2017 Chevrolet Trailblazer II (facelift 2016) Dimensions, Size & Specs

Production
Model Year:2017
Production Years:2016 - 2020 discontinued in 2020
1835 - 1852 mm72.2 - 72.9 in6.0 - 6.1 ft
4887 mm192.4 in16.0 ft
Length
4887 mm192.4 in16.0 ft
Width
2132 mm83.9 in7.0 ft
Height
1835 - 1852 mm72.2 - 72.9 in6.0 - 6.1 ft
Trunk Capacity
205 liter7.2 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2017 Chevrolet Trailblazer II, engineered for optimal performance and comfort

Dimensions
Length:4887 mm192.4 in16.0 ft
Width:1902 mm74.9 in6.2 ft
Width (Opened Mirrors):2132 mm83.9 in7.0 ft
Height:1835 - 1852 mm72.2 - 72.9 in6.0 - 6.1 ft
Ground Clearance:222 mm8.7 in0.7 ft
Trunk Capacity:205 liter7.2 cu ft
Trunk Capacity (Max):1830 liter64.6 cu ft
Weight Specifications
Curb Weight:2106 kg4643 lbs
Maximal permitted Weight:2720 kg5997 lbs
Tire Specifications
Rims Sizes:6.5J x 16, 7.0J x 17, 7.5J x 18
Tire Sizes:245/70 R16 (W:245 | H:70 | D:16)
255/65 R17 (W:255 | H:65 | D:17)
265/60 R18 (W:265 | H:60 | D:18)
Useful Information

About 2017 Chevrolet Trailblazer II

The Chevrolet Trailblazer II facelift (2016-2020), marketed as the 2017 model year, is a midsize SUV that blends robust dimensions with versatile functionality. With an overall length of 4887 mm (192.3 inches) and a width of 1902 mm (74.8 inches) excluding mirrors, it achieves a commanding road presence. When mirrors are opened, the width increases to 2132 mm (83.9 inches), demanding consideration in tight spaces. Standing tall between 1835 mm and 1852 mm (72.2 to 72.9 inches), the Trailblazer delivers a sturdy yet handsome silhouette typical of an SUV designed for both urban driving and off-road ventures.

Weighing in at a curb weight of approximately 2106 kg (4,642 lbs) and capable of a maximum weight of 2720 kg (5,998 lbs), it offers a sturdy build suitable for families and outdoor enthusiasts alike. The SUV features a generous luggage capacity of 205 liters (7.2 cubic feet) with rear seats upright, which expands impressively to 1830 liters (64.6 cubic feet) when the rear seats are folded down, allowing for ample cargo versatility.

Ground clearance is a notable 222 mm (8.7 inches), providing the Trailblazer with commendable off-road capability and confidence over uneven terrain. The model supports a variety of rim and tire sizes including 6.5J x 16, 7.0J x 17, and 7.5J x 18 rims paired with tires ranging from 245/70 R16, 255/65 R17, to 265/60 R18, adapting to varying driving needs and styles.

Overall, the Chevrolet Trailblazer II facelift (2016-2020) stands out as a spacious, durable midsize SUV well-suited for diverse driving conditions and lifestyles, merging sizeable interior roominess with a commanding exterior footprint.

Exceptional Features

2017 Chevrolet Trailblazer II Highlights

Discover the standout features that make the 2017 Chevrolet Trailblazer II a leader in its class

Engine Options

The 2017 Chevrolet Trailblazer II offers a range of efficient engines including a 1.4L turbocharged petrol engine and a 2.8L Duramax turbo diesel engine, providing a balance of power and fuel economy.

Modern Exterior Design

Featuring a refreshed front grille, sleek headlights, and updated bumpers, the facelifted model presents a more contemporary and aggressive look compared to the previous version.

Advanced Infotainment System

Equipped with Chevrolet’s MyLink system, the Trailblazer II includes a touchscreen display, smartphone integration via Apple CarPlay and Android Auto, Bluetooth connectivity, and navigation options.

Spacious and Comfortable Interior

The cabin offers ample seating for seven passengers with flexible folding rear seats, high-quality materials, and ergonomic design aimed at comfort during long drives.

