2016 Ford S-MAX II Dimensions, Size & Specs

The curb weight of the Ford S-MAX II ranges from 1645 kg to 1809 kg (3627 to 3987 pounds), varying depending on the specific trim level and optional equipment chosen. This weight reflects the vehicle's construction, safety features, and design emphasis on durability. The maximum permissible weight, also known as the gross vehicle weight rating (GVWR), spans from 2450 kg to 2615 kg (5401 to 5762 pounds). This capacity ensures the vehicle can carry passengers, cargo, and any additional load without compromising safety or performance.

The Ford S-MAX II boasts a versatile luggage capacity tailored to varying needs. With all rear seats in use, the available cargo space is between 285 liters and 700 liters (approximately 10 to 25 cubic feet), suitable for groceries, luggage, or daily items. When the rear seats are folded down, the capacity expands significantly, offering between 2020 liters and 2200 liters (71 to 77.7 cubic feet) of storage space, making it ideal for transporting larger items, furniture, or extensive travel luggage. This flexibility enhances the vehicle's practicality as a family minivan or multipurpose vehicle.

The Ford S-MAX II has a ground clearance of 128 mm (5.04 inches). This relatively low ride height improves the vehicle's stability and handling, especially on paved roads and highways, enhancing driving dynamics for family and urban use. However, it also means that the S-MAX II might be less suited for rough off-road conditions or very uneven terrain, where higher clearance would prevent scraping or damage underneath. For typical suburban and city driving, the 128 mm clearance strikes a balance between comfort and practicality.

Yes, the side mirrors increase the overall width of the Ford S-MAX II from 1916 mm (75.4 inches) to 2137 mm (84.1 inches) when fully opened. This roughly 22 cm (8.7 inches) increase per side is critical during parking or navigating narrow streets. Drivers should be mindful of this extended width to avoid damage and ensure safe maneuvers in tight spaces. Folding mirrors when stationary or parking can mitigate width issues. The consideration of mirror extension is important, especially in urban environments with limited parking spaces.

The Ford S-MAX II's dimensions suggest that it will generally fit into a standard residential garage, but with some caveats. The typical single-car garage width varies from 2400 mm to 3000 mm (94.5 to 118 inches), so the car's 1916 mm (75.4 inches) width fits comfortably within this range. Including mirrors, the width extends to 2137 mm (84.1 inches), so mirrors will need to be folded in for tight garages. The height at 1655 mm (65.2 inches) is well below most garage door heights, which are usually over 2000 mm (78 inches). Length of 4796 mm (188.8 inches) is more critical; standard garages range from 5400 mm to 6000 mm (213 to 236 inches) in depth, so the S-MAX II should fit lengthwise with some space to spare, assuming an average garage depth.

Compared to the first generation Ford S-MAX (produced from 2006 to 2015), the S-MAX II introduced in 2015 offers subtle but meaningful changes in size and proportions. The second generation measures 4796 mm (188.8 inches) in length, slightly longer than the first generation's approximate 4662 mm (183.5 inches), translating to more cabin and cargo space. In terms of width, the S-MAX II is wider at 1916 mm (75.4 inches) versus the previous gen's 1850 mm (72.8 inches), enhancing interior shoulder space but also increasing the vehicle's footprint. Height has been maintained around the same, circa 1655 mm (65.2 inches). These dimensional updates improved passenger comfort and utility, maintaining a balance between urban usability and spaciousness.

Within the midsize minivan or multi-purpose vehicle (MPV) segment, the Ford S-MAX II holds competitive dimensions. It is marginally longer and wider than some rivals like the Volkswagen Touran or Citroën Grand C4 SpaceTourer, which typically measure slightly less in length and width. For example, the VW Touran measures around 4486 mm (176.6 inches) in length and 1832 mm (72.1 inches) in width, making the S-MAX II roomier. The S-MAX II’s larger luggage capacity (up to 2200 liters with seats folded) also often surpasses competitors, making it one of the more spacious and versatile options available. This size makes it attractive for families needing space without moving to a full-size van.

The Ford S-MAX II comes equipped with various tire and rim size options, including rims sized 7.5J x 17, 7.5J x 18, and 8J x 19, coupled with tire sizes of 235/55 R17, 235/50 R18, and 245/45 R19 respectively. Larger rims with lower-profile tires (e.g., 19-inch rims with 245/45 tires) generally improve handling and cornering stability due to reduced tire sidewall flex but may result in a firmer ride and increased susceptibility to road imperfections. Conversely, smaller rims with higher-profile tires (e.g., 17-inch rims with 235/55 tires) offer a more comfortable ride, better absorption of bumps, and potentially longer tire life. Choosing the appropriate tire and rim combination depends on driving preferences, with the S-MAX II offering flexibility to balance comfort and performance.

The curb weight of the Ford S-MAX II ranges from 1645 kg to 1809 kg (3627 to 3987 pounds) due to several factors. Variations in trim levels contribute significantly, with basic models weighing less due to fewer added features or lighter materials, while higher trims equipped with advanced safety systems, larger wheels, or luxury options add weight. Engine type affects weight as well, with diesel or larger displacement engines usually heavier than smaller petrol options. Additionally, the inclusion of all-wheel drive versions or other optional equipment such as panoramic roofs can increase the overall weight. These factors lead to varied fuel consumption, handling characteristics, and payload capacities within the same model generation.
