2024 Kia EV9 Dimensions, Size & Specs

Production
Model Year:2024
Production Years:2023 - present in production since 2023
1755 mm69.1 in5.8 ft
5009 - 5015 mm197.2 - 197.4 in16.4 - 16.5 ft
1755 mm69.1 in5.8 ft
2263 mm89.1 in7.4 ft
1755 mm69.1 in5.8 ft
2263 mm89.1 in7.4 ft
1755 mm69.1 in5.8 ft
5009 - 5015 mm197.2 - 197.4 in16.4 - 16.5 ft
1755 mm69.1 in5.8 ft
2263 mm89.1 in7.4 ft
1755 mm69.1 in5.8 ft
2263 mm89.1 in7.4 ft
Length
5009 - 5015 mm197.2 - 197.4 in16.4 - 16.5 ft
Width
2263 mm89.1 in7.4 ft
Height
1755 mm69.1 in5.8 ft
Trunk Capacity
333 - 572 liter11.8 - 20.2 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2024 Kia EV9, engineered for optimal performance and comfort

Dimensions
Length:5009 - 5015 mm197.2 - 197.4 in16.4 - 16.5 ft
Width:1980 mm78.0 in6.5 ft
Width (Folded Mirrors):2047 mm80.6 in6.7 ft
Width (Opened Mirrors):2263 mm89.1 in7.4 ft
Height:1755 mm69.1 in5.8 ft
Ground Clearance:177 - 198 mm7.0 - 7.8 in0.6 - 0.6 ft
Trunk Capacity:333 - 572 liter11.8 - 20.2 cu ft
Trunk Capacity (Max):2313 - 2393 liter81.7 - 84.5 cu ft
Weight Specifications
Curb Weight:2310 - 2589 kg5093 - 5708 lbs
Maximal permitted Weight:2910 - 3240 kg6415 - 7143 lbs
Roof Load:70 kg154 lbs
Tire Specifications
Rims Sizes:19, 20, 21, 9J x 21 ET58.5
Tire Size:285/45 R21 113V (W:285 | H:45 | D:21)
Useful Information

About 2024 Kia EV9

The 2024 Kia EV9 is a midsize electric SUV that combines bold design with practicality and advanced electric vehicle technology. Produced from 2023 to the present, the EV9 offers a substantial presence on the road with a length ranging between 5009 mm and 5015 mm (197.3 - 197.6 inches), a width from 1979 mm to 1980 mm (77.9 - 78.0 inches) excluding mirrors, and a height between 1750 mm and 1755 mm (68.9 - 69.1 inches). When the mirrors are folded, the width measures a more compact 2047 mm (80.6 inches), extending to 2263 mm (89.1 inches) with mirrors opened, accommodating optimal visibility.

Weighing between 2310 kg and 2589 kg (5095 - 5708 lbs) curb weight, the EV9 supports a maximum weight capacity ranging from 2910 kg to 3240 kg (6417 - 7146 lbs), highlighting its robust build and capability. This electric SUV supports a roof load of up to 70 kg (154 lbs), providing additional utility options. The EV9’s ride height or ground clearance varies from 177 mm to 198 mm (approximately 7.0 - 7.8 inches), ensuring confident driving over various terrains and conditions.

Passenger and cargo space is versatile, with a luggage capacity starting at 333 liters (11.8 cubic feet) behind the rear seats, expandable to a generous 572 liters (20.2 cubic feet). Folding the rear seats further increases cargo space dramatically to between 2313 liters and 2393 liters (81.7 - 84.5 cubic feet), making it highly practical for families and long trips. The Kia EV9 rides on sizable rims available in 19, 20, and 21 inches, featuring tire sizes of 285/45 R21 113V, providing a balanced ride with enhanced grip and stability.

Overall, the 2024 Kia EV9's combination of electric powertrain efficiency, spacious dimensions, and versatile cargo capacity makes it an excellent option for eco-conscious buyers seeking a stylish and spacious SUV with modern features. Its impressive size and functionality place it competitively in the growing electric SUV segment, appealing to customers valuing both innovation and practicality.

Exceptional Features

2024 Kia EV9 Highlights

Discover the standout features that make the 2024 Kia EV9 a leader in its class

Electric Powertrain

The 2024 Kia EV9 is equipped with a fully electric powertrain, offering a robust range of up to approximately 300 miles on a single charge, depending on the configuration.

Spacious Three-Row Seating

Designed as a large SUV, the EV9 provides comfortable three-row seating accommodating up to seven passengers, with ample cargo space for families and adventures.

Advanced Infotainment System

Features a dual 12.3-inch curved display setup that integrates the digital instrument cluster and infotainment system, providing a seamless user experience with connectivity options.

Fast Charging Capability

Supports ultra-fast DC fast charging, allowing the battery to be charged from 10% to 80% in approximately 30 minutes, facilitating convenient long-distance travel.

