2019 Ford Ranger IV SuperCrew (Americas) Dimensions, Size & Specs

The width of the Ford Ranger IV SuperCrew notably changes due to the mirrors. With mirrors folded, the width ranges from 1976 mm to 2028 mm (77.8 to 79.8 inches), making it easier to maneuver in tighter parking spaces or narrow roads. When the mirrors are opened, the width increases significantly to between 2179 mm and 2180 mm (85.8 to 85.9 inches), which should be considered when driving on narrow lanes or parking spots to ensure adequate clearance.

The height of the Ford Ranger IV SuperCrew ranges from 1806 mm to 1873 mm (71.1 inches to 73.7 inches), which is typical for midsize pickup trucks in this segment. Its ride height or ground clearance ranges from 213 mm to 283 mm (8.4 inches to 11.1 inches), offering good capability for off-road driving and uneven terrain. This range of ground clearance supports better obstacle negotiation and overall versatility for outdoor and utility use.

The curb weight of the 2019-2023 Ford Ranger IV SuperCrew is approximately 2332 kg (5138 lbs). It has a maximum weight capacity that ranges between 2744 kg to 3090 kg (6053 lbs to 6813 lbs), depending on configuration and equipment. This shows the vehicle's robust build, allowing it to carry heavy loads, whether passengers or cargo, making it suitable for demanding work or recreational purposes.

The Ford Ranger IV SuperCrew comes with rim sizes of 16, 17, or 18 inches, depending on the trim and package selected. The corresponding tire sizes include 285/70 R17, 255/70 R16, 255/65 R17, and 265/60 R18. These tire and rim options offer flexibility between ride comfort, off-road capability, and aesthetic preferences, adapting well to different driving needs and terrain types.

Standard garages usually measure approximately 2438 mm (8 feet) wide by 6096 mm (20 feet) deep. With the Ford Ranger IV SuperCrew's width ranging up to 2028 mm (79.8 inches) and mirrors folded width up to nearly 2028 mm (79.8 inches), it fits comfortably within standard garage widths, but parking one with mirrors opened (up to 2180 mm or 85.9 inches wide) would be tight or impractical. Its length of up to 5398 mm (212.6 inches) fits well within the depth of a typical garage, so overall, the Ranger can fit in a standard garage with mirrors folded and careful maneuvering.

Compared to the previous generation Ford Ranger, the Ranger IV SuperCrew (2019-2023) is generally larger in most dimensions. It gained length, width, and height improvements to provide more interior space and cargo capacity. For example, its length increased by approximately 200-300 mm, and width and height also grew to improve cabin comfort and road presence. These augmentations offer a more refined driving experience and improved utility while maintaining the agile feel expected in a midsize pickup.

The Ford Ranger IV SuperCrew is competitive in the midsize pickup segment. Its length, ranging from 5354 to 5398 mm (211-212.6 inches), and width up to 2028 mm (79.8 inches) put it roughly in line with competitors like the Chevrolet Colorado, Toyota Tacoma, and Nissan Frontier. While some rivals may be slightly more compact, the Ranger's size offers a balanced combination of interior space and maneuverability. Ground clearance and load capacities are also competitive, making it a top choice for buyers seeking versatility and capability in a midsize truck.

The 2019-2023 Ford Ranger IV SuperCrew is designed with a spacious cabin to accommodate up to five passengers comfortably with its SuperCrew configuration. While specific interior dimensions vary by seat position and trim, the overall increased exterior dimensions translate to improved legroom and headroom compared to previous generations. The cargo bed size is tailored for practical utility, typically ranging around 1.5 meters (approximately 5 feet) in length, ideal for hauling equipment, tools, or recreational gear, making it a versatile pickup for work and lifestyle uses.

Given its sizeable dimensions and weight, the Ford Ranger IV SuperCrew (2019-2023) is well-suited for a wide range of uses. Its robust curb weight of approximately 2332 kg (5138 lbs) and payload capacity enable heavy-duty tasks such as towing trailers, carrying construction materials, or transporting outdoor sporting goods. The ample ground clearance and rugged build also make it a strong candidate for off-road adventures and rural driving. Additionally, the spacious SuperCrew cabin makes it practical for family or work crews needing comfortable transport alongside cargo space.
