2017 Honda CR-V V Dimensions, Size & Specs

Production
Model Year:2017
Production Years:2017 - 2019 discontinued in 2019
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
4586 - 4603 mm180.6 - 181.2 in15.0 - 15.1 ft
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
4586 - 4603 mm180.6 - 181.2 in15.0 - 15.1 ft
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
2117 mm83.3 in6.9 ft
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
2117 mm83.3 in6.9 ft
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
4586 - 4603 mm180.6 - 181.2 in15.0 - 15.1 ft
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
2117 mm83.3 in6.9 ft
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
2117 mm83.3 in6.9 ft
Length
4586 - 4603 mm180.6 - 181.2 in15.0 - 15.1 ft
Width
2117 mm83.3 in6.9 ft
Height
1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
Trunk Capacity
150 - 1110 liter5.3 - 39.2 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2017 Honda CR-V V, engineered for optimal performance and comfort

Dimensions
Length:4586 - 4603 mm180.6 - 181.2 in15.0 - 15.1 ft
Width:1855 mm73.0 in6.1 ft
Width (Folded Mirrors):1932 mm76.1 in6.3 ft
Width (Opened Mirrors):2117 mm83.3 in6.9 ft
Height:1679 - 1689 mm66.1 - 66.5 in5.5 - 5.5 ft
Ground Clearance:155 - 208 mm6.1 - 8.2 in0.5 - 0.7 ft
Trunk Capacity:150 - 1110 liter5.3 - 39.2 cu ft
Trunk Capacity (Max):936 - 2146 liter33.1 - 75.8 cu ft
Weight Specifications
Curb Weight:1500 - 1728 kg3307 - 3810 lbs
Maximal permitted Weight:2130 - 2350 kg4696 - 5181 lbs
Roof Load:75 kg165 lbs
Tire Specifications
Rims Sizes:17, 18, 19, 7.5J x 18
Tire Sizes:235/65 R17 (W:235 | H:65 | D:17)
235/60 R18 (W:235 | H:60 | D:18)
225/65 R17 (W:225 | H:65 | D:17)
225/60 R18 (W:225 | H:60 | D:18)
Useful Information

About 2017 Honda CR-V V

The Honda CR-V V, produced from 2017 to 2019, is a well-balanced SUV known for its versatile size and practical dimensions. This generation offers a length ranging between 4586 mm and 4603 mm (approximately 180.6 to 181.3 inches), fitting comfortably within the compact SUV segment yet providing ample interior space. Its width varies slightly from 1854 mm to 1855 mm (73.0 to 73.1 inches), with the vehicle becoming wider when including mirrors: 1932 mm (76.0 inches) when folded and 2117 mm (83.3 inches) with mirrors opened, which is a key consideration for parking and urban driving. The height of the CR-V V ranges from 1679 mm to 1689 mm (66.1 to 66.5 inches), offering a commanding view of the road without being overly tall.

Weighing between 1500 kg and 1728 kg (3307 to 3810 lbs), this SUV maintains a balance between sturdiness and fuel efficiency. Maximum weight capacity spans from 2130 kg to 2350 kg (4695 to 5181 lbs), allowing adequate load for passengers and cargo combined. The luggage capacity ranges from a modest 150 liters (5.3 cubic feet) with all seats in use to an expansive 1110 liters (39.2 cubic feet), which can be further expanded to between 936 and 2146 liters (33.0 to 75.7 cubic feet) when rear seats are folded – ideal for transporting bulky items or gear. The roof load is rated at 75 kg (165 lbs), supporting additional storage options like roof racks.

Ground clearance or ride height varies from 155 mm to 208 mm (6.1 to 8.2 inches), enhancing both on-road comfort and mild off-road capability. The CR-V V typically rides on 17 to 19-inch rims, with sizes including 17-inch, 18-inch, and 19-inch wheels sized at 7.5J x 18. Tires vary between 225/60 R18, 235/60 R18, 225/65 R17, and 235/65 R17, contributing to a stable ride and good grip under various conditions.

Overall, the 2017-2019 Honda CR-V V balances compact design with spacious interiors and versatile cargo capabilities, making it a preferred choice for families and drivers seeking reliable, efficient, and roomy SUVs in the mid-size segment.

Exceptional Features

2017 Honda CR-V V Highlights

Discover the standout features that make the 2017 Honda CR-V V a leader in its class

Engine and Performance

The 2017 Honda CR-V V is powered by a 2.4-liter inline-4 engine producing around 184 horsepower, paired with a continuously variable transmission (CVT) for smooth and efficient driving.

All-Wheel Drive Capability

This model offers Real Time AWD with Intelligent Control System, providing enhanced traction and stability in various driving conditions.

Spacious Interior and Comfort

The CR-V V features a roomy cabin with high-quality materials, comfortable seating for five, and versatile cargo space with a 60/40 split-folding rear seat.

Advanced Safety Features

Equipped with multiple airbags, anti-lock braking system (ABS), vehicle stability assist (VSA), and Honda's multi-angle rearview camera for improved safety.

Infotainment and Connectivity

Includes a 7-inch display audio system with smartphone integration, Bluetooth connectivity, USB ports, and available navigation for convenient and connected driving.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Honda CR-V V produced between 2017 and 2019 has an overall length ranging between 4586 mm to 4603 mm (approximately 180.6 to 181.2 inches). This length provides a balanced size for an SUV, offering ample interior space without becoming too cumbersome for city driving. The relatively moderate length makes the CR-V manageable in tight parking spots and urban environments while still accommodating passengers and cargo comfortably. Its slightly varied length between different trims or configurations can be due to design elements like bumpers or added features. Overall, the size ensures good maneuverability while maintaining utility.

