2022 Lincoln Navigator IV L (facelift 2021) Dimensions, Size & Specs

Production
Model Year:2022
Production Years:2021 - 2024 discontinued in 2024
1935 mm76.2 in6.3 ft
5636 mm221.9 in18.5 ft
1935 mm76.2 in6.3 ft
5636 mm221.9 in18.5 ft
1935 mm76.2 in6.3 ft
2383 mm93.8 in7.8 ft
1935 mm76.2 in6.3 ft
2383 mm93.8 in7.8 ft
1935 mm76.2 in6.3 ft
5636 mm221.9 in18.5 ft
1935 mm76.2 in6.3 ft
2383 mm93.8 in7.8 ft
1935 mm76.2 in6.3 ft
2383 mm93.8 in7.8 ft
Length
5636 mm221.9 in18.5 ft
Width
2383 mm93.8 in7.8 ft
Height
1935 mm76.2 in6.3 ft
Trunk Capacity
971 liter34.3 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2022 Lincoln Navigator IV L, engineered for optimal performance and comfort

Dimensions
Length:5636 mm221.9 in18.5 ft
Width:2029 mm79.9 in6.7 ft
Width (Folded Mirrors):2123 mm83.6 in7.0 ft
Width (Opened Mirrors):2383 mm93.8 in7.8 ft
Height:1935 mm76.2 in6.3 ft
Ground Clearance:244 - 246 mm9.6 - 9.7 in0.8 - 0.8 ft
Trunk Capacity:971 liter34.3 cu ft
Trunk Capacity (Max):3404 liter120.2 cu ft
Weight Specifications
Curb Weight:2688 - 2747 kg5926 - 6056 lbs
Tire Specifications
Rims Sizes:20, 22
Tire Sizes:275/55 R20 (W:275 | H:55 | D:20)
285/45 R22 (W:285 | H:45 | D:22)
Useful Information

About 2022 Lincoln Navigator IV L

The 2022 Lincoln Navigator IV L facelift is a full-size luxury SUV produced from 2021 to 2024, representing the latest update of the fourth-generation Navigator long-wheelbase model. This SUV is characterized by its commanding dimensions and refined presence on the road, combining luxury with expansive interior space and practical utility. The Navigator IV L measures an impressive 5636 mm (221.9 inches) in length, providing ample room for passengers and cargo. It boasts a width of 2029 mm (79.8 inches) with mirrors folded, expanding to 2383 mm (93.8 inches) when mirrors are opened, ensuring a broad stance and stability. The vehicle height ranges between 1933 and 1935 mm (76.1 - 76.2 inches), contributing to its commanding SUV profile.

Weighing between 2688 and 2747 kilograms (5925 to 6058 pounds), the Navigator IV L embodies the robust construction and premium materials expected in this segment. Ground clearance is rated between 244 and 246 mm (9.6 to 9.7 inches), facilitating confident driving over various terrains.

Luggage capacity is one of the standout features, with 971 liters (34.3 cubic feet) available behind the rear seats for everyday use, expanding substantially to 3404 liters (120.1 cubic feet) when the rear seats are folded down – ideal for hauling large items or extended luggage for long trips.

This luxury SUV comes equipped with sizeable 20 or 22-inch rims, paired with tire sizes 275/55 R20 and 285/45 R22, delivering a blend of road comfort and style. The Lincoln Navigator IV L facelift perfectly balances commanding size, luxury, and utility, making it a top choice for drivers seeking spaciousness and premium features in a full-size SUV.

Exceptional Features

2022 Lincoln Navigator IV L Highlights

Discover the standout features that make the 2022 Lincoln Navigator IV L a leader in its class

Powerful Engine

Equipped with a 3.5L twin-turbocharged V6 EcoBoost engine producing 450 horsepower and 510 lb-ft of torque, providing robust performance and smooth acceleration.

Luxurious Interior

Features premium materials including leather upholstery, wood trim, and ambient lighting, offering a spacious and comfortable cabin with seating for up to eight passengers.

Advanced Technology

Includes a 13.2-inch touchscreen with SYNC 4 infotainment system, wireless Apple CarPlay and Android Auto, and a premium Revel audio system for enhanced connectivity and entertainment.

