2022 Lincoln Navigator IV (facelift 2021) Dimensions, Size & Specs

Production
Model Year:2022
Production Years:2021 - 2024 discontinued in 2024
1941 mm76.4 in6.4 ft
5334 mm210.0 in17.5 ft
1941 mm76.4 in6.4 ft
5334 mm210.0 in17.5 ft
1941 mm76.4 in6.4 ft
2383 mm93.8 in7.8 ft
1941 mm76.4 in6.4 ft
2383 mm93.8 in7.8 ft
1941 mm76.4 in6.4 ft
5334 mm210.0 in17.5 ft
1941 mm76.4 in6.4 ft
2383 mm93.8 in7.8 ft
1941 mm76.4 in6.4 ft
2383 mm93.8 in7.8 ft
Length
5334 mm210.0 in17.5 ft
Width
2383 mm93.8 in7.8 ft
Height
1941 mm76.4 in6.4 ft
Trunk Capacity
547 liter19.3 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2022 Lincoln Navigator IV, engineered for optimal performance and comfort

Dimensions
Length:5334 mm210.0 in17.5 ft
Width:2029 mm79.9 in6.7 ft
Width (Folded Mirrors):2123 mm83.6 in7.0 ft
Width (Opened Mirrors):2383 mm93.8 in7.8 ft
Height:1941 mm76.4 in6.4 ft
Ground Clearance:244 - 246 mm9.6 - 9.7 in0.8 - 0.8 ft
Trunk Capacity:547 liter19.3 cu ft
Trunk Capacity (Max):2925 liter103.3 cu ft
Weight Specifications
Curb Weight:2579 - 2656 kg5686 - 5855 lbs
Tire Specifications
Rims Sizes:20, 22
Tire Sizes:275/55 R20 (W:275 | H:55 | D:20)
285/45 R22 (W:285 | H:45 | D:22)
Useful Information

About 2022 Lincoln Navigator IV

The 2022 Lincoln Navigator IV (facelift 2021) is a full-size luxury SUV that offers a commanding presence on the road, combining spaciousness with premium design and advanced technology. Produced from 2021 to 2024, this generation Navigator showcases impressive exterior dimensions with a length of 5334 mm (210 inches), a width of 2029 mm (79.8 inches) excluding mirrors, expanding to 2383 mm (93.8 inches) when mirrors are opened, and a height that varies between 1938 mm (76.3 inches) and 1941 mm (76.4 inches). These dimensions contribute to its spacious interior and road stability. The vehicle maintains a substantial curb weight ranging from 2579 kg (5688 lbs) to 2656 kg (5856 lbs), reflecting its build quality and luxury features. The Navigator IV is designed for versatility with a luggage capacity of 547 liters (19.3 cubic feet) when all seats are in use, which dramatically expands to 2925 liters (103.3 cubic feet) when rear seats are folded down, providing ample cargo space for large family trips or cargo hauling. Its ride height or ground clearance ranges from 244 mm to 246 mm (9.6 to 9.7 inches), allowing for confident handling on various terrains while preserving comfort. Available with rim sizes of 20 and 22 inches paired with tire dimensions of 275/55 R20 and 285/45 R22, this Navigator model combines aesthetic appeal with robust road grip. Overall, the 2022 Lincoln Navigator IV facelift stands as an ideal choice for buyers seeking a large, luxurious SUV with significant passenger and cargo space, enhanced road presence, and advanced vehicle dynamics.

Exceptional Features

2022 Lincoln Navigator IV Highlights

Discover the standout features that make the 2022 Lincoln Navigator IV a leader in its class

Powertrain

Equipped with a 3.5-liter twin-turbocharged V6 engine producing 450 horsepower and 510 lb-ft of torque, paired with a 10-speed automatic transmission for smooth and responsive performance.

Interior Luxury

Spacious and luxurious cabin with premium materials, including leather upholstery, real wood accents, and available massaging front seats, offering a first-class experience for all passengers.

Technology

Features a large 13.2-inch touchscreen infotainment system with SYNC 4, wireless Apple CarPlay and Android Auto, a 28-speaker Revel Ultima 3D audio system, and a digital instrument cluster.

Safety and Driver Assistance

Includes Lincoln Co-Pilot360 Plus suite with adaptive cruise control, lane-keeping assist, blind-spot monitoring, automated emergency braking, and a 360-degree camera system for enhanced safety.

