2010 Hyundai ix35 Dimensions, Size & Specs

Production
Model Year:2010
Production Years:2009 - 2013 discontinued in 2013
1660 mm65.4 in5.4 ft
L: 4410 mm173.6 in14.5 ft | W: 1820 mm71.7 in6.0 ft
Length
4410 mm173.6 in14.5 ft
Width
1820 mm71.7 in6.0 ft
Height
1660 mm65.4 in5.4 ft
Trunk Capacity
591 liter20.9 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2010 Hyundai ix35, engineered for optimal performance and comfort

Dimensions
Length:4410 mm173.6 in14.5 ft
Width:1820 mm71.7 in6.0 ft
Height:1660 mm65.4 in5.4 ft
Ground Clearance:170 mm6.7 in0.6 ft
Trunk Capacity:591 liter20.9 cu ft
Trunk Capacity (Max):1436 liter50.7 cu ft
Weight Specifications
Curb Weight:1305 - 1601 kg2877 - 3530 lbs
Maximal permitted Weight:1830 - 2140 kg4034 - 4718 lbs
Roof Load:100 kg220 lbs
Tire Specifications
Rims Sizes:6.5J x 16, 6.5J x 17, 6.5J x 18, 6.5J x18
Tire Sizes:215/70 R16 (W:215 | H:70 | D:16)
225/60 R17 (W:225 | H:60 | D:17)
225/55 R18 (W:225 | H:55 | D:18)
Useful Information

About 2010 Hyundai ix35

The 2010 Hyundai ix35 is a compact SUV produced between 2009 and 2013, well-suited for families and urban drivers seeking practicality and style. It measures 4410 mm (173.6 inches) in length, 1820 mm (71.7 inches) in width, and stands between 1655 mm to 1660 mm (65.2 to 65.4 inches) in height. This size offers a balanced footprint that combines spacious interior comfort with maneuverability ideal for city and light off-road driving. The ix35's ground clearance is 170 mm (6.7 inches), providing decent capability over uneven terrain while maintaining ease of entry and exit.

Curb weight varies from 1305 to 1601 kg (2878 to 3530 lbs), depending on the trim and optional equipment, while the maximum allowable weight ranges between 1830 and 2140 kg (4037 to 4717 lbs). These weight specifications contribute to a solid, stable driving experience without sacrificing fuel efficiency. The SUV rides on rims sized from 16 to 18 inches, with matching tire sizes that include 215/70 R16, 225/60 R17, and 225/55 R18, enhancing grip and ride comfort across different road surfaces.

In terms of cargo space, the Hyundai ix35 offers a generous luggage capacity of 591 liters (20.9 cubic feet) with rear seats up, expanding impressively to 1436 liters (50.7 cubic feet) when the rear seats are folded down. This makes it highly versatile for transporting gear, luggage, or larger items, catering well to outdoor activities or family outings. The roof can accommodate a load of up to 100 kg (220 lbs), allowing for roof racks and additional cargo.

Overall, the 2010 Hyundai ix35 combines smart dimensions and thoughtful design to deliver a versatile and practical SUV option in its segment. Its external size and interior flexibility make it well-rounded for everyday use as well as weekend adventures.

Exceptional Features

2010 Hyundai ix35 Highlights

Discover the standout features that make the 2010 Hyundai ix35 a leader in its class

Engine Options

The 2010 Hyundai ix35 offers a range of efficient and reliable engines, including a 2.0-liter petrol engine and a 2.0-liter turbo diesel engine, providing a balance of power and fuel economy.

Exterior Design

Modern and sleek styling with a bold front grille, dynamic headlamps, and a sporty silhouette, making the ix35 visually appealing and aerodynamic.

Interior Comfort

Spacious cabin with quality materials, ergonomic dashboard layout, adjustable seats, and ample legroom ensuring comfort for both driver and passengers.

Safety Features

Equipped with multiple airbags, ABS with EBD, electronic stability control, and a reinforced body structure to enhance occupant safety.

