2018 Ford Mustang Convertible VI (facelift 2017) Dimensions, Size & Specs

The width of the Ford Mustang Convertible VI (2017-2023 facelift) varies depending on the position of the side mirrors. With the mirrors folded in, the width ranges from 1933 mm to 1957 mm (about 76.1 to 77 inches). When the mirrors are extended/opened, the width increases to approximately 2080 to 2081 mm (81.9 to 81.91 inches). The body width without mirrors stands at 1915 to 1916 mm (75.39 to 75.43 inches). This information is critical for garage fitting and urban driving, as the mirrors notably add to the width.

The height of the Ford Mustang Convertible VI facelift (2017-2023) measures between 1394 mm and 1396 mm (approximately 54.9 to 54.96 inches). This relatively low profile is typical of sports convertibles, delivering a sleek and dynamic stance while facilitating better aerodynamics and handling characteristics for an engaging driving experience.

The curb weight of the Ford Mustang Convertible VI facelift edition ranges from 1681 kg to 1771 kg (approximately 3707 to 3905 lbs), depending on specific trim or additional equipment. The maximum permissible weight is rated at 2150 kg (around 4740 lbs). This weight range reflects a balance between a sturdy build with reinforced convertible structures and the desire to maintain agile driving dynamics.

The Mustang Convertible VI facelift version provides a luggage capacity ranging from 323 liters to 332 liters (about 11.4 to 11.7 cubic feet). This is relatively spacious for a convertible, allowing owners to carry everyday essentials or even small luggage for trips, albeit less than a traditional coupe or sedan due to the convertible roof mechanism which takes up part of the rear space.

The ride height or ground clearance of the Ford Mustang Convertible VI facelift is approximately 144 mm (5.67 inches). This lower ground clearance is typical for sports-oriented vehicles to improve handling and stability by lowering the center of gravity. However, it means drivers should be cautious on uneven roads or speed bumps to avoid scraping the underbody.

Yes, the Ford Mustang Convertible VI facelift generally fits into a standard garage. With a length just under 4.79 meters (about 15.7 feet) and a height of around 1.4 meters (4.58 feet), these dimensions align with typical garage door clearances. The width, especially with mirrors folded (approximately 1.95 meters or 6.4 feet), should also comfortably fit through most standard garage entrances. Owners should, however, be mindful of mirror extension which can increase width to just over 2 meters (about 6.8 feet) when opening or parking in tighter spaces.

Compared to the previous generation Mustang Convertible, the 2017 facelift Mustang Convertible VI is very similar in exterior dimensions but includes refined design elements enhancing aerodynamics and body rigidity. Length and width remain in the same general range—around 4.79 meters in length and just under 2 meters in width with mirrors folded. The newer model may have slight improvements in curb weight due to advanced materials, maintaining a balance between structural strength (important for convertibles) and weight reduction. Overall, it represents an evolution with subtle dimensional tweaks rather than a wholesale size change.

The Mustang Convertible VI facelift is comparable in size to its American muscle convertible competitors like the Chevrolet Camaro Convertible and Dodge Challenger Convertible. Its length (approximately 4.79 meters/15.7 feet) and width (up to about 2.08 meters/6.8 feet with mirrors) place it in the mid-to-large range for this vehicle category. While its dimensions are closely matched to the Camaro, the Dodge Challenger tends to be slightly larger and heavier, offering more interior and trunk space but compromising some agility. The Mustang strikes a balance with sporty proportions, muscular presence, and manageable dimensions for everyday usability.

The Ford Mustang Convertible VI (2017 facelift) offers several rim and tire size options to suit different performance and aesthetic preferences. The rims can be sized from 8J x 18 inches to larger 9.5J x 19 inches and 9J x 19 inches options. Correspondingly, tire sizes available include 275/40 R19 and 255/40 R19. These larger wheel and tire sizes enhance handling, grip, and the car's aggressive stance, contributing to both performance driving and visual appeal.
