2017 Kia Rio IV Hatchback (YB) Dimensions, Size & Specs

Production
Model Year:2017
Production Years:2017 - 2020 discontinued in 2020
1450 mm57.1 in4.8 ft
4065 mm160.0 in13.3 ft
1450 mm57.1 in4.8 ft
1990 mm78.3 in6.5 ft
1450 mm57.1 in4.8 ft
1990 mm78.3 in6.5 ft
1450 mm57.1 in4.8 ft
4065 mm160.0 in13.3 ft
1450 mm57.1 in4.8 ft
1990 mm78.3 in6.5 ft
1450 mm57.1 in4.8 ft
1990 mm78.3 in6.5 ft
Length
4065 mm160.0 in13.3 ft
Width
1990 mm78.3 in6.5 ft
Height
1450 mm57.1 in4.8 ft
Trunk Capacity
325 liter11.5 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2017 Kia Rio IV Hatchback, engineered for optimal performance and comfort

Dimensions
Length:4065 mm160.0 in13.3 ft
Width:1725 mm67.9 in5.7 ft
Width (Opened Mirrors):1990 mm78.3 in6.5 ft
Height:1450 mm57.1 in4.8 ft
Ground Clearance:135 mm5.3 in0.4 ft
Trunk Capacity:325 liter11.5 cu ft
Trunk Capacity (Max):980 - 1103 liter34.6 - 39.0 cu ft
Weight Specifications
Curb Weight:1110 - 1235 kg2447 - 2723 lbs
Maximal permitted Weight:1560 - 1680 kg3439 - 3704 lbs
Roof Load:70 kg154 lbs
Tire Specifications
Rims Sizes:15, 16, 17, 6.0J x 15, 6.0J x 16, 6.5J x 17
Tire Sizes:185/65 R15 (W:185 | H:65 | D:15)
195/55 R16 (W:195 | H:55 | D:16)
205/45 R17 (W:205 | H:45 | D:17)
185/65 R15 88H (W:185 | H:65 | D:15)
195/55 R16 87H (W:195 | H:55 | D:16)
205/45 R17 88V (W:205 | H:45 | D:17)
Useful Information

About 2017 Kia Rio IV Hatchback

The Kia Rio IV Hatchback (YB), produced from 2017 to 2020, is a well-balanced compact hatchback that offers a practical size suited for urban and suburban driving. Measuring 4065 mm (159.8 inches) in length and 1725 mm (67.9 inches) in width, the Rio IV balances maneuverability with a comfortable cabin space. When the exterior mirrors are opened, the width expands to 1990 mm (78.3 inches). Its height stands at 1450 mm (57.1 inches), providing a slightly elevated driving position compared to smaller hatchbacks, while maintaining a low profile that supports good aerodynamics. The vehicle's curb weight ranges from 1110 to 1235 kg (2447 to 2722 lbs), contributing to its nimble handling and fuel efficiency, with a maximum weight between 1560 and 1680 kg (3439 to 3704 lbs), accommodating passengers and cargo comfortably.

One of the Kia Rio IV’s notable features is its luggage capacity. With all seats in place, it offers 325 liters (11.5 cubic feet) of cargo space, which expands significantly when the rear seats are folded down, ranging from 980 to 1103 liters (34.6 to 38.9 cubic feet). This flexibility makes it a practical choice for daily commuting as well as weekend trips that require extra storage. The roof load capacity of 70 kg (154 lbs) also allows for additional cargo options such as roof racks.

In terms of ride height and ground clearance, the Rio IV provides 135 mm (5.3 inches), striking a balance between comfort and the ability to handle mild road obstacles. This clearance is suitable for city roads and light off-road conditions without compromising stability.

The hatchback rolls on a variety of rim sizes including 15-, 16-, and 17-inch wheels with widths such as 6.0J x 15, 6.0J x 16, and 6.5J x 17. The compatible tire sizes for this generation offer flexibility depending on preferences for performance or comfort and include 185/65 R15, 195/55 R16, and 205/45 R17 variants in H and V speed ratings.

Overall, the Kia Rio IV Hatchback from 2017 to 2020 presents itself as a compact yet spacious hatchback option with versatile cargo space, accessible driving dynamics, and adaptable wheel and tire options. Its dimensions and weight profile cater well to drivers looking for a practical economy car without sacrificing interior room and functionality.

Exceptional Features

2017 Kia Rio IV Hatchback Highlights

Discover the standout features that make the 2017 Kia Rio IV Hatchback a leader in its class

Engine and Performance

The 2017 Kia Rio IV Hatchback (YB) is equipped with a 1.4-liter inline-4 engine producing around 100 horsepower, paired with either a six-speed manual or a six-speed automatic transmission, offering a balance of fuel efficiency and urban drivability.

Fuel Efficiency

The vehicle boasts impressive fuel economy, with EPA estimates typically around 28-33 miles per gallon in the city and 37-41 mpg on the highway, making it an economical choice for daily commuting.

