2022 Land Rover Range Rover V SWB Dimensions, Size & Specs

Production
Model Year:2022
Production Years:2021 - present in production since 2021
1870 mm73.6 in6.1 ft
5052 - 5058 mm198.9 - 199.1 in16.6 - 16.6 ft
1870 mm73.6 in6.1 ft
5052 - 5058 mm198.9 - 199.1 in16.6 - 16.6 ft
1870 mm73.6 in6.1 ft
2209 mm87.0 in7.2 ft
1870 mm73.6 in6.1 ft
2209 mm87.0 in7.2 ft
1870 mm73.6 in6.1 ft
5052 - 5058 mm198.9 - 199.1 in16.6 - 16.6 ft
1870 mm73.6 in6.1 ft
2209 mm87.0 in7.2 ft
1870 mm73.6 in6.1 ft
2209 mm87.0 in7.2 ft
Length
5052 - 5058 mm198.9 - 199.1 in16.6 - 16.6 ft
Width
2209 mm87.0 in7.2 ft
Height
1870 mm73.6 in6.1 ft
Trunk Capacity
725 - 818 liter25.6 - 28.9 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2022 Land Rover Range Rover V SWB, engineered for optimal performance and comfort

Dimensions
Length:5052 - 5058 mm198.9 - 199.1 in16.6 - 16.6 ft
Width (Folded Mirrors):2047 mm80.6 in6.7 ft
Width (Opened Mirrors):2209 mm87.0 in7.2 ft
Height:1870 mm73.6 in6.1 ft
Ground Clearance:219 - 295 mm8.6 - 11.6 in0.7 - 1.0 ft
Trunk Capacity:725 - 818 liter25.6 - 28.9 cu ft
Trunk Capacity (Max):1841 liter65.0 cu ft
Weight Specifications
Curb Weight:2379 - 2735 kg5245 - 6030 lbs
Maximal permitted Weight:3400 - 3480 kg7496 - 7672 lbs
Roof Load:100 kg220 lbs
Useful Information

About 2022 Land Rover Range Rover V SWB

The 2022 Land Rover Range Rover V SWB (Short Wheelbase) is a premium full-size SUV offering an imposing yet refined presence on the road. In production since 2021, this generation exemplifies luxury and capability combined with robust dimensions and versatile interior space. The Range Rover V SWB measures approximately 5052 to 5058 mm (199 inches) in length, making it a sizable vehicle optimized for comfort without compromising maneuverability. The width ranges from 2047 mm (81 inches) with the mirrors folded to 2209 mm (87 inches) with mirrors unfolded, accommodating both narrow urban settings and expansive highway driving. Its height stands at 1870 mm (74 inches), providing a commanding driving position with excellent road visibility.

Weighing between 2379 and 2735 kg (5247-6028 lbs) curb weight, the Range Rover V SWB maintains a sturdy yet technologically advanced chassis designed to handle varying terrains with confidence. The maximum authorized weight ranges between 3400 and 3480 kg (7496-7671 lbs), allowing for substantial payload or towing capacity. The vehicle boasts a generous luggage capacity of 725 to 818 liters (25.6 to 28.9 cubic feet), which dramatically expands to 1841 liters (65 cubic feet) when the rear seats are folded, offering flexibility for transporting larger items or luggage on longer journeys.

Ground clearance, an important factor for an SUV with off-road aspirations, varies between 219 and 295 mm (8.6 to 11.6 inches), enhancing its ability to traverse uneven terrain and obstacles while maintaining ride comfort. Additionally, the roof load capacity of 100 kg (220 lbs) supports roof racks or carriers, increasing cargo versatility. Overall, the Range Rover V SWB exemplifies a perfect blend of luxury, practicality, and ruggedness in a smooth, refined package suited for discerning drivers looking for a sophisticated SUV capable of handling both urban and adventurous requirements.

Exceptional Features

2022 Land Rover Range Rover V SWB Highlights

Discover the standout features that make the 2022 Land Rover Range Rover V SWB a leader in its class

Engine and Performance

The 2022 Range Rover V SWB is powered by a 4.4-liter V8 twin-turbocharged engine, delivering robust performance with approximately 523 horsepower and 553 lb-ft of torque, ensuring smooth and powerful acceleration.

Interior Luxury and Comfort

This model features a meticulously crafted interior with premium materials, including Windsor leather upholstery, heated and ventilated seats, and advanced climate control, providing exceptional comfort and sophistication.

Advanced Terrain Response System

Equipped with Land Rover’s Terrain Response 2 technology, the Range Rover V SWB adapts to various driving conditions automatically, optimizing performance on different terrains such as mud, sand, rock, and snow.

Infotainment and Connectivity

The vehicle includes a Pivi Pro dual touchscreen system with a 13.1-inch upper display and a 13.7-inch lower touchscreen, supporting smartphone integration via Apple CarPlay and Android Auto, along with a premium Meridian sound system.

