2014 Ford Transit Connect II Wagon L2 Dimensions, Size & Specs

The Ford Transit Connect II Wagon L2 offers versatile cargo space tailored for different needs. With the rear seats in their upright position, the luggage capacity is 322 liters (approximately 11.4 cubic feet), which is sufficient for daily groceries, luggage for a family, or smaller loads. When the rear seats are folded down, the available cargo space expands substantially to 2761 liters (around 97.5 cubic feet), making it practical for transporting larger items such as furniture, equipment, or bulkier goods. This large increase in cargo volume reflects the vehicle’s multipurpose design aimed at users needing both passenger seating and ample cargo flexibility.

The curb weight of the 2014 Ford Transit Connect II Wagon L2 varies between 1456 kg and 1819 kg (approximately 3210 to 4009 lbs), depending on the specific trim level and optional equipment installed. This weight is the standard mass of the vehicle without passengers or cargo but with all necessary operating consumables such as fuel and oil. The vehicle's maximum permissible weight, which includes passengers, cargo, and the vehicle itself, ranges from 2270 kg to 2395 kg (about 5002 to 5280 lbs). This maximum weight rating helps users understand the vehicle’s load limits to maintain safe handling and optimal performance.

The ride height or ground clearance of the Transit Connect II Wagon L2 is 163 mm (6.4 inches), which strikes a balance between comfort, accessibility, and utility. This moderate ground clearance allows for easier entry and exit for passengers, making it suitable as a family-oriented minivan or for business purposes. At the same time, it offers enough clearance to manage typical urban and suburban road conditions, including speed bumps and uneven surfaces, without risking damage to the undercarriage. However, this clearance is not high enough for serious off-road driving but meets the practical needs of its target audience perfectly.

Yes, the side mirrors of the 2014 Ford Transit Connect II Wagon L2 notably affect its overall width. Without mirrors, the vehicle is approximately 1834-1835 mm wide (72.2-72.3 inches). Folding the mirrors reduces the width to 1966 mm (77.4 inches), while mirrors fully opened extend the width to 2137 mm (84.1 inches). This increased width with mirrors extended must be considered when navigating tight parking spots, narrow streets, or garage entrances. Operators will often fold mirrors in congested areas to reduce width for better clearance and to prevent damage but should ensure mirrors are opened fully when driving for safety and better visibility.

Compared to the first-generation Ford Transit Connect, the 2014 Transit Connect II Wagon L2 is longer and wider, offering improved passenger comfort and cargo capacity. The second generation measures 4818 mm long, which is an increase over the previous generation's approximate length of 4398 mm to 4413 mm, depending on the variant. Width has also increased, making the vehicle more spacious. Additionally, the luggage volume saw a significant improvement, especially with rear seats folded, jumping to 2761 liters from a much smaller figure in the predecessor. These enhancements reflect Ford's focus on adapting the Transit Connect into a more versatile and family-friendly vehicle, offering a refined ride and greater usability.

The 2014 Ford Transit Connect II Wagon L2 typically features rims sized 6.5J x 16 inches with tire sizes mainly at 205/60 R16 or 215/55 R16. These tire options provide a good balance between ride comfort, handling, and load-bearing capacity. The relatively tall sidewalls (indicated by the tire aspect ratios 60 and 55) help absorb road irregularities, contributing to a smoother ride suitable for both urban and highway driving. Additionally, the 16-inch wheel diameter offers a compromise between maintaining ride comfort and ensuring enough grip and stability for a vehicle that often carries heavier loads or passengers.

The 2014 Ford Transit Connect II Wagon L2, at 4818 mm (189.6 inches) in length and a width of up to 2137 mm (84.1 inches) with mirrors fully opened, fits into many standard residential garages, but with some considerations. Typical single-car residential garages have interior widths around 2400 mm (94.5 inches) and lengths ranging from 4800 mm to 5400 mm (189-213 inches). This means that while the Transit Connect II Wagon L2 will fit lengthwise in many garages, clearance can be tight, especially when mirrors are extended. Folding mirrors before parking can help. Height is usually not an issue given the vehicle’s maximum height of 1840 mm (72.4 inches), which fits well under standard garage doors.

The Ford Transit Connect II Wagon L2 holds its own well against similar minivans and compact cargo wagons in terms of dimensions and cargo capacity. Its length of 4818 mm (189.6 inches) is competitive, often slightly longer than some compact rivals, while its width and height also provide a spacious cabin atmosphere. The standout feature is its versatile cargo volume, especially the large 2761 liters (97.5 cubic feet) available with the rear seats folded, which is higher than many competitors in its class. This makes it particularly attractive for users needing flexible combinations of passenger seating and cargo space, easily competing with vehicles like the Nissan NV200 or Chevrolet City Express in terms of utility.

Within the 2014 Ford Transit Connect II Wagon L2 range, curb weight varies from 1456 kg to 1819 kg (approximately 3210 to 4009 lbs). This variation is due to differences in trim levels, equipment packages, and optional features such as all-wheel drive or enhanced safety technology packages. Similarly, the vehicle's height can range between 1828 mm and 1840 mm (71.9 to 72.4 inches), influenced primarily by roof rack availability or antenna mounts. Understanding these variances is important for users mindful of weight limits or garage clearances and can impact factors such as fuel consumption, handling characteristics, and allowable payload capacities.
