2006 Ford Explorer IV Dimensions, Size & Specs

The width of the Ford Explorer IV varies between 1832 mm and 1872 mm (72.1 to 73.7 inches) when considering only the vehicle's body without mirrors. With the side mirrors folded, the width increases to approximately 1969 mm (77.5 inches). When the mirrors are opened, the width extends further to about 2154 mm (84.8 inches). These dimensions are important for parking and garage fitment considerations, as well as for ensuring safe clearance on narrow roads.

The Ford Explorer IV SUV's height ranges from 1814 mm to 1849 mm (71.4 to 72.8 inches), depending on the specific model and any roof accessories installed. The vehicle's ride height, or ground clearance, is approximately 208 mm (8.2 inches). This ground clearance enables the SUV to manage moderate off-road conditions and uneven terrains while maintaining a comfortable ride height for passengers and good visibility on the road.

The curb weight of the 2006-2010 Ford Explorer IV ranges from 1925 kg to 2170 kg (4244 to 4785 lbs), depending on configurations such as engine options, trim levels, and installed equipment. The maximum permissible weight, or gross vehicle weight rating (GVWR), spans from 2567 kg to 2825 kg (5661 to 6229 lbs). This indicates the vehicle's capacity to carry passengers, cargo, and any additional loads safely.

The luggage capacity in the Ford Explorer IV is approximately 385 to 391 liters (13.6 to 13.8 cubic feet) with all rear seats upright, providing moderate cargo space for everyday needs such as groceries or luggage for a trip. When the rear seats are folded down, the cargo volume significantly expands to between 2370 and 2492 liters (83.7 to 88 cubic feet), offering substantial loading capacity ideal for larger items, camping gear, or other bulky cargo.

The Ford Explorer IV generally fits into a standard garage, but it can be a tight fit depending on the garage size and the vehicle's width with mirrors. The length of up to 4912 mm (193.4 inches) should typically be accommodated by most two-car garages which usually measure around 6 meters (20 feet) in depth. However, the width with mirrors fully extended at 2154 mm (84.8 inches) may require careful maneuvering or folding the mirrors to 1969 mm (77.5 inches) width for more comfortable access. Height-wise, garage door clearance is usually not an issue as the Explorer IV's height maxes out at approximately 1849 mm (72.8 inches).

Compared to the Ford Explorer III, produced from 2002 to 2005, the Explorer IV maintains a similar footprint but with slight dimensional increases. The Explorer IV is generally longer, with lengths ranging from 4813 mm to 4912 mm versus the Explorer III’s approx 4704 mm to 4828 mm (185.2 to 190.2 inches). Width also saw moderate growth from about 1803 mm to 1844 mm (71 to 72.6 inches) in the predecessor to the 1832–1872 mm (72.1 to 73.7 inches) body width in the generation IV model. These increases contribute to enhanced interior space and improved cargo capacity. The ground clearance and curb weight also slightly increased to accommodate sturdier build and additional features.

When compared to contemporaries like the Toyota Highlander (first generation), Jeep Grand Cherokee (2005–2010), and Honda Pilot (first generation), the Ford Explorer IV is competitive in size. Its length of around 4.8 to 4.9 meters (189 to 193 inches) is comparable to these rivals. The Explorer’s width is on the higher end, especially considering mirrors, which may affect parking ease. Its ground clearance of 208 mm (8.2 inches) suits light off-roading better than some competitors. Cargo capacity with seats folded is generous in the Explorer IV, making it versatile for family and utility use compared to peers. Overall, its dimensions strike a balance between interior spaciousness and typical midsize SUV footprint.

The Ford Explorer IV came equipped with several rim and tire size options tailored to different trims and performance needs. Rim sizes available include 7J x 16, 7.5J x 17, and 7.5J x 18 inches. Corresponding tire sizes offered were 235/70 R16, 245/65 R17, and 235/65 R18. These tire choices help tailor ride comfort, handling, and aesthetics depending on the model, with larger rims and lower-profile tires generally providing sportier handling at the expense of ride softness.

The 2006 to 2010 Ford Explorer IV is a midsize SUV designed to deliver a comfortable, versatile driving experience suitable for families and adventure seekers. It offers a blend of off-road capability with a high ride height and ground clearance, combined with spacious interior room for up to seven passengers with three-row seating. It is available in rear-wheel drive and four-wheel drive configurations. The Explorer IV is known for its rugged yet refined build, incorporating safety features and modern amenities for its time, making it a popular choice in the SUV segment.
