2003 Cadillac CTS I Dimensions, Size & Specs

Production
Model Year:2003
Production Years:2003 - 2007 discontinued in 2007
1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
4828 - 4865 mm190.1 - 191.5 in15.8 - 16.0 ft
1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
1795 mm70.7 in5.9 ft
1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
1795 mm70.7 in5.9 ft
1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
4828 - 4865 mm190.1 - 191.5 in15.8 - 16.0 ft
1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
1795 mm70.7 in5.9 ft
1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
1795 mm70.7 in5.9 ft
Length
4828 - 4865 mm190.1 - 191.5 in15.8 - 16.0 ft
Width
1795 mm70.7 in5.9 ft
Height
1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
Trunk Capacity
360 liter12.7 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2003 Cadillac CTS I, engineered for optimal performance and comfort

Dimensions
Length:4828 - 4865 mm190.1 - 191.5 in15.8 - 16.0 ft
Width:1795 mm70.7 in5.9 ft
Height:1440 - 1455 mm56.7 - 57.3 in4.7 - 4.8 ft
Trunk Capacity:360 liter12.7 cu ft
Trunk Capacity (Max):362 - 430 liter12.8 - 15.2 cu ft
Weight Specifications
Curb Weight:1625 - 1780 kg3583 - 3924 lbs
Maximal permitted Weight:2125 - 2160 kg4685 - 4762 lbs
Tire Specifications
Rims Sizes:7J x 16, 7.5J x 17, 8.5J X 18
Tire Sizes:225/55 R16 (W:225 | H:55 | D:16)
225/50 R17 (W:225 | H:50 | D:17)
245/45 R18 (W:245 | H:45 | D:18)
Useful Information

About 2003 Cadillac CTS I

The Cadillac CTS I, produced from 2003 to 2007, marked Cadillac's entry into the midsize luxury sedan market with a bold design and well-balanced proportions. This first-generation CTS was crafted to compete with European rivals, offering an elegant and sporty profile. The sedan's length ranges from 4,828 mm to 4,865 mm (approximately 190.1 to 191.5 inches), providing ample cabin space while maintaining a manageable footprint for urban and suburban driving. With a width spanning 1,793 to 1,795 mm (70.5 to 70.7 inches), it delivers a stable stance on the road without being overly wide. The height of the vehicle varies between 1,440 mm and 1,455 mm (56.7 to 57.3 inches), contributing to a sleek silhouette and low center of gravity to enhance handling dynamics.

In terms of weight, the CTS I varies from 1,625 kg to 1,780 kg (approximately 3,583 to 3,924 pounds) curb weight, accommodating various trims and optional equipment packages. The maximum permissible weight ranges between 2,125 kg and 2,160 kg (4,686 to 4,762 pounds), ensuring substantial carrying capacity without compromising ride quality. One of the notable features is its luggage capacity of 360 liters (about 12.7 cubic feet), which modestly increases to between 362 and 430 liters (12.8 to 15.2 cubic feet) when the rear seats are folded, offering practical storage options for longer trips or bulky cargo.

The vehicle rides on a range of rim sizes from 16 to 18 inches (7J x 16, 7.5J x 17, 8.5J x 18), which influence both aesthetics and driving dynamics, paired with appropriate tire sizes including 225/55 R16, 225/50 R17, and 245/45 R18. These specifications offer a balance between comfort, grip, and road feedback, reflecting Cadillac’s focus on delivering a comfortable yet engaging driving experience.

Overall, the Cadillac CTS I sedan combines American luxury with balanced dimensions and versatility, making it a compelling choice in the midsize segment during its production years.

Exceptional Features

2003 Cadillac CTS I Highlights

Discover the standout features that make the 2003 Cadillac CTS I a leader in its class

Engine Options

The 2003 Cadillac CTS I offers a 3.2-liter V6 engine producing 220 horsepower, delivering a balance of performance and efficiency.

Transmission

Equipped with either a 5-speed manual transmission or a 5-speed automatic transmission, catering to different driving preferences.

Interior Design

Features a driver-focused cockpit with high-quality materials, supportive seating, and a user-friendly dashboard layout.

Safety Features

Includes standard anti-lock brakes (ABS), traction control, front airbags, and an optional side airbag system for enhanced safety.

Handling and Suspension

Utilizes a sophisticated suspension system with a four-wheel independent setup, providing sharp handling and a comfortable ride.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Cadillac CTS I sedan, produced from 2003 to 2007, measures between 4828 mm and 4865 mm (approximately 190.1 to 191.5 inches) in length. Its width ranges from 1793 mm to 1795 mm (about 70.6 to 70.7 inches). The height varies between 1440 mm and 1455 mm (around 56.7 to 57.3 inches). These dimensions place the CTS I within the mid-size luxury sedan category, offering a balanced profile suitable for both urban and highway driving.