Towing and Capability

Robust towing capability rated at up to 8,700 pounds, making it suitable for towing trailers and boats, supported by Trailer Reverse Guidance and Trailer Sway Control features.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The 2022 Lincoln Navigator IV (facelift 2021) SUV measures 5334 mm (209.9 inches) in length, making it a large, commanding vehicle on the road. Its width varies depending on the mirrors: 2029 mm (79.8 inches) wide excluding mirrors, 2123 mm (83.5 inches) with folded mirrors, and 2383 mm (93.8 inches) with mirrors opened. The height ranges from 1938 mm to 1941 mm (76.3 to 76.4 inches), giving it a tall and robust SUV stature.

The curb weight of the 2022 Lincoln Navigator IV facelift ranges between 2579 kg and 2656 kg (5679 to 5858 lbs). This weight reflects the SUV's substantial size, luxury features, and robust build quality. While the heavier weight might reduce agility compared to smaller SUVs, it contributes to a stable ride and solid road presence. The Navigator is engineered to balance weight with powerful engines to maintain commendable acceleration and towing capacities appropriate for its class.

This generation of the Lincoln Navigator offers a ride height or ground clearance between 244 mm and 246 mm (9.6 to 9.7 inches). Such clearance is quite good for tackling uneven urban roads, light off-road conditions, or obstacles like speed bumps and curbs, providing a confident driving experience both in the city and on gently rugged terrain.

The 2022 Lincoln Navigator IV facelift provides a generous luggage capacity of 547 liters (19.3 cubic feet) with all seats upright. When the rear seats are folded down, the cargo space expands dramatically to an impressive 2925 liters (103.3 cubic feet). This flexibility makes it an excellent choice for families or individuals needing to transport large amounts of cargo or bulky items with ease.

Given its dimensions—an overall length of 5334 mm (about 17.5 feet), height up to 1941 mm (6.37 feet), and width up to 2383 mm (7.82 feet) with mirrors extended—the Lincoln Navigator IV is larger than many vehicles and requires a spacious garage. Standard single-car garages typically measure around 6m (20 feet) deep by 3m (10 feet) wide, so it will fit lengthwise but may feel tight widthwise, especially with mirrors open. Folding mirrors can help improve clearance. It's advisable to measure your garage dimensions carefully before parking this SUV inside.

Compared to the previous Navigator III generation, the Navigator IV facelift retains a similar length and height but features subtle refinements that slightly adjust its overall footprint. For example, the length remains large at 5334 mm (about 209.9 inches), ensuring ample cabin space and road presence. The older Navigator III was slightly shorter and narrower, so the facelifted fourth generation offers a marginally roomier interior and exterior stance. These refinements improve passenger comfort and cargo versatility while maintaining the luxury character Lincoln is known for.

The 2022 Lincoln Navigator IV facelift stands out in the luxury full-size SUV segment for its considerable size. At 5334 mm (209.9 inches) in length, it is generally longer than competitors like the Cadillac Escalade or the Range Rover. Its width with mirrors open (2383 mm or 93.8 inches) is also among the wider SUVs available, contributing to its commanding road presence. This expansive size translates into spacious interiors and superior cargo flexibility. Customers seeking luxurious, roomy family transportation will find the Navigator comfortably spacious yet on the larger side for urban environments.

The Navigator IV facelift is offered with rim sizes of 20 and 22 inches, complemented by tire sizes of 275/55 R20 and 285/45 R22, respectively. Larger rims and lower-profile tires (like the 22-inch with 285/45) generally enhance the SUV's sporty appearance and cornering precision but may slightly reduce ride softness by transmitting more road imperfections. The 20-inch wheels with taller sidewall tires offer a more cushioned ride over rough surfaces, making them ideal for comfort-oriented drivers.

The Lincoln Navigator IV facelift has a height varying from 1938 mm to 1941 mm (76.3 to 76.4 inches). This substantial stature aids in roomy interior headroom, making it comfortable for taller passengers in all three rows. The height also enhances the commanding driving position typical of large SUVs, improving forward visibility. Additionally, the interior benefits from this vertical space, allowing Lincoln to incorporate luxury features such as panoramic sunroofs without compromising passenger headroom.

The Navigator IV facelift is designed with family needs in mind, offering multiple rows of seating that comfortably accommodate seven or eight passengers, depending on configuration. The large dimensions and generous interior volume provide plenty of legroom and headroom across all rows. With a luggage capacity of 547 liters (19.3 cubic feet) with all seats up and an expansive 2925 liters (103.3 cubic feet) when rear seats fold, families can transport everything from groceries to bulky sports equipment easily. Its flexible interior layout and quality materials also contribute to a premium, family-friendly environment.
