2010 Ford Transit Connect I (facelift 2009) Panel Van L2H2 Dimensions, Size & Specs

The Ford Transit Connect I (facelift 2009) Panel Van L2H2 has a width of 1795 mm (about 70.7 inches) excluding mirrors. With the side mirrors opened, the width expands between 2044 mm and 2113 mm (approximately 80.5 to 83.2 inches), which is essential to consider when driving in tight spaces or parking. This width with mirrors deployed is quite standard for a vehicle in the minivan/commercial panel van category.

The height of this Transit Connect variant ranges from 1980 mm to 2014 mm (approximately 77.9 to 79.3 inches). This tall roof height (L2H2 stands for Long wheelbase, High roof) enhances interior vertical space, making it ideal for cargo loading and maximizing interior volume. The taller height also influences driving dynamics and garage compatibility, which should be considered for potential owners.

The curb weight of the 2010 Ford Transit Connect I facelift 2009 L2H2 ranges from 1432 kg to 1796 kg (approximately 3157 to 3960 pounds), depending on trim and equipment. The maximum permissible weight ranges between 2260 kg and 2340 kg (roughly 4980 to 5157 pounds). This payload capacity allows for substantial cargo and equipment transport, making this model favored in commercial fleet usage.

This generation of the Ford Transit Connect Panel Van L2H2 delivers impressive cargo volume. The luggage capacity ranges from 3670 to 3700 liters (129.7 to 130.6 cubic feet) with the rear seats in place. With the rear seats folded, the cargo space expands significantly to approximately 4300 liters (151.9 cubic feet). This generous space makes it highly practical for transporting goods, tools, and large items for commercial or personal use.

The ride height or ground clearance for the Transit Connect L2H2 ranges between 166 mm and 183 mm (6.5 to 7.2 inches). This moderate clearance balances accessibility for loading and unloading cargo while providing enough height to comfortably handle uneven urban terrain or light off-road conditions. It is well-suited for city driving with occasional rough surface encounters.

Given the height range of 1980 mm to 2014 mm (about 78 to 79.3 inches), the 2010 Ford Transit Connect Panel Van L2H2 can be a tight fit in many standard residential garages, which typically have a clearance height of around 2 meters (approx. 79 inches). While the length of 4525-4587 mm and width (about 1795 mm excluding mirrors) will normally fit comfortably in most garages, owners should verify garage door height and width before parking this tall van inside to avoid clearance issues.

Compared to the pre-facelift Ford Transit Connect I models produced before 2009, the facelifted 2009-2013 version L2H2 has received subtle dimensional enhancements, particularly in length (up to 4587 mm) and height (up to 2014 mm) to optimize cargo space and driver ergonomics. The width remains similar, but aerodynamic improvements were introduced for better efficiency. Overall, these changes reflect a focus on increasing payload efficiency and usability while maintaining the compact footprint of the Transit Connect.

When compared to similar compact panel vans like the Volkswagen Caddy or Mercedes-Benz Citan from the same era, the 2010 Ford Transit Connect I L2H2 stands out for its taller roof height and slightly larger cargo volume, particularly with rear seats folded reaching up to 4300 liters. While VW Caddy and Mercedes Citan offer comparable width and length, the Transit Connect's higher roof provides better vertical loading space, making it a preferred choice for businesses requiring roomier cargo areas without stepping up to full-size vans.

The standard rim size for this Transit Connect generation is 15 inches, specifically 15 x 6J rims. Tire options commonly include 205/65 R15 or 195/65 R15 sizes. These tire dimensions provide a balance between ride comfort, handling, and load-carrying capability, suitable for urban and suburban driving while supporting the vehicle’s weight and payload.