Safety and Driver Assistance

The 2022 Range Rover V SWB comes with a suite of advanced safety features such as adaptive cruise control, lane keep assist, blind spot monitoring, 3D surround camera, and emergency braking to enhance driver confidence and safety.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The 2022 Land Rover Range Rover V SWB measures approximately between 5052 mm and 5058 mm (198.9 to 199.1 inches) in length. Its width with folded mirrors is roughly 2047 mm (80.6 inches), expanding to 2209 mm (87 inches) with mirrors opened. The vehicle stands at a height of about 1870 mm (73.6 inches). These dimensions position the Range Rover V SWB as a large luxury SUV, providing a commanding road presence and spacious interior. This size balance also allows for enhanced maneuverability compared to longer variants while maintaining ample interior and cargo space.

The curb weight of the 2022 Land Rover Range Rover V SWB ranges between 2379 kg and 2735 kg (5248 to 6029 lbs), depending on specific configurations and optional equipment. Its maximum allowable weight ranges from 3400 kg to 3480 kg (7496 to 7671 lbs), which accounts for passengers, cargo, and additional load on top of the base weight. This weight capacity underlines the vehicle's robust construction and suitability for carrying multiple passengers and substantial cargo while maintaining optimal performance and safety.

With the rear seats in their upright position, the 2022 Land Rover Range Rover V SWB offers a generous luggage capacity ranging between 725 liters and 818 liters (25.6 to 28.9 cubic feet). When the rear seats are folded down, this capacity expands substantially to 1841 liters (64.9 cubic feet). This sizeable cargo space flexibility makes the vehicle highly practical for both everyday urban use and longer trips requiring ample storage, enabling users to accommodate large items or multiple pieces of luggage with ease.

The ride height or ground clearance of the 2022 Range Rover V SWB varies between 219 mm and 295 mm (8.6 to 11.6 inches), depending on suspension settings and terrain response configurations. This adjustable ground clearance allows the vehicle to handle a variety of difficult terrains with ease, from uneven trails to shallow water crossings, contributing to its renowned off-road prowess. The higher clearance settings also enhance obstacle traversal without risking undercarriage damage, while the lower settings improve on-road stability and aerodynamics for a smoother highway experience.

With the mirrors opened, the Range Rover V SWB measures approximately 2209 mm (87 inches) in width, which is wider than many standard home garages. Typical single-car garages are often around 2438 mm (96 inches) wide, so while the vehicle will fit, it leaves minimal clearance on either side. Drivers should exercise caution and may find it more comfortable to fold the mirrors to reduce the width to about 2047 mm (80.6 inches) when parking. Overall, the Range Rover V SWB can fit into most standard garages but with limited side clearance, so awareness during parking is advisable.

The 2022 Range Rover V SWB maintains a similar footprint to the later versions of its predecessor, keeping the length around 5050 mm (198.8 inches) and width roughly 2047 mm (80.6 inches) folded mirrors. However, advancements in design, aerodynamics, and interior packaging have allowed for a slightly increased interior space and more efficient use of cargo capacity. The current generation also benefits from modern suspension technology that slightly improves ground clearance and ride comfort. Overall, while external dimensions remain familiar, the new generation refines usability and luxury compared to its predecessor.

The 2022 Range Rover V SWB competes with other large luxury SUVs such as the Mercedes-Benz GLS, BMW X7, and Audi Q7. In terms of length, it generally matches or slightly exceeds these rivals, with its length near 5052-5058 mm (198.9-199.1 inches) compared to around 5200 mm (204.7 inches) for the GLS and about 5150 mm (202.8 inches) for the BMW X7. Its width with folded mirrors at 2047 mm (80.6 inches) is comparable, but when mirrors are opened to 2209 mm (87 inches), it is wider than many competitors. The Range Rover's ground clearance of up to 295 mm (11.6 inches) also surpasses many rivals, giving it a unique edge in off-road capability and road presence.

The 2022 Range Rover V SWB has a maximum roof load capacity of 100 kg (220 lbs). This rating means the roof can safely carry items such as roof racks, luggage boxes, bikes, or sports equipment without risking structural integrity or handling issues. This capacity enhances the vehicle's versatility for outdoor activities, long-distance travel, or when additional cargo space is required beyond the interior and trunk. Users should ensure roof accessories are compatible and evenly distribute the load to maintain vehicle stability and safety.

Thanks to its large dimensions, the Range Rover V SWB offers an exceptionally spacious and luxurious interior. The relatively long wheelbase and carefully optimized cabin layout provide generous legroom and headroom for all passengers, especially in the rear seats. The sizable luggage capacity—from 725 to 818 liters with seats up, extending up to 1841 liters with seats folded—supports a flexible lifestyle. The cabin is designed to combine luxury materials with practical technology and comfort features, ensuring that the space translates into a first-class passenger experience fitting for a premium SUV.

Indeed, the 2022 Range Rover V SWB presents a curb weight ranging from 2379 to 2735 kg (5248 to 6029 lbs), which can be somewhat heavier compared to some older generations of the Range Rover, which typically weighed around 2200 to 2600 kg (4850 to 5730 lbs). The increase in weight can be attributed to added luxury features, advanced safety systems, and the use of heavier performance components. However, improvements in chassis rigidity, materials, and engineering have balanced the weight increase with enhanced driving dynamics, comfort, and off-road capability, ensuring that the heft does not compromise the vehicle's overall performance.
