2021 Genesis GV70 Dimensions, Size & Specs

Production
Model Year:2021
Production Years:2020 - 2025 in production since 2020
1630 mm64.2 in5.3 ft
4715 mm185.6 in15.5 ft
1630 mm64.2 in5.3 ft
4715 mm185.6 in15.5 ft
1630 mm64.2 in5.3 ft
2165 mm85.2 in7.1 ft
1630 mm64.2 in5.3 ft
2165 mm85.2 in7.1 ft
1630 mm64.2 in5.3 ft
4715 mm185.6 in15.5 ft
1630 mm64.2 in5.3 ft
2165 mm85.2 in7.1 ft
1630 mm64.2 in5.3 ft
2165 mm85.2 in7.1 ft
Length
4715 mm185.6 in15.5 ft
Width
2165 mm85.2 in7.1 ft
Height
1630 mm64.2 in5.3 ft
Trunk Capacity
503 liter17.8 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2021 Genesis GV70, engineered for optimal performance and comfort

Dimensions
Length:4715 mm185.6 in15.5 ft
Width:1910 mm75.2 in6.3 ft
Width (Folded Mirrors):1995 mm78.5 in6.5 ft
Width (Opened Mirrors):2165 mm85.2 in7.1 ft
Height:1630 mm64.2 in5.3 ft
Ground Clearance:174 mm6.9 in0.6 ft
Trunk Capacity:503 liter17.8 cu ft
Trunk Capacity (Max):1678 liter59.3 cu ft
Weight Specifications
Curb Weight:1820 - 2310 kg4012 - 5093 lbs
Maximal permitted Weight:2845 kg6272 lbs
Roof Load:100 kg220 lbs
Tire Specifications
Rims Sizes:18, 19, 21, 8.5J x 20
Tire Sizes:235/55 R19 (W:235 | H:55 | D:19)
265/40 R20 (W:265 | H:40 | D:20)
Useful Information

About 2021 Genesis GV70

The Genesis GV70 is a luxury midsize SUV produced from 2020 to 2025, designed to offer a sophisticated combination of elegant design, impressive performance, and practical dimensions. Measuring 4715 mm (185.6 inches) in length, it sits comfortably in the midsize SUV segment, providing spacious interior room without being overly large. The vehicle's width is 1910 mm (75.2 inches) with folded mirrors, extending to 1995 mm (78.5 inches), and further widening to 2165 mm (85.2 inches) when the mirrors are opened. Standing at a height of 1630 mm (64.2 inches), the GV70 maintains a balanced stance with a ride height or ground clearance of 174 mm (6.85 inches), well-suited for urban driving and light off-road situations.

Weighing between 1820 and 2310 kg (4012 - 5093 lbs), the GV70 maintains a solid yet nimble curb weight, ensuring stable handling and efficient performance. It has a maximum weight rating of 2845 kg (6273 lbs), supporting both passengers and cargo comfortably. Speaking of cargo, the luggage capacity is practical for family or adventure use, offering 503 liters (17.8 cubic feet) of space with the rear seats in place, and expandable to 1678 liters (59.2 cubic feet) when the rear seats are folded down. This versatility makes the GV70 ideal for both everyday tasks and weekend trips.

The SUV rides on a variety of rim sizes, from 18-inch and 19-inch options up to a sportier 21-inch configuration (8.5J x 20 wheel specification), paired with tires sized 235/55 R19 and 265/40 R20 to provide a balance of comfort and road grip. A roof load capacity of 100 kg (220 lbs) also allows for additional cargo solutions like roof racks or carriers. Overall, the Genesis GV70 delivers an alluring mix of modern luxury, practical dimensions, and robust SUV capability, making it a standout choice in the premium SUV market.

Exceptional Features

2021 Genesis GV70 Highlights

Discover the standout features that make the 2021 Genesis GV70 a leader in its class

Powerful Engine Options

The 2021 Genesis GV70 offers a choice between a turbocharged 2.5-liter inline-4 engine producing 300 horsepower and a 3.5-liter twin-turbo V6 engine delivering 375 horsepower, providing strong and responsive performance.

Luxurious Interior

The GV70's cabin features premium materials such as Nappa leather, open-pore wood trim, and customizable ambient lighting, creating a comfortable and upscale environment for occupants.

Advanced Infotainment System

Equipped with a 14.5-inch curved display incorporating both the infotainment and instrument cluster, the system supports Apple CarPlay, Android Auto, and offers intuitive touch and rotary control options.

Comprehensive Safety Features

Includes a suite of driver assistance technologies such as Forward Collision-Avoidance Assist, Blind-Spot Collision-Avoidance Assist, Lane Keeping Assist, and Rear Cross-Traffic Collision-Avoidance Assist to enhance safety on the road.

