2022 GMC Sierra 1500 V (GMTT1XX, facelift 2022) Crew Cab Short Box Dimensions, Size & Specs

The width of the 2022 GMC Sierra 1500 V Crew Cab Short Box is 2063 mm (approximately 81.2 inches) without the mirrors. When you include the exterior mirrors as they are opened for driving, the total width increases to 2478 mm (about 97.5 inches). This wider stance with mirrors extended is important to consider for navigating narrow roads or tight parking spaces, but the narrower body width without mirrors aids in urban maneuverability.

The height of the 2022 GMC Sierra 1500 V Crew Cab Short Box varies between 1917 mm and 1990 mm (approximately 75.4 inches to 78.3 inches). This height variation depends on factors such as suspension setup, tire size, and optional equipment like roof racks, running boards, or the presence of a tonneau cover. Additionally, different rims and tires can affect the total vehicle height slightly. The height plays a role in the truck's aerodynamics, visibility, and ability to clear obstacles.

The curb weight of the 2022 GMC Sierra 1500 V Crew Cab Short Box ranges between 2155 kg and 2508 kg (approximately 4750 lbs to 5530 lbs). Variations in weight depend primarily on engine configurations, trim levels, drivetrain options (such as 2WD or 4WD), and installed features or packages. For example, a higher trim with more luxury features or added off-road equipment will generally weigh more than a base model. The weight is an essential factor for fuel efficiency, handling, and payload capacity.

The maximum weight capacity (gross vehicle weight rating - GVWR) of the 2022 GMC Sierra 1500 V Crew Cab Short Box ranges from 3062 kg to 3311 kg (approximately 6750 lbs to 7300 lbs). This includes the vehicle's own weight plus the payload it can safely carry. Payload capacity specifically varies depending on configuration but is designed to allow for heavy-duty towing and hauling tasks typical for a full-size pickup truck. The Sierra 1500 V’s robust chassis and drivetrain options make it well-suited for users needing both daily usability and strong work capability.

Ground clearance for the 2022 GMC Sierra 1500 V Crew Cab Short Box ranges from 200 mm to 276 mm (approximately 7.9 inches to 10.9 inches). This variation depends on factors such as tire size (ranging from 255/70 R17 up to 265/65 R18), suspension tuning, and whether off-road or heavy-duty packages are fitted. Higher ground clearance improves off-road capability and fording depth, while lower clearance can enhance on-road stability and aerodynamics.

The 2022 GMC Sierra 1500 V Crew Cab Short Box comes equipped with several rim and tire size options: rim sizes include 8J x 17 inches, 8.5J x 18 inches, and 8.0J x 17 inches. Tire sizes offered are 255/70 R17, 265/70 R17, and 265/65 R18. These options allow buyers to prioritize factors such as ride comfort, off-road capability, or road performance and influence the ride height and handling characteristics of the truck accordingly.

Standard residential garage dimensions typically measure about 2.4 meters (8 feet) in width and 4.9 to 6 meters (16 to 20 feet) in length. The Sierra 1500 V Crew Cab Short Box, with a width of 2.06 meters (6.76 feet) excluding mirrors and length between 5.89 to 5.92 meters (approximately 19.3 to 19.4 feet), may present length challenges for smaller garages but will fit width-wise comfortably when mirrors are folded. Owners with a standard single garage should check actual dimensions, as the vehicle length approaches or exceeds typical garage depth, but wider two-car garages or specialized parking spaces will generally accommodate it without issues.

Compared to its predecessor, the 2022 GMC Sierra 1500 V Crew Cab Short Box presents subtle increases in length and height, maintaining a similar overall width. The previous generation generally measured slightly shorter in length and had marginally less ground clearance. The current generation also benefits from updated chassis architecture that improves payload and towing capacity while refining ride quality. These dimensional adjustments enhance usability and comfort without dramatically altering the truck’s footprint, ensuring familiar maneuverability alongside improved capability.

Within the full-size pickup segment, the 2022 GMC Sierra 1500 V Crew Cab Short Box is competitive in dimensions, offering a length (5891–5916 mm / 232–233 inches) similar to rivals like the Ford F-150 and Ram 1500 Crew Cabs. Width without mirrors is standard for this segment, though the Sierra’s options for wider mirrors increase its road presence. Its ground clearance and curb weight are also within typical ranges, providing a balance between on-road comfort and off-road capability. Buyers seeking a combination of work versatility and daily comfort will find the Sierra 1500 V’s size and proportions well suited compared to other trucks in the same class.