Safety and Driver Assistance

Equipped with Lincoln Co-Pilot360 technology suite, featuring adaptive cruise control, lane-keeping assist, blind-spot monitoring, and automatic emergency braking for enhanced safety.

Spacious Cargo Capacity

Offers generous cargo space, especially in the extended L version, with split-folding rear seats for versatile storage options and enhanced practicality.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The 2022 Lincoln Navigator IV L (facelift 2021) SUV measures 5636 mm (221.8 inches) in length, 2029 mm (79.9 inches) in width without mirrors, 2123 mm (83.5 inches) with folded mirrors, and 2383 mm (93.8 inches) with mirrors opened. The height ranges between 1933 mm to 1935 mm (76.1 to 76.2 inches), providing a commanding road presence typical of full-size luxury SUVs.

The curb weight of the Lincoln Navigator IV L (facelift 2021) ranges between 2688 kg and 2747 kg (5926 to 6058 lbs). This substantial weight reflects its large size and luxury features, contributing to a smooth and stable ride. However, it also impacts fuel consumption and maneuverability, requiring a strong engine and well-tuned suspension to maintain comfort and performance.

With all rear seats up, the 2022 Lincoln Navigator IV L provides a generous luggage capacity of 971 liters (34.3 cubic feet). When the rear seats are folded down, the cargo space expands dramatically to 3404 liters (120.2 cubic feet). This makes it highly versatile for transporting bulky items, long trips, or moving larger loads, underscoring its practicality as a luxury SUV.

The Navigator IV L features a ground clearance between 244 and 246 mm (9.6 to 9.7 inches), offering ample clearance for light off-road conditions, uneven terrains, and urban obstacles such as curbs. This ride height strikes a balance between luxury SUV comfort and some degree of ruggedness, making it suitable for drivers who want elevated driving position with occasional off-pavement capability.

Fitting the Lincoln Navigator IV L into a standard residential garage may be challenging due to its large dimensions. Typical garage widths are about 2400 to 2700 mm (94.5 to 106.3 inches), while the Navigator is 2123 mm wide with mirrors folded (83.5 inches) but expands to 2383 mm (93.8 inches) with mirrors extended. Its height of approximately 1935 mm (76.2 inches) generally fits standard garage door heights, but careful maneuvering is essential due to width and length.

Compared to the third-generation Navigator, the fourth-generation Navigator IV L (facelift 2021) maintains a similar footprint but features refinements in length and width to enhance interior space and presence. The Navigator IV L is typically longer and wider, contributing to increased passenger comfort and cargo capacity. Both models aim for luxury and size, but the facelift also improved aerodynamics and modern styling cues, offering a more contemporary look.

The Navigator IV L is among the largest luxury SUVs, competing with models like the Cadillac Escalade ESV, Mercedes-Benz GLS, and BMW X7. Its 5636 mm (221.8 inches) length and nearly 2-meter width position it at the upper end of size metrics, offering more interior and cargo space than many competitors. It is ideal for buyers prioritizing maximum space, luxury, and road presence.

The Navigator IV L comes equipped with rim options of 20- and 22-inch sizes, paired with tires sized 275/55 R20 or 285/45 R22. Larger 22-inch wheels with lower profile tires provide sharper handling and an aggressive stance but may sacrifice some ride comfort on rough roads. Conversely, 20-inch wheels with higher profile tires generally yield a smoother, more cushioned ride, fitting the SUV’s luxury character.

The Lincoln Navigator IV L offers spacious three-row seating designed to accommodate seven or eight passengers depending on configuration. The extended wheelbase version (L) provides increased legroom especially in the rear seats, making it exceptionally comfortable for adults in all seating rows. Luxury appointments include premium materials, advanced climate control, and cutting-edge infotainment technologies for an elevated passenger experience.

The 2022 Lincoln Navigator IV L stands out through its combination of expansive interior space, high-end materials like handcrafted wood and leather, and cutting-edge technology features. It boasts an advanced suite of driver assistance systems, premium audio, and optional twin-panel panoramic roof enhancing ambiance. Its powerful engine and smooth suspension make it a capable yet refined full-size SUV tailored to luxury buyers who want comfort, style, and space.