Dynamic All-Wheel Drive System

The GV70 offers an advanced all-wheel-drive system with electronic torque vectoring, which improves handling and stability in various driving conditions, enhancing both performance and safety.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Genesis GV70 (2021 generation) has an exterior length of 4715 mm (185.6 inches), a width of 1910 mm (75.2 inches) without mirrors, a width of 1995 mm (78.5 inches) with mirrors folded, and 2165 mm (85.2 inches) with mirrors opened. The height stands at 1630 mm (64.2 inches). These dimensions contribute to the GV70's balanced proportions, offering a confident stance on the road while fitting comfortably in typical parking spaces. The mirrored width variations are important to consider for tight parking or narrow lanes, as opened mirrors significantly increase the vehicle's width.

The Genesis GV70's curb weight varies between 1820 kg and 2310 kg (approximately 4012 to 5093 lbs), depending on trim levels and options. The maximum permissible weight is 2845 kg (6272 lbs), accommodating passengers, cargo, and additional load. As a luxury mid-size SUV, these weights align well with the vehicle's size, ensuring sturdy handling, stability, and safety. The weight range affects fuel efficiency and performance, especially considering engine variants and AWD systems within the GV70 lineup.

The Genesis GV70 provides a luggage capacity of 503 liters (17.8 cubic feet) with all seats in place, which is competitive for its class. When the rear seats are folded down, this capacity expands significantly to 1678 liters (59.2 cubic feet), allowing for flexible cargo space suitable for larger items or luggage during travel. This versatility makes the GV70 practical for daily commuting as well as longer trips, giving the user the freedom to accommodate varied cargo dimensions and volumes.

The Genesis GV70 has a ride height or ground clearance of 174 mm (6.85 inches), which is typical for luxury SUVs aimed primarily at on-road comfort and light off-road capability. This clearance balances between providing sufficient distance from road obstacles, speed bumps, or minor terrain irregularities while maintaining stable handling and vehicle dynamics. It offers enough capability for occasional gravel roads or rough urban conditions but is not designed for heavy-duty off-roading.

The Genesis GV70 offers rim sizes including 18, 19, and 21 inches, with a common configuration being 8.5J x 20 inches. Tire sizes vary from 235/55 R19 to 265/40 R20. Larger rims with lower-profile tires (like 21-inch rims with 40-profile tires) provide enhanced handling and a sportier aesthetic but may slightly reduce ride comfort due to stiffer sidewalls. Conversely, smaller rims with higher-profile tires improve ride cushioning and comfort but deliver a different driving feel. These variations allow buyers to tailor the vehicle's style and dynamics to their preferences.

The Genesis GV70 generally fits comfortably into a standard garage, but owners should consider the vehicle's width with mirrors, especially when the mirrors are opened at 2165 mm (85.2 inches or about 7.1 feet). Typical garage door widths vary but commonly are around 2.4 to 2.7 meters (7.9 to 8.9 feet). With folded mirrors, width is 1995 mm (78.5 inches), which provides easier clearance. Therefore, folding mirrors before entering the garage is advisable to avoid contact or damage, especially in narrower garage spaces.

The 2021 Genesis GV70 is a relatively new model in the Genesis lineup, introduced as a luxury compact/mid-size SUV positioned below the larger GV80. Compared to the GV80, the GV70 is smaller, with a length of 4715 mm versus GV80's approximately 4945 mm, making it more maneuverable in urban environments. Since the GV70 does not have a direct predecessor, its design and size reflect current market demands for premium SUVs that blend luxury with practical dimensions for daily use. It fills a gap between smaller crossovers and full-size SUVs in Genesis’s portfolio.

The Genesis GV70 competes with vehicles like the Audi Q5, BMW X3, and Mercedes-Benz GLC in the luxury compact/mid-size SUV segment. Dimensionally, the GV70's length of 4715 mm (185.6 inches) and width around 1910 mm (75.2 inches) are on par or slightly larger than some competitors, offering a comfortable cabin space. Its luggage capacity of 503 liters (17.8 cubic feet) with seats up and 1678 liters (59.2 cubic feet) folded is competitive, providing practical utility. The GV70 often distinguishes itself with refined luxury interiors, advanced technology, and a strong emphasis on driver comfort, giving it an edge in overall user experience despite similar dimensional stats.

Different trims and configurations of the Genesis GV70 may range in curb weight from approximately 1820 kg (4012 lbs) to 2310 kg (5093 lbs). Variations depend on drivetrain types (AWD or RWD), added luxury or safety features, and wheel/tire packages. The GV70's consistent length (4715 mm) and width (1910 mm) remain unchanged but heavier models might experience slight reductions in fuel economy and more solid on-road stability. Lighter trims may offer a more responsive driving experience with potentially better fuel efficiency, while heavier trims likely provide enhanced stability and comfort.

The Genesis GV70 supports a roof load capacity of up to 100 kg (approximately 220 lbs), allowing owners to carry rooftop cargo such as luggage boxes, sports gear, or other equipment. When using the roof load, it is crucial to evenly distribute weight and secure the load properly to avoid damage to the roof or affect driving stability. Overloading beyond this limit may compromise vehicle handling, increase wind resistance, and negatively impact fuel efficiency. Additionally, users should remove cargo when not needed to restore optimal aerodynamics and prevent unnecessary wear.
