1998 Lamborghini Diablo Roadster Dimensions, Size & Specs

Production
Model Year:1998
Production Years:1996 - 1999 discontinued in 1999
1133 mm44.6 in3.7 ft
L: 4542 mm178.8 in14.9 ft | W: 2040 mm80.3 in6.7 ft
Length
4542 mm178.8 in14.9 ft
Width
2040 mm80.3 in6.7 ft
Height
1133 mm44.6 in3.7 ft
Trunk Capacity
150 liter5.3 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 1998 Lamborghini Diablo Roadster, engineered for optimal performance and comfort

Dimensions
Length:4542 mm178.8 in14.9 ft
Width:2040 mm80.3 in6.7 ft
Height:1133 mm44.6 in3.7 ft
Ground Clearance:140 mm5.5 in0.5 ft
Trunk Capacity:150 liter5.3 cu ft
Weight Specifications
Curb Weight:1625 kg3583 lbs
Maximal permitted Weight:1890 kg4167 lbs
Tire Specifications
Rims Sizes:13J x 17, 8.5J x 17
Tire Sizes:335/35 R17 (W:335 | H:35 | D:17)
235/40 R17 (W:235 | H:40 | D:17)
Useful Information

About 1998 Lamborghini Diablo Roadster

The 1998 Lamborghini Diablo Roadster is a striking example of Italian supercar engineering from the late 1990s, produced between 1996 and 1999. This roadster variant of the iconic Diablo model combines aggressive styling with remarkable performance, while retaining a focused yet usable cabin and usable cargo space. Measuring 4542 mm (approximately 179 inches) in length, 2040 mm (about 80.3 inches) in width, and standing 1133 mm (44.6 inches) tall, the Diablo Roadster exhibits the low-slung, wide stance typical of Lamborghini’s design philosophy. Its curb weight is 1625 kg (3579 lbs), with a maximum weight rating of 1890 kg (4167 lbs), underscoring a balance between lightweight construction and the structural reinforcements required for a convertible roadster layout. Ground clearance is set at a modest 140 mm (5.5 inches), highlighting the car’s focus on performance and handling over rough terrain clearance. The vehicle rides on distinctive rims sized 13J x 17 inches at the front and 8.5J x 17 inches at the rear, fitted with ultra-wide tires sized 335/35 R17 at the rear and 235/40 R17 at the front, offering exceptional grip and stability. Despite its performance-oriented nature, the Diablo Roadster manages to maintain a luggage capacity of 150 liters (about 5.3 cubic feet), sufficient for small trips or weekend gear. This blend of dramatic styling, compact roadster dimensions, and engineering finesse makes the Diablo Roadster a noteworthy car in Lamborghini’s lineage and a compelling candidate for enthusiasts seeking a high-performance open-top supercar experience.

Exceptional Features

1998 Lamborghini Diablo Roadster Highlights

Discover the standout features that make the 1998 Lamborghini Diablo Roadster a leader in its class

Engine

A powerful 5.7-liter V12 engine producing around 485 horsepower, delivering exceptional performance and a thrilling driving experience.

Body Style

Roadster design featuring a removable soft top, combining high-performance sports car dynamics with open-air driving enjoyment.

Transmission

A 5-speed manual transmission providing direct and engaging gear shifts to maximize driver control and performance.

Performance

Capable of accelerating from 0 to 60 mph in approximately 4.5 seconds, with a top speed exceeding 200 mph.

Suspension and Handling

Independent suspension with double wishbones at the front and rear, tuned for sharp handling and stability during high-speed cornering.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The 1998 Lamborghini Diablo Roadster features a length of 4542 mm (approximately 178.7 inches), a width of 2040 mm (about 80.3 inches), and a height of 1133 mm (roughly 44.6 inches). These dimensions contribute to its low-slung, aggressive stance typical of Lamborghini’s design philosophy, combining aerodynamic efficiency with a commanding road presence. Its wide body enhances stability at high speeds, while the relatively low height aids in reducing air resistance, improving overall performance and handling.