Comprehensive Safety and Driver Assistance

Equipped with Kia’s Drive Wise suite, including features such as adaptive cruise control, lane keeping assist, blind-spot monitoring, and highway driving assist to enhance safety.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The 2024 Kia EV9 measures between 5009 mm and 5015 mm in length. In imperial units, this converts to approximately 197.2 to 197.4 inches, or about 16 feet 5 inches. This length positions the EV9 as a sizable SUV catering to consumers looking for a spacious electric vehicle with ample cabin and cargo space, offering a balanced footprint for maneuverability and interior volume.

The Kia EV9 has a body width ranging from 1979 mm to 1980 mm (approximately 77.9 to 77.95 inches, or about 6 feet 6 inches). When accounting for the mirrors, the width varies between 2047 mm (80.6 inches or 6 feet 8.6 inches) with folded mirrors and 2263 mm (89.1 inches or 7 feet 5.1 inches) with mirrors fully extended. These dimensions are crucial to consider when parking or selecting a garage space, as the vehicle is notably wider with mirrors extended, requiring clearance of at least 2.3 meters (7.5 feet) for safe and comfortable parking.

The height of the Kia EV9 ranges from 1750 mm to 1755 mm, which is about 68.9 to 69 inches, or roughly 5 feet 9 inches. This moderate height for an SUV ensures the EV9 can fit comfortably in most residential garages, which typically have a clearance around 2 meters (6 feet 7 inches) or more. It's also low enough to pass under most urban overpasses and parking structures, making it practical for everyday city and suburban use.

Yes, the Kia EV9 generally fits into a standard garage. With a length of about 5 meters (16.4 feet), width with folded mirrors around 2.05 meters (6.7 feet), and a height just under 1.76 meters (5.8 feet), it fits comfortably within the typical residential garage dimensions, which are often around 6 meters long by 3 meters wide and about 2.1 meters high. However, caution is advised if garage space is particularly tight, especially considering mirror width when opened is over 2.25 meters (7.4 feet), so mirrors should be folded for easy clearance.

The Kia EV9 has a curb weight between 2310 kg and 2589 kg (about 5,093 to 5,709 lbs), with a maximum weight capacity ranging from 2910 kg to 3240 kg (approximately 6,413 to 7,143 lbs). These weight figures are typical for a large electric SUV equipped with substantial battery packs and advanced hardware. The higher curb weight contributes to stability on the road and a solid ride feel but may influence acceleration and braking performance slightly compared to lighter vehicles. The weight also impacts energy consumption and driving range, but electric powertrains optimize this with strong torque and regenerative braking systems.

The Kia EV9 offers versatile cargo space to meet different needs. With the rear seats in position, it provides between 333 and 572 liters of luggage capacity (approximately 11.8 to 20.2 cubic feet). When the rear seats are folded down, the cargo volume expands significantly to between 2313 and 2393 liters (roughly 81.7 to 84.5 cubic feet). This substantial flexibility makes the EV9 highly practical for families, road trips, or transporting bulky items, ensuring ample space.

The Kia EV9 offers a ground clearance between 177 mm and 198 mm (about 6.97 to 7.8 inches). This relatively high clearance for an electric SUV provides the EV9 with enhanced capability to handle uneven roads, light off-road conditions, and urban obstacles like speed bumps. The elevated ride height contributes to better driver visibility and a commanding road presence, aligning with consumer expectations for SUVs, while maintaining enough profile to ensure easy ingress and egress.

The Kia EV9 comes equipped with various wheel options, including rims sized 19, 20, or 21 inches, with a specified 9J x 21 ET58.5 rim size for some models. Tires mounted are sized 285/45 R21 113V, offering a wide and sporty footprint. This wheel and tire combination promotes stability and grip, which are essential for a large electric SUV carrying significant weight, ensuring handling that complements the vehicle’s size and performance characteristics.

The 2024 Kia EV9, as a new generation model, is larger and more spacious compared to earlier electric SUVs from Kia, such as the Kia EV6, which is a midsize crossover. The EV9 is designed as a full-size SUV with significantly greater length (over 5 meters compared to the EV6’s 4.68 meters) and a higher seating capacity, emphasizing family utility and cargo capacity. Compared to competitors in the large electric SUV segment, the EV9 holds its own with competitive dimensions, modern tech features, and a balanced combination of interior space and exterior design, making it a strong contender for buyers seeking a large electric SUV experience.

The 2024 Kia EV9 represents Kia’s commitment to electrification and advanced mobility solutions in the SUV segment. Key highlights include its bold, boxy exterior design that maximizes interior space and presence, alongside a minimalist and tech-focused interior. Features notably include a fully digital cockpit, advanced driver assistance systems, and a high-capacity battery offering impressive electric range and fast-charging capability. Its flexible seating and notable luggage capacity speak to family-friendly practicality, while sustainable materials underline Kia’s focus on eco-conscious design.
