2018 Fiat 500L (facelift 2017) Dimensions, Size & Specs

The Fiat 500L (2017 facelift) measures between 1774 mm and 1784 mm in width (69.9 to 70.2 inches) excluding mirrors. When the side mirrors are fully opened, the car's overall width increases to 2036 mm (80.1 inches). This expanded width is important to consider for tight parking or narrow streets, but the compact width without mirrors helps in urban maneuverability.

The height of the Fiat 500L (facelift 2017) ranges between 1658 mm and 1670 mm (65.3 to 65.7 inches). This relatively tall stance compared to standard hatchbacks significantly benefits passenger headroom and overall cabin comfort, making the 500L feel more spacious inside despite its compact footprint. The added height also contributes to a commanding driving position.

Yes, the 2017 facelift Fiat 500L generally fits into a standard residential garage. Typical garage dimensions are about 2440 mm (8 feet) wide and 4877 mm (16 feet) long, whereas the 500L measures roughly 4242-4249 mm (13.9 feet) in length and 1774-1784 mm (5.8 feet) in width without mirrors. With mirrors folded, it comfortably fits inside. However, consider the 2036 mm (80.1 inches) width with mirrors open when parking to avoid collisions.

The curb weight of the Fiat 500L (2017 facelift) is approximately 1476 kg (3254 lbs). This relatively moderate weight for a compact MPV supports a stable, balanced driving experience without feeling overly heavy. It aids fuel efficiency and handling, providing a good compromise between comfort and agility. The weight also helps absorb road imperfections, enhancing ride quality.

The Fiat 500L facelifted in 2017 offers a generous luggage capacity of 633 liters (22.3 cubic feet) with rear seats in place, which is quite spacious for a car this size. When the rear seats are folded down, the boot volume expands significantly to 1927 liters (68 cubic feet), providing excellent versatility for transporting larger items or luggage, making it one of the more practical hatchbacks in the compact MPV category.

The 2017 facelift Fiat 500L has a ground clearance (ride height) of 120 mm (4.7 inches). This moderate clearance suits mainly urban and suburban road conditions, allowing the car to handle occasional speed bumps or rough roads with minimal risk of scraping the underbody. However, it may not be ideal for off-road or very uneven terrain, reflecting the 500L's design focus on city and family use.

Compared with the pre-facelift Fiat 500L, the 2017 facelift version retained very similar external dimensions with subtle refinements. Length remained about 4242-4249 mm (167.0-167.2 inches), width close at around 1774-1784 mm (69.9-70.2 inches), and height slightly adjusted between 1658 and 1670 mm (65.3-65.7 inches). The facelift aimed more at modernizing styling and updating features rather than changing the core dimensions, thus maintaining the spacious and practical interior environment beloved by customers.

In comparison with competitors like the Renault Captur, Ford EcoSport, and Kia Soul, the Fiat 500L facelifted 2017 is generally larger inside and out, especially in cargo space. While many compact SUVs offer similar footprint lengths roughly between 4200 and 4300 mm (165.3 to 169.3 inches), the 500L stands out with a significantly larger luggage capacity of 633 liters (22.3 cu ft) expanding to 1927 liters (68 cu ft) with seats folded. Its taller height and boxy shape maximize cabin space, making it a top choice for buyers prioritizing interior room and flexibility.

The 2017 facelift Fiat 500L comes with various rim sizes ranging from 15 to 17 inches, specifically 6J x 15, 6.5J x 16, 7J x 17, and 6J x 16 inches. Tire sizes vary accordingly with 195/65 R15, 205/55 R16, and 225/45 R17 options, allowing drivers to balance ride comfort, handling, and style. These choices reflect the car’s flexible design, catering to different preferences from efficiency-oriented to sportier setups.
