2019 Ford Transit Connect II (facelift 2018) Wagon L2 Dimensions, Size & Specs

For the 2019 Ford Transit Connect II Wagon L2, the width with the side mirrors folded is 1967 mm (77.4 inches), making it easier to park in tight spaces. With mirrors opened, the width extends to 2137 mm (84.1 inches), which is important for understanding clearance in narrow lanes or parking spots.

The curb weight, which is the vehicle's weight without passengers or cargo, for this model ranges from 1659 kg to 1813 kg (3658 to 3998 lbs). Its maximum permissible weight, or gross vehicle weight rating (GVWR), ranges between 2280 kg and 2472 kg (5027 to 5449 lbs), indicating the maximum total weight including passengers and cargo.

With all rear seats in place, the luggage capacity of the Transit Connect II Wagon L2 is a modest 300 liters (approximately 10.6 cubic feet), suitable for everyday groceries or small luggage. When the rear seats are folded flat, the cargo volume expands dramatically to 2800 liters (about 98.9 cubic feet), making it ideal for larger loads or moving bulky items.

Standard residential garages typically measure about 2400 mm to 2700 mm (94.5 to 106 inches) wide and 4800 mm to 5500 mm (189 to 216 inches) deep. With a length of 4825 mm (190 inches) and a width between 1835 mm and 2137 mm (72.2 to 84.1 inches including mirrors), the Transit Connect II Wagon L2 fits comfortably in terms of length and width, although mirror clearance when opened may require cautious maneuvering. The height of 1820 mm (71.7 inches) also generally fits under standard garage door heights.

The Ford Transit Connect II Wagon L2 has a ground clearance of 144 mm (5.7 inches), which is relatively low for a minivan but typical for vehicles designed for urban and suburban driving. This clearance provides a good balance between ease of entry, stable handling, and the ability to clear common road obstacles and speed bumps, though it is less suitable for rough or uneven terrain.

Compared to the first generation Transit Connect, the 2019 second generation Wagon L2 has increased in length to 4825 mm (190 inches) from approximately 4410 mm (173.6 inches) and has a wider body at 1835 mm (72.2 inches) compared to the previous narrower stance. This increase in size provides more interior space for passengers and cargo, reflecting a shift toward greater versatility and comfort in the second generation model.

When compared to similar minivan models like the Volkswagen Caddy or Mercedes-Benz Metris, the Ford Transit Connect II Wagon L2 offers a longer length of 4825 mm (190 inches) and competitive width of 1835 mm (72.2 inches excluding mirrors), providing ample cargo and passenger space. Its folding rear seats allowing up to 2800 liters (98.9 cubic feet) of cargo capacity position it favorably for both family and commercial use. While other minivans might offer slightly larger interiors or features, the Transit Connect strikes a practical balance of size, maneuverability, and cargo versatility.

The 2019 Ford Transit Connect II Wagon L2 comes with rim sizes of 6.5J x 16 and 6.5J x 17 inches, paired with tire options of 205/60 R16, 215/55 R16, and 215/55 R17. These tire sizes provide a good balance between ride comfort, fuel efficiency, and handling. The relatively tall sidewalls contribute to absorbing road imperfections, which is beneficial for urban and light cargo transport applications.

The 2019 Ford Transit Connect II Wagon L2 is a versatile minivan primarily designed for both family and commercial use. Its spacious interior, flexible seating arrangements, and sizable cargo capacity make it practical for transporting passengers and goods. It combines compact exterior dimensions suitable for city driving with a focus on utility, safety, and efficiency. The facelifted model includes updated styling and features introduced in 2018, continuing production until at least 2024.
