2010 Ford Transit Connect I (facelift 2009) Crew Van L2H2 Dimensions, Size & Specs

The curb weight of the 2010 Ford Transit Connect I (facelift 2009) Crew Van L2H2 ranges from 1526 to 1573 kilograms (3364 to 3469 pounds). This represents the weight of the vehicle without passengers or cargo but with all necessary fluids and a full tank of fuel. The maximum gross weight, which includes the vehicle’s weight plus the maximum allowable load, ranges from 2252 to 2340 kilograms (4964 to 5157 pounds). This makes it well-suited for carrying substantial cargo loads, aligning with its purpose as a commercial minivan.

The 2010 Ford Transit Connect I Crew Van L2H2 offers impressive cargo volume suitable for commercial and utility purposes. With the rear seats in place, the luggage capacity ranges between 2100 to 2220 liters (approximately 74.1 to 78.4 cubic feet). When the rear seats are folded down, the cargo volume expands significantly to between 3361 to 3400 liters (118.7 to 120 cubic feet). This expansive capacity supports the transport of bulky goods, tools, or supplies with ease, making it a versatile vehicle for various professional and personal uses.

The 2010 Ford Transit Connect I (facelift 2009) Crew Van L2H2 features a ride height or ground clearance ranging from 166 to 183 millimeters (6.5 to 7.2 inches). This clearance provides a good balance between accessibility and undercarriage protection, making it suitable for navigating urban streets, light off-road conditions, and uneven surfaces commonly encountered during deliveries or work-related travel. The moderate ground clearance contributes to stability and a comfortable ride.

The standard wheel size on the 2010 Ford Transit Connect I Crew Van L2H2 is 6J x 15 inches, which are paired with tire sizes of either 195/65 R15 or 205/65 R15. These tire dimensions offer a good balance of ride comfort, durability, and load capacity suited to the vehicle’s commercial purposes. The combination ensures adequate grip and stability, essential for carrying cargo and handling varying road conditions safely.

Given its dimensions, the 2010 Ford Transit Connect I (facelift 2009) Crew Van L2H2 fits comfortably into most standard residential garages. With a height ranging between 1980 and 2014 mm (77.9 to 79.3 inches), it’s slightly taller than typical sedans but generally still fits under common garage door heights, which usually exceed 2 meters (79 inches). Its width of 1795 mm (70.7 inches), excluding mirrors, means that folding or closing mirrors is advisable in narrower garages to avoid contact with walls or objects, as the width with mirrors opened extends up to 2113 mm (83.2 inches). Overall, it should accommodate well in standard single-car garages with reasonable maneuvering space.

The 2010 Ford Transit Connect I (facelift 2009) is a refreshed version of the first generation introduced in 2002. The facelift brought some dimensional updates, especially with the Crew Van L2H2 variant offering a longer wheelbase and increased height compared to earlier models. Length increased slightly up to 4587 mm (180.6 inches), while the height was raised to a max of 2014 mm (79.3 inches), enhancing interior cargo volume and standing room inside the vehicle. Width remained relatively similar, but the facelift improved interior ergonomics and load flexibility. Overall, the facelifted model provided better utility without compromising maneuverability compared to its predecessor.

Within the compact and small commercial van segment, the 2010 Ford Transit Connect I (facelift 2009) offers competitive dimensions and cargo capacity. Its length of around 4.5 meters (approximately 178 to 181 inches) and large cargo volume of up to 3400 liters (120 cubic feet) with seats folded places it favorably versus rivals like the Volkswagen Caddy or the Fiat Doblo. While some competitors may offer slightly larger exterior dimensions or cargo space, the Transit Connect balances compact maneuverability with practical cargo carrying ability. Additionally, its moderate height and width make it easier to handle in urban environments, a key selling point compared to bulkier full-size vans.

The 2010 Ford Transit Connect I (facelift 2009) Crew Van L2H2 is primarily designed as a versatile small commercial van suitable for tradespeople, delivery services, and businesses requiring efficient cargo transportation. Key features include a spacious cabin accommodating up to five occupants, excellent cargo capacity with various configurations, and a compact footprint allowing ease of driving in city traffic. The vehicle is appreciated for its fuel efficiency, practical ride height, and reliability in everyday use. It is ideal for those needing a balance of passenger transport and significant cargo volume in one commercial vehicle.

The 2010 Ford Transit Connect I Crew Van L2H2 is configured to comfortably seat up to five occupants, making it a suitable choice where both cargo space and passenger transport are required. The interior space is optimized to allow a balance between passenger comfort and cargo capacity, offering flexible seating arrangements especially with foldable rear seats. This versatility means users can switch between carrying passengers and maximizing cargo volume, which can reach up to 3400 liters (120 cubic feet) with rear seats folded. The interior also features practical storage spaces and an ergonomic dashboard designed for commercial efficiency.