Interior and Comfort

The Rio IV Hatchback features a comfortable and well-designed cabin with seating for five, supportive seats, and quality materials for the segment, along with standard air conditioning and available touchscreen infotainment.

Technology and Infotainment

It offers modern tech features including a 7-inch touchscreen display with Apple CarPlay and Android Auto compatibility, Bluetooth connectivity, USB ports, and available navigation, enhancing driver convenience and connectivity.

Safety Features

Safety is enhanced by standard features such as multiple airbags, Anti-lock Braking System (ABS), Electronic Stability Control (ESC), and available options like a rearview camera and advanced driver assistance systems.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Kia Rio IV Hatchback (YB), produced from 2017 to 2020, measures 4065 mm (159.8 inches) in length, 1725 mm (67.9 inches) in width without mirrors, and 1450 mm (57.1 inches) in height. When considering the width with mirrors opened, the size increases to 1990 mm (78.3 inches). These dimensions place the Rio IV firmly within the compact hatchback segment, offering a balanced footprint that supports urban maneuverability and practicality.

With the side mirrors folded in, the Kia Rio IV Hatchback is 1725 mm (67.9 inches) wide, making it quite easy to navigate narrow streets and urban parking spots. When the mirrors are opened for driving, the width extends to 1990 mm (78.3 inches). This increased width is typical for modern hatchbacks to ensure better visibility and safety but should be considered when parking or driving through tight spaces.

The Kia Rio IV Hatchback features a ground clearance of 135 mm (5.3 inches). This modest ride height provides adequate clearance for typical urban and suburban roads, including minor bumps and potholes. However, it may be less suited for rough terrain or unpaved roads, where higher clearance would be advantageous. The lower ground clearance complements the vehicle's sporty aesthetic and improves stability and handling by lowering the center of gravity.

The Kia Rio IV Hatchback offers a practical luggage capacity of 325 liters (11.5 cubic feet) when the rear seats are upright, which is suitable for everyday groceries or small luggage. When the rear seats are folded down, this capacity significantly increases to between 980 liters and 1103 liters (34.6 to 38.9 cubic feet), providing considerable space for larger cargo or bulky items. This flexibility makes the Rio IV user-friendly for both daily commuting and weekend getaways.

The Kia Rio IV Hatchback has a curb weight ranging from 1110 kg to 1235 kg (approximately 2447 to 2722 pounds), depending on the trim and engine options. This weight reflects the vehicle's compact and lightweight design, which contributes to fuel efficiency and nimble handling. The maximum allowed weight (gross vehicle weight rating) ranges between 1560 kg and 1680 kg (3440 to 3704 pounds), indicating the total vehicle capacity, including passengers, cargo, and fuel. Staying within these weight limits is essential for safe operation and optimal performance.

The Kia Rio IV Hatchback offers several rim sizes to suit different preferences and driving needs, including 15, 16, and 17-inch wheels. The corresponding rim widths are 6.0J x 15, 6.0J x 16, and 6.5J x 17. Tire size options include 185/65 R15, 195/55 R16, and 205/45 R17. These tire and rim configurations balance ride comfort, handling precision, and aesthetics, allowing customers to tailor the vehicle's performance and look.

Yes, the Kia Rio IV Hatchback comfortably fits into a standard garage. Its length of 4065 mm (159.8 inches) and width of 1725 mm (67.9 inches) without mirrors allow for easy parking in typical residential garages, which often are around 2400 to 3000 mm wide and 4800 to 6000 mm long. However, with mirrors folded out (1990 mm / 78.3 inches width), extra caution might be required when maneuvering tightly spaced garages or parking areas to avoid scratching the mirrors.

Compared to its predecessor, the Kia Rio III Hatchback, the Rio IV (YB) presents some dimensional refinements. The Rio IV is slightly larger, with its length measuring 4065 mm (159.8 inches) compared to around 4055 mm (159.6 inches) for the previous generation. It also offers increased width and height, which translates into more interior space and comfort. These incremental increases enhance passenger comfort and cargo capacity while maintaining the vehicle's compact character for urban driving.

The Kia Rio IV Hatchback's dimensions are competitive within the subcompact hatchback class. Its 4065 mm (159.8 inch) length and 1725 mm (67.9 inch) width are similar to rivals like the Hyundai i20, Ford Fiesta, and Volkswagen Polo. While some competitors might be marginally longer or wider, the Rio IV balances size and agility, providing ample space inside without compromising maneuverability in city environments. Its flexible luggage space of up to 1103 liters stands out for versatility against peers.

The Kia Rio IV Hatchback (YB) produced between 2017 and 2020 is appreciated for its refined styling, improved cabin quality, and efficient performance. It features modern technology, comfortable seating, and a practicality-enhancing hatchback layout. Engine options and trims vary, but the model is known for its reliability and affordability in the subcompact segment. Its lightweight design contributes to fuel economy, while the various tire and rim options allow drivers to choose between sportier or comfort-oriented driving experiences.
