urban environments.

Compared to other compact minivans from the mid-2000s, such as the Ford C-Max and the Volkswagen Touran, the Mazda 5 I offered competitive dimensions that balanced interior space and exterior compactness. With lengths around 4.5 to 4.6 meters (about 177 to 181 inches), it was slightly longer than the C-Max but roughly similar in size to the Touran. Its flexible seating and cargo options, together with its sleek styling and efficient use of space, positioned it well in this segment. The Mazda 5 I was often favored for its driving dynamics and reliability compared to some rivals, making it a strong choice among these multipurpose vehicles.

The Mazda 5 I comes with several rim size options: 15-inch (6J x 15), 16-inch (6.5J x 16), and 17-inch (6.5J x 17). Corresponding tire sizes include 195/65 R15, 205/55 R16, and 205/50 R17. Smaller rims with higher profile tires (e.g., 15-inch) generally result in a more comfortable ride due to better shock absorption, which is excellent for family and daily commuting. Larger rims with low-profile tires (e.g., 17-inch) tend to offer improved handling and a sportier appearance but can transmit more road imperfections into the cabin. Consumers can choose based on their preference between comfort and sporty driving feel.