Technology and Convenience

Includes features such as touchscreen infotainment system, Bluetooth connectivity, steering wheel-mounted controls, and climate control for an enhanced driving experience.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Hyundai ix35 from the 2010 model year measures 4410 mm (173.6 inches) in length, 1820 mm (71.7 inches) in width, and between 1655 mm (65.2 inches) to 1660 mm (65.4 inches) in height. These dimensions place the ix35 firmly in the compact SUV category, offering a good balance between interior space and manageable exterior size for urban driving and parking.

The curb weight of the Hyundai ix35 2010 model ranges from 1305 kg (2878 lbs) to 1601 kg (3530 lbs), depending on the trim and equipment level. The vehicle’s maximum permissible weight, which includes passengers, cargo, and fuel, ranges between 1830 kg (4037 lbs) and 2140 kg (4717 lbs). These weight ranges impact fuel efficiency and handling while reflecting the solid build typical of SUVs in its class.

The Hyundai ix35 provides a practical luggage capacity of 591 liters (20.9 cubic feet) with the rear seats in their upright position. When more cargo space is needed, folding down the rear seats expands the luggage capacity significantly to 1436 liters (50.7 cubic feet). This flexibility makes the ix35 suitable for both everyday commuting and larger haul needs such as family trips or moving bulky items.

The roof load capacity of the Hyundai ix35 is rated at 100 kg (220 lbs), allowing for additional cargo storage options such as roof boxes or bike racks. The ground clearance, a crucial factor for an SUV’s off-road ability and urban versatility, stands at 170 mm (6.7 inches). This height supports moderate off-road driving and provides good clearance over urban obstacles like speed bumps and uneven surfaces.

The Hyundai ix35 2010 offers a variety of rim sizes including 6.5J x 16, 6.5J x 17, and 6.5J x 18 inches. Corresponding tire sizes include 215/70 R16, 225/60 R17, and 225/55 R18. These options allow owners to choose between different wheel and tire combinations, balancing ride comfort, handling, and aesthetics according to personal preference and driving conditions.

Yes, the Hyundai ix35 (2010) fits comfortably into a standard residential garage. A typical single-car garage door height is around 2.1 to 2.4 meters (82.7 to 94.5 inches), and the ix35’s height ranges from 1655 mm (65.2 inches) to 1660 mm (65.4 inches), which leaves ample clearance. Its width of 1820 mm (71.7 inches) also suits standard garage widths, allowing easy parking with room to open doors and move around.

Compared to its predecessor, the Hyundai Tucson (produced 2004-2009), the 2010 Hyundai ix35 is slightly larger in several key dimensions, reflecting a modernized, more spacious approach. The ix35’s length of 4410 mm (173.6 inches) is longer than the Tucson’s approximately 4385 mm (172.6 inches). Width increased to 1820 mm (71.7 inches) versus the Tucson’s roughly 1805 mm (71.1 inches). Height remains similar, but the ix35 generally offers more interior and cargo space, along with updated styling and technology improvements.

The Hyundai ix35 sits competitively in the compact SUV segment regarding size. Its length of 4410 mm (173.6 inches) and width of 1820 mm (71.7 inches) place it close to rivals like the Nissan Qashqai and Ford Kuga of the same era, which typically measure between 4300 mm to 4500 mm in length and 1780 mm to 1850 mm in width. Its good ground clearance of 170 mm (6.7 inches) and flexible cargo capacity make it a practical choice that balances interior space, drivability, and utility.

The Hyundai ix35 boasts a well-designed interior with passenger comfort and cargo versatility in mind. The 591-liter (20.9 cubic feet) luggage space with rear seats upright is considerable for daily use, while a flat-folding rear seat system expands the load area to 1436 liters (50.7 cubic feet), offering flexibility for larger items or travel gear. These attributes, combined with a comfortable cabin height and seating dimensions, enhance its appeal as a family-friendly compact SUV.

The curb weight of the Hyundai ix35 varies from 1305 kg (2878 lbs) to 1601 kg (3530 lbs) depending on the configuration and engine options. A higher curb weight typically corresponds with more equipment and a larger engine, which improves safety and refinement but can slightly reduce fuel economy and agility. The ix35’s weight ensures a stable and planted feel on the road, offering confident handling combined with the composure expected from a compact SUV.
