2021 Hyundai Tucson IV Dimensions, Size & Specs

The curb weight of the Hyundai Tucson IV varies between 1425 kg (3141 lbs) and 1818 kg (4008 lbs), depending on the specific trim level, engine option, and equipment. A lighter curb weight version generally offers better fuel efficiency and agility, resulting in more responsive handling and a more dynamic driving experience. Conversely, the heavier versions, often featuring more luxury or technology options, may prioritize comfort, safety features, and equipment over outright performance. Maintaining a good balance between weight and functionality, Tucson IV achieves a combination of efficient fuel consumption while ensuring stable handling characteristic of a compact SUV.

The Hyundai Tucson IV has a ride height/ground clearance ranging from 170 mm to 211 mm (6.7 to 8.3 inches), allowing it to handle a variety of terrains and road conditions with confidence. The higher ground clearance improves its capability when driving on uneven roads or mild off-road trails, reducing the risk of undercarriage damage. Meanwhile, it maintains stability and a lower center of gravity for comfortable on-road driving. This ground clearance range caters well to urban drivers who occasionally venture onto rougher road surfaces or snowy conditions, balancing practicality and versatility.

The Hyundai Tucson IV offers flexible cargo space that caters to differing luggage needs. With the rear seats upright, the luggage compartment provides between 539 liters (19 cubic feet) and 1096 liters (38.7 cubic feet) of storage volume, depending on the specific configuration and model variant. When the rear seats are folded down, the cargo capacity expands significantly, ranging from 1721 liters (60.7 cubic feet) to 2090 liters (73.8 cubic feet). This vast range allows for the convenient transport of larger items, making the Tucson IV practical for family trips, shopping, and outdoor activities, providing both flexibility and ample storage.

The Hyundai Tucson IV has a body width of approximately 1864 to 1865 mm (73.4 inches) without the mirrors. Including the mirrors when opened, the total width extends to 2130 mm (83.9 inches). This larger width with mirrors considered is important when parking or maneuvering in tight spaces, as the mirrors add a notable extra width that must be accounted for to avoid collisions with nearby vehicles or obstacles. While the Tucson’s width is typical for a compact SUV, drivers should be mindful when parking in narrow urban garages or tight spots due to the added mirror width.

The Hyundai Tucson IV generally fits within a standard residential garage, but it is important to consider the garage dimensions to be sure. Most traditional single-car garages have interior widths of roughly 2.4 to 2.7 meters (7.9 to 8.9 feet) and lengths of about 4.8 to 6 meters (15.7 to 19.7 feet). With a vehicle width of about 1865 mm (73.4 inches) and a maximum length of 4630 mm (182.3 inches), the Tucson IV fits comfortably lengthwise in most garages. However, drivers must be cautious about the extra width with mirrors open (2130 mm or 83.9 inches). Closing the mirrors or having a wider garage space solves this. The Tucson IV’s height up to 1666 mm (65.6 inches) also fits under typical garage door heights without trouble.

Compared to the Hyundai Tucson III, the fourth generation Tucson IV generally features a slight increase in exterior dimensions, contributing to an improved interior space and a more modern, aggressive stance. The length range of the Tucson IV (4500-4630 mm) is moderately longer than the Tucson III, which measured around 4480 mm in length. Width and height have also seen modest increases, giving the newer generation a broader and taller profile. These dimension enhancements provide both aesthetic improvements and substantial benefits inside the cabin, including increased passenger comfort and cargo capacity. The overall design language became sharper and more dynamic with the Tucson IV, improving aerodynamics and road presence compared to the third generation.

When compared to popular competitors such as the Toyota RAV4 and Honda CR-V, the Hyundai Tucson IV holds its own in the compact SUV segment with competitive dimensions. The Tucson IV’s length varies between 4500 mm and 4630 mm (177-182 inches), which is closely matched or slightly shorter than the Toyota RAV4 (approximately 4600 mm or 181 inches) and similar to the Honda CR-V (about 4630 mm or 182 inches). Width-wise, Tucson’s 1865 mm (73.4 inches) body is on par with these rivals, although the RAV4 can be slightly wider. Height at approximately 1666 mm (65.6 inches) also aligns well, contributing to a generous cabin volume and excellent road visibility. Overall, the Tucson IV’s size provides balance, allowing agility in urban settings while offering ample passenger and cargo space similar to its key rivals.

The Hyundai Tucson IV offers a range of factory rim sizes including 17-, 18-, and 19-inch wheels, with rim widths between 7.0J and 7.5J depending on the variant. Corresponding tire sizes include 215/65 R17, 235/55 R18, 235/50 R19, 235/65 R17 104H, 235/55 R19 101H, and 235/60 R18 103H. Larger rims (19 inches) paired with lower-profile tires tend to provide improved handling and a sportier ride feel due to reduced sidewall flex, enhancing road grip and steering responsiveness. Smaller rims with taller sidewall tires (17 inches) offer a more comfortable ride by better absorbing road imperfections. This variety allows buyers to balance ride comfort, aesthetics, and performance characteristics to suit their preferences.

The Hyundai Tucson IV has a rated roof load capacity of 100 kg (approximately 220 lbs). This figure represents the maximum weight that can be safely placed on the vehicle’s roof, typically including roof racks, cargo boxes, or sporting equipment such as bikes or skis. It is important not to exceed this limit to maintain vehicle stability, handling, and safety. A strong and well-maintained roof rack system designed for such loads will help distribute weight evenly while preventing damage to the vehicle. For drivers who frequently transport large or heavy items on the roof, abiding by this weight limit is crucial to preserving performance and safety.
