2015 Lincoln Navigator III L (facelift 2015) Dimensions, Size & Specs

This Navigator generation has a curb weight of approximately 2749 kg (6061 lbs), indicating its substantial build quality with luxury and performance features. Its maximum weight capacity or gross vehicle weight rating (GVWR) is around 3461 kg (7633 lbs), which factors in passengers, cargo, and fuel. This high GVWR reflects its capability as a large luxury SUV designed for both comfort and towing.

With all seats in use, the Navigator III L provides a generous luggage capacity of 1206 liters (42.6 cubic feet), suitable for typical family travel needs. When the rear seats are folded down, the cargo volume greatly expands to 3630 liters (128.2 cubic feet), offering extensive space for bulky items or extended luggage loads. This versatility makes the Navigator III L well-suited for road trips and transporting large gear.

The ride height or ground clearance for this Navigator is 213 mm (8.4 inches). This clearance allows the SUV to handle uneven terrain and light off-road conditions while maintaining a smooth ride on paved roads. It strikes a good balance between luxury road comfort and practical capability in various driving situations.

Fitting the Navigator III L into a standard single-car garage can be challenging due to its size. With a length of 5646 mm (222.2 inches) and a width of up to 2332 mm (91.7 inches) with mirrors open, many typical garages (often around 5500 mm long and 2400 mm wide) may require careful maneuvering or closing mirrors. Homeowners with compact garages might need to fold mirrors or ensure extra space for comfortable parking.

The width with mirrors folded is 2002 mm (78.8 inches), whereas with mirrors fully extended, it increases significantly to 2332 mm (91.7 inches). This nearly 33 cm (13 inches) difference can affect parking and driving in narrow spaces. Folding mirrors improves maneuverability and reduces the vehicle's effective width, which is useful in tight urban driving conditions or narrow garages.

Compared to the previous generation, the 2015 Navigator III L facelift maintained its long-wheelbase size but benefitted from exterior design tweaks that slightly altered aerodynamics and styling. Overall length remained in the upper mid-5 meter range, and width and height saw modest changes primarily due to updated bumpers and lighting elements. This facelift focused more on refined aesthetics and technology upgrades over significant dimensional changes.

The 2015 Navigator III L is competitive in size within the full-size luxury SUV segment. It is similar in length to the Cadillac Escalade ESV (around 5734 mm) and slightly longer than the Mercedes-Benz GLS (approx. 5207 mm). Its width with mirrors folded is comparable to these rivals, but the Navigator's overall height (1981 mm) is generally a bit taller, enhancing its commanding stance. Its cargo capacity and ground clearance are also in line with segment expectations, making it a strong contender among large luxury SUVs.

The Navigator III L comes equipped with 20-inch rims paired with 275/55 R20 tires. These larger diameter wheels with relatively wide tires aid in delivering a smooth and stable ride, balancing on-road comfort with the ability to handle various terrains. The tire dimensions contribute to maintaining proper grip for the vehicle's substantial weight while improving overall driving dynamics expected in a premium SUV.

The 2015 Navigator III L facelift is a full-size luxury SUV designed for buyers seeking spaciousness, premium comfort, and strong presence on the road. Its extended wheelbase version caters to families or executives requiring abundant rear passenger space along with ample cargo capacity. It offers a blend of luxury features, powerful performance, and moderate off-road capability, addressing the market demand for versatile, upscale SUVs suitable for diverse lifestyles.