Safety Features

Includes multiple airbags, ABS with EBD, electronic stability control, hill start assist, and rear parking sensors, enhancing overall safety for driver and passengers.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Chevrolet Trailblazer II facelift for the 2017 model year measures 4887 mm (192.3 inches) in length, 1902 mm (74.8 inches) in width without mirrors, and between 1835 mm to 1852 mm (72.2 to 72.9 inches) in height, depending on specific trims or optional equipment. These dimensions contribute to a robust SUV presence on the road, providing ample interior space while maintaining reasonable maneuverability.

With side mirrors fully opened, the Chevrolet Trailblazer II reaches a width of 2132 mm (83.9 inches). This extended width is important to consider when parking in tight spaces, navigating narrow lanes, or using automatic car washes. Drivers should be mindful of this total width to prevent scrapes or damage, as the mirrors extend beyond the main body dimensions.

The Chevrolet Trailblazer II facelift offers a ground clearance of 222 mm (8.7 inches). This substantial clearance allows the SUV to handle rough and uneven terrain effectively, providing better off-road capability and protection against obstacles such as rocks or deep potholes. It ensures that the underbody components are less likely to be damaged during off-road driving or poor road conditions.

The curb weight of the 2017 Chevrolet Trailblazer II is approximately 2106 kg (4,643 lbs), while the maximum gross vehicle weight rating (GVWR) is 2720 kg (5,996 lbs). This means the SUV can safely carry passengers, cargo, and any additional load up to the maximum weight without compromising safety or performance. The relatively robust weight supports its capability as a medium-sized SUV offering durability and stability on various road surfaces.

The Chevrolet Trailblazer II offers a luggage capacity of 205 liters (7.2 cubic feet) when the rear seats are in use. When the rear seats are folded down, the capacity dramatically increases to 1830 liters (64.6 cubic feet). This versatility allows the SUV to accommodate everyday cargo needs comfortably and provides significant space for larger items or extended trips when additional space is required, making it practical for families or outdoor adventures.

The Chevrolet Trailblazer II, with its overall width of 1902 mm (74.8 inches) and length of 4887 mm (192.3 inches), generally fits into most standard garages designed with typical clearances in mind—usually about 2400 mm (94.5 inches) wide and 6000 mm (236 inches) deep. However, drivers should consider the width with mirrors open (2132 mm or 83.9 inches) and garage door width for comfortable access. Generally, it fits but requires some caution when maneuvering in tight garage spaces.

Compared to the previous Trailblazer generation, the 2017 facelifted Trailblazer II maintains similar dimensions but incorporates subtle design updates that slightly enhance interior space utilization and cargo versatility. While exact predecessor dimensions vary by market, the facelift maintains the SUV's established size class with a length close to 4.9 meters and a broad width around 1.9 meters. The refreshed model improves features and styling rather than drastically changing physical size.

The 2017 Chevrolet Trailblazer II sits competitively among mid-size SUVs like the Toyota Fortuner, Ford Everest, and Mitsubishi Pajero Sport. Its 4887 mm length and 1902 mm width offer a balance of cabin space and external footprint comparable to these rivals. The Trailblazer excels in ground clearance with 222 mm, comparable to off-road oriented competitors, making it suitable for varied terrains. Cargo space with seats folded (1830 liters) is on par, making it an appealing option for buyers seeking spacious, versatile, mid-size SUVs.

The Chevrolet Trailblazer II facelift supports several rim sizes ranging from 16 inches to 18 inches, including 6.5J x 16, 7.0J x 17, and 7.5J x 18. Tire sizes available include 245/70 R16, 255/65 R17, and 265/60 R18. Generally, smaller rims with taller tires (like 16-inch rims) tend to improve ride comfort by better absorbing road imperfections, while larger rims with lower-profile tires (like 18 inches) can enhance handling and aesthetics but may slightly reduce ride softness.

The 2017 Chevrolet Trailblazer II facelift is a robust mid-size SUV designed for both city driving and off-road adventures. It offers a strong build, enhanced safety features, and spacious interiors with flexible seating and cargo options. The facelift brought updated design elements and technology improvements, making it more competitive in its segment. It appeals to buyers seeking a blend of style, practicality, and capability in an SUV that performs well across different driving environments.
