1987 Honda Civic IV Dimensions, Size & Specs

The curb weight of the Honda Civic IV ranges between 932 kg and 942 kg (approximately 2055 to 2077 lbs). Its maximum permissible weight varies from 1370 kg to 1400 kg (around 3020 to 3086 lbs). This lightweight design helped improve fuel efficiency and handling characteristics compared to larger sedans at the time.

The Honda Civic IV offers a ground clearance ranging from 150 mm to 160 mm (5.9 to 6.3 inches). This moderate ride height was sufficient to handle a variety of road conditions while maintaining a sporty, low-to-the-ground profile.

The factory standard wheels on the Honda Civic IV are 13-inch rims sized 5J x 13. The accompanying tires measure 175/70 R13, a typical setup for compact sedans of that era. This combination balanced ride comfort, handling, and cost effectively.

Yes, with a length of 4230 mm (166.5 inches) and a width of 1690 mm (66.5 inches), the Honda Civic IV fits comfortably into most standard residential garages, which typically accommodate vehicles up to approximately 5500 mm (216 inches) in length and 2500 mm (98 inches) in width. Its relatively low height of about 1360-1390 mm (53.5-54.7 inches) also ensures good clearance under typical garage doors.

Compared to the third-generation Civic, the Civic IV expanded slightly in all dimensions. It is longer at 4230 mm (166.5 inches), wider at 1690 mm (66.5 inches), and marginally taller (1360-1390 mm or 53.5-54.7 inches). These increases improved interior space and stability while retaining the overall compact and economical nature that defined the Civic line. The weight remained light, emphasizing efficiency and maneuverability.

When compared to competitors like the Toyota Corolla or Nissan Sentra of the late 1980s, the Honda Civic IV held an advantage with its lightweight design (932-942 kg / 2055-2077 lbs) and slightly sportier dimensions. Its 4230 mm length and 1690 mm width were very competitive, offering a balanced mix of interior space and compact exterior dimensions that facilitated easier parking and urban driving. Additionally, Honda's reputation for reliability and fuel efficiency bolstered the Civic's appeal against similar vehicles.

The roof load capacity of the Honda Civic IV is rated at 75 kg (approximately 165 lbs). This means it can safely support roof racks, cargo boxes, or bicycle carriers within that weight limit. It's important to not exceed this limit to maintain vehicle safety and handling performance.

The Honda Civic IV, being a compact sedan, is designed to comfortably seat up to five passengers with two in the front and three in the rear. While specific interior dimensions (such as legroom and headroom) are not widely published, the modest increase in exterior size from the previous generation typically translated into improved cabin space, offering practical room for daily commuting and small families.

The Honda Civic IV features a front MacPherson strut suspension and a rear double-wishbone setup, which was advanced for its class at the time. This configuration provided a balanced mix of ride comfort, stability, and handling responsiveness. Combined with the lightweight chassis and compact dimensions, the Civic IV was well-regarded for its nimble driving dynamics, making it a popular choice for drivers seeking an economical yet enjoyable compact car.