The curb weight of the Cadillac CTS I ranges between 1625 kg and 1780 kg (approximately 3584 to 3924 pounds), depending on the specific trim and options. The maximum allowable weight, which includes passengers, cargo, and fuel, falls between 2125 kg and 2160 kg (around 4685 to 4762 pounds). This weight profile supports a robust build typical of luxury sedans, balancing performance and comfort without compromising handling.

The Cadillac CTS I offers a luggage capacity of 360 liters (approximately 12.7 cubic feet) with the rear seats in their upright position. When the rear seats are folded down, this capacity expands between 362 liters and 430 liters (roughly 12.8 to 15.2 cubic feet). This versatile storage space provides practicality for daily use or long trips, allowing for the accommodation of larger or additional items when needed.

The Cadillac CTS I comes with a range of wheel sizes, including 16-inch rims measuring 7J x 16, 17-inch rims sized 7.5J x 17, and 18-inch rims at 8.5J x 18. Corresponding tire sizes include 225/55 R16, 225/50 R17, and 245/45 R18. These options enable buyers to balance ride comfort, handling, and appearance, depending on their preferences and driving conditions.

Yes, the Cadillac CTS I is suitable for parking in a standard residential garage. The vehicle’s maximum external dimensions—length up to 4865 mm (191.5 inches), width up to 1795 mm (70.7 inches), and height up to 1455 mm (57.3 inches)—fit comfortably within typical garage sizes. Most standard garages provide clearance for vehicles roughly 6 meters (20 feet) in length and 2.4 meters (8 feet) in width, making the CTS I a good fit for private residential garages without causing spatial constraints.

The Cadillac CTS I was introduced as a replacement for the Cadillac Catera and positioned as a more modern, sportier luxury sedan. Compared to the Catera, the CTS I is generally longer and wider, with a more aggressive and angular design language. For instance, the Catera measured around 4710 mm in length, making the CTS I longer by roughly 100 to 150 mm, which translated into improved interior space and road presence. The CTS I also introduced sharper styling cues and a firmer suspension setup compared to its predecessor, aligning with Cadillac’s shift toward a more European-inspired driving experience.

When compared with contemporaries like the BMW 3 Series (E46), Mercedes-Benz C-Class (W203), and Audi A4 of the early to mid-2000s, the Cadillac CTS I offers competitive dimensions. The CTS I is slightly longer and generally wider than the BMW E46 sedan, which measured about 4510 mm in length and 1745 mm in width. Compared to the Mercedes C-Class (approximately 4520 mm long and 1720 mm wide) and Audi A4 (about 4530 mm long and 1760 mm wide), the CTS I tends to offer a more spacious cabin and larger exterior footprint, emphasizing American luxury sedan characteristics with slightly larger dimensions for increased comfort and road stance.

Within the Cadillac CTS I generation, the exterior dimensions slightly vary due to different trims, options, or optional equipment like wheel size. Length ranges from 4828 mm to 4865 mm (190.1 to 191.5 inches), width from 1793 mm to 1795 mm (70.6 to 70.7 inches), and height from 1440 mm to 1455 mm (56.7 to 57.3 inches). These minor variations arise largely from suspension setups, wheel and tire combinations, and optional aerodynamic packages, but overall, the CTS I maintains a consistent physical footprint across trims.

The Cadillac CTS I is classified as a 4-door sedan, a body style that balances passenger comfort with manageable exterior dimensions. Compared to SUVs, the CTS I is generally lower in height (1440 - 1455 mm vs. SUVs typically exceeding 1650 mm), narrower, and lighter, providing better aerodynamics and handling characteristics. When compared to coupes, the CTS I offers additional rear passenger space with its four-door design, but is slightly larger overall due to the accommodation of two extra doors and enhanced rear seat volume.

With a height ranging between 1440 mm and 1455 mm (56.7 to 57.3 inches) and width approximately 1793 mm to 1795 mm (70.6 to 70.7 inches), the Cadillac CTS I features a relatively low and wide stance typical of luxury sports sedans of its era. This contributes to stable handling during cornering and reduces body roll compared to taller vehicles. The width provides a spacious interior cabin for passengers and enhances vehicle stability at higher speeds, while the moderate height helps maintain a lower center of gravity, resulting in confident and sporty driving dynamics. These proportions strike a balance between comfort, aggressive styling, and responsive road behavior.