The curb weight of the 1998 Lamborghini Diablo Roadster is 1625 kg (about 3583 pounds), which refers to the weight of the vehicle without passengers or cargo but with all necessary fluids. The maximum permissible weight, which includes the vehicle itself plus passengers, cargo, and fuel, is 1890 kg (approximately 4167 pounds). The weight plays a crucial role in its performance, balancing power and handling for superior driving dynamics typical of high-performance roadsters.

The ride height or ground clearance of the 1998 Lamborghini Diablo Roadster is 140 mm (5.5 inches). This low ground clearance contributes to improved aerodynamics and stability at high speeds by lowering the car's center of gravity. However, such a low stance requires attention when navigating speed bumps, steep driveways, and uneven roads, as it increases the risk of scraping the underbody or front splitter on obstacles.

The Lamborghini Diablo Roadster is equipped with staggered tire and rim sizes that enhance its handling and traction. The front tires measure 235/40 R17 paired with rims sized 8.5J x 17, while the rear tires are wider at 335/35 R17 mounted on rims sized 13J x 17. This setup provides a significant contact patch at the rear for better grip during acceleration while maintaining responsive steering at the front, contributing to the supercar’s overall performance and road-holding capabilities.

The luggage capacity of the Lamborghini Diablo Roadster is limited to 150 liters (approximately 5.3 cubic feet), which is typical for supercars focused primarily on performance rather than utility. This space is suitable for a couple of small bags or personal items, reflecting the car’s emphasis on driving experience and style over practical cargo storage. Owners planning road trips will need to pack lightly or use additional luggage solutions to accommodate more gear.

Given the Diablo Roadster’s dimensions—4542 mm (178.7 inches) in length and 2040 mm (80.3 inches) in width—it generally fits into a standard residential garage, though with limited extra space. Most typical garages are around 2400 mm (8 feet) wide and 5400 mm (18 feet) deep, so while the car’s length and width fit with some clearance, the width may feel tight, especially if the garage door or access points are narrower than average. Careful parking is necessary to avoid damage to the vehicle or garage walls.

Compared to the predecessor Lamborghini Diablo coupe, the Diablo Roadster maintains very similar overall dimensions with a length of 4542 mm (178.7 inches) matching closely and a width of 2040 mm (80.3 inches) also consistent. Height remains low at 1133 mm (44.6 inches), preserving the Diablo’s signature aggressive profile. The Roadster’s curb weight is slightly higher due to structural reinforcements needed for the convertible design. Overall, the Roadster retains the coupe's imposing road presence while offering open-top driving without significant compromises in size.

When compared to similar late 1990s supercar roadsters like the Ferrari F355 Spider or Porsche 911 Turbo Cabriolet, the Lamborghini Diablo Roadster is notably wider and lower. For instance, the Diablo’s width of 2040 mm (80.3 inches) surpasses many competitors, emphasizing its broad, muscular stance, while its low height of 1133 mm (44.6 inches) enhances its aerodynamic profile. The length is roughly comparable, but the Diablo's aggressive dimensions reflect its priority on raw power and dramatic styling, setting it apart from its contemporaries that often favored slightly more restrained proportions.

The wide track of the Diablo Roadster, with a width of 2040 mm (80.3 inches), combined with its low height of 1133 mm (44.6 inches) and modest ride height of 140 mm (5.5 inches), creates a low center of gravity and excellent lateral stability. These characteristics contribute to sharp, responsive handling and strong cornering capabilities. The car’s weight distribution and aerodynamic shape also benefit from these dimensions, resulting in a dynamic driving experience typical for a Lamborghini supercar designed to perform well both in straight-line acceleration and on winding roads.

The Lamborghini Diablo Roadster was produced from 1996 to 1999. It was introduced as a convertible version of the standard Diablo to offer open-air driving while maintaining supercar performance and style. While exact production figures vary, the Roadster remains a rarer and more exclusive variant compared to the coupe, making it highly sought after by collectors and enthusiasts. Its limited production run reflects Lamborghini’s tradition of crafting distinctive, hand-built supercars with exceptional performance and dramatic design.