The Honda CR-V V's width ranges from 1854 mm to 1855 mm (about 73.0 inches) excluding mirrors. With the mirrors folded, the width expands to 1932 mm (approximately 76.1 inches), and with mirrors opened, it reaches 2117 mm (around 83.3 inches). The variance in width is important for navigating tight parking spaces or narrow streets. The mirrors can be folded to reduce the width significantly, making it easier to squeeze through narrow gaps, park in compact garages, or avoid obstacles. Conversely, when driving, the mirrors are opened to provide safe visibility but require awareness of the increased width.

The Honda CR-V V has a ride height or ground clearance between 155 mm and 208 mm (about 6.1 to 8.2 inches), depending on the configuration and trim. This range offers a good balance for an SUV, providing sufficient clearance to handle rough roads, mild off-road paths, or obstacles like speed bumps and curbs. A higher ground clearance reduces the risk of undercarriage damage while enhancing all-weather versatility. Meanwhile, the CR-V maintains a comfortable ride height for easy entry and exit, as well as a lower center of gravity compared to taller SUVs, which aids in stability and handling.

The height of the Honda CR-V V ranges from 1679 mm to 1689 mm (approximately 66.1 to 66.5 inches). This moderate height allows for a spacious interior cabin, providing ample headroom for passengers while maintaining a relatively aerodynamic profile. Regarding parking, the height means the vehicle can generally fit into most standard residential and commercial garages; however, drivers should check their garage height clearance to ensure compatibility, especially if the garage has additional fixtures like low hanging lights or storage. The height also contributes to ease of access and exit for passengers due to a comfortable seating position.

The curb weight of the Honda CR-V V varies between 1500 kg and 1728 kg (approximately 3,307 to 3,808 pounds), depending on the model, trim, and equipment. A curb weight within this range indicates a vehicle light enough to promote fuel efficiency and responsive handling, yet solid enough to provide stability and safety on the road. The weight supports smooth driving dynamics, good acceleration, and confident braking performance. Lighter models closer to 1500 kg may achieve better fuel economy, while heavier trims with more features or all-wheel-drive systems tend to weigh towards the upper limit.

The Honda CR-V V offers a standard luggage capacity ranging from 150 liters to 1110 liters (approximately 5.3 to 39.2 cubic feet) with rear seats upright, allowing for regular daily cargo needs such as groceries or small luggage. When the rear seats are folded down, the capacity significantly expands to between 936 liters and 2146 liters (about 33.1 to 75.7 cubic feet), making it highly versatile for larger cargo, sports equipment, or moving items. This wide range accommodates different configurations and trim levels, making the CR-V suitable for both family use and active lifestyles requiring ample cargo space.

Yes, the Honda CR-V V typically fits into a standard garage. Standard residential garages usually measure about 2440 mm to 2740 mm (96 to 108 inches) wide and approximately 2130 mm (84 inches) in height. With the CR-V V’s width ranging from 1854 mm - 1855 mm (73 inches) without mirrors folded, it comfortably fits with space to spare, especially if mirrors are folded in, reducing the width to 1932 mm (76.1 inches). Its height between 1679 mm and 1689 mm (66.1 to 66.5 inches) allows ample vertical clearance. The length of roughly 4586 to 4603 mm (180.6 to 181.2 inches) fits well within most garages, leaving room for opening doors and some storage. Checking individual garage sizes is recommended but generally, the CR-V V is garage-friendly.

Compared to the predecessor CR-V IV, the Honda CR-V V (2017-2019) received subtle dimensional increases and modern upgrades. The CR-V V is slightly longer, around 4586-4603 mm (180.6-181.2 inches), compared to the CR-V IV’s length of approximately 4525 mm (178 inches), offering marginally more interior space. Width is similar, but the CR-V V has a sleeker, more aerodynamic design. Height saw slight adjustment to enhance interior headroom. Feature-wise, the CR-V V introduced advanced safety and driver assistance systems such as Honda Sensing, improved infotainment, and a more refined interior. Overall, the CR-V V builds on the solid foundation of the CR-V IV with incremental improvements in size, comfort, and technology without dramatically changing the vehicle’s footprint.

The Honda CR-V V competes strongly in the compact SUV segment with dimensions that provide a roomy and comfortable cabin compared to peers like the Toyota RAV4, Mazda CX-5, and Ford Escape. Its length (4586-4603 mm / 180.6-181.2 inches) and width (1854-1855 mm / 73 inches) position it near the top in terms of interior space, offering generous legroom and cargo capacity. The large luggage capacity, especially with rear seats folded (up to 2146 liters / 75.7 cubic feet), surpasses many rivals that often have lower maximum cargo volumes. With its thoughtful design, the CR-V V maximizes usable space, combining comfort, practicality, and ease of driving — a hallmark for buyers seeking versatility without a bulky SUV footprint.

The Honda CR-V V comes equipped with multiple rim sizes including 17, 18, and 19 inches, with rims typically measuring 7.5J x 18 inches for some trims. Corresponding tire sizes include 235/65 R17, 235/60 R18, 225/65 R17, and 225/60 R18. Larger rims with lower profile tires, like the 19-inch options, can enhance handling and road grip due to larger contact patches but may result in a firmer ride over rough surfaces. Conversely, the 17-inch rim and tire combinations generally provide a softer ride and better absorption of bumps, making them preferable for comfort-focused drivers. These variations allow buyers to choose configurations that best balance performance and comfort.
