2011 Ford F-250 Super Duty III Super Cab Short box Dimensions, Size & Specs

The 2011-2016 Ford F-250 Super Duty III Super Cab Short box has a curb weight ranging between 2767 kg and 2998 kg (approximately 6100 to 6610 lbs). The maximum permissible weight, which includes passengers and cargo, ranges from 4491 kg to 4536 kg (about 9900 to 9999 lbs). This robust weight specification reflects the truck's heavy-duty construction designed for towing, hauling, and demanding work scenarios.

The ground clearance of the 2011-2016 Ford F-250 Super Duty III Super Cab Short box ranges from 208 mm to 216 mm (8.2 to 8.5 inches). This height is ample for a full-size pickup truck, providing good off-road capability and allowing the vehicle to clear rough terrain, rocks, and obstacles without damaging the underbody. The ride height also contributes to better water fording and an elevated driving position, both important advantages in challenging work or outdoor conditions.

The 2011-2016 Ford F-250 Super Duty III Super Cab Short box measures 2664 mm (104.9 inches) in width when the side mirrors are folded. With the mirrors fully opened, the overall width extends to 2794 mm (110 inches). This extended width is critical to keep in mind when navigating narrow streets or parking, as the mirrors add significant width beyond the vehicle body. Folded mirrors help improve ease of parking and maneuvering in tight spaces.

This generation of the Ford F-250 Super Duty III Super Cab Short box offers a luggage capacity of 1815 liters (approximately 64.1 cubic feet) with the rear seats folded down. This provides a substantial amount of cargo space, ideal for transporting larger equipment, tools, or other bulky items. While pickups primarily rely on their bed for cargo, the expanded rear cabin space offers additional flexibility for secure and weather-protected storage.

Fitting the 2011-2016 Ford F-250 Super Duty III Super Cab Short box into a standard residential garage can be challenging due to its large size. With a length of 5903 mm (232.3 inches) and a width (mirrors folded) of 2664 mm (104.9 inches), it often exceeds the dimensions of typical single-car garages, which usually are about 5500 mm (216 inches) in length and 2400-2700 mm (94-106 inches) in width. Additionally, the vehicle height can be up to 2019 mm (79.5 inches), which should be checked against the garage door opening height. Owners with standard garages may need to fold mirrors or consider larger garage spaces to accommodate the truck comfortably.

Compared to its predecessor, the 2011-2016 Ford F-250 Super Duty III Super Cab Short box typically features modest dimensional updates, focusing on improved interior space, comfort, and functional design. Although exact previous generation dimensions vary slightly by model year, this generation is often a bit longer and wider to meet growing customer demands for cabin comfort and utility. The increase in curb weight and maximum weight capacity reflects enhancements in structure and towing capability. Overall, this generation offers a larger, more refined truck while maintaining the ruggedness expected from the F-250 series.

The 2011-2016 Ford F-250 Super Duty III Super Cab Short box holds strong against competitors such as the Chevrolet Silverado 2500HD and Ram 2500. Dimensionally, it is comparable or slightly larger in length and width, especially considering mirror width. Its robust maximum weight rating and cargo capacity position it favorably for heavy-duty work and towing in its class. The ride height and ground clearance are competitive, offering good off-road performance. Ford’s Super Duty line is well-regarded for strong engine options, durability, and advanced towing technologies, often giving it an edge over rivals in real-world utility despite similar external sizes.

The 2011-2016 Ford F-250 Super Duty III Super Cab Short box supports several tire size options depending on trim and preference. Common compatible tire sizes include 265/70 R17, 275/65 R18, and 275/70 R18. These tires balance load capacity and ride comfort, suitable for the vehicle's heavy-duty use, providing traction, stability, and durability on various terrains. Tire choices can influence overall vehicle dimensions slightly, particularly in height, which can affect approach angles and clearance.

The 2011-2016 Ford F-250 Super Duty III is available in multiple cab and bed configurations, including Regular Cab, Super Cab, and Crew Cab variants. The Super Cab is a mid-size cab with two full front doors and smaller rear-hinged rear doors, paired here with a Short box bed, which balances passenger space and cargo carrying needs. This flexibility allows buyers to choose a configuration best suited for work or personal use. Each configuration impacts overall vehicle length and interior passenger capacity, with the Super Cab providing increased rear seating accessibility compared to the Regular Cab.
