2013 BMW Z4 (E89 LCI, facelift 2013) Dimensions, Size & Specs

The curb weight of the BMW Z4 (E89 LCI facelift) from 2013 to 2016 ranges between 1395 kg and 1525 kg (roughly 3075 to 3363 pounds). The maximum allowable weight is between 1725 kg and 1855 kg (approximately 3805 to 4089 pounds). This variation in weight is influenced by model variants, engine choice, optional equipment, and body materials. Such weight figures are well balanced for a roadster, contributing to agile handling while maintaining structural integrity and passenger comfort.

The 2013-2016 BMW Z4 (E89 LCI facelift) offers a luggage capacity of 180 liters (about 6.4 cubic feet) under normal conditions. When the rear seats are folded down, the luggage space increases to 310 liters (roughly 10.9 cubic feet). This expanded capacity enhances practicality for longer trips or when transporting larger items, though as a roadster, the Z4 is primarily designed for sporty driving rather than maximum cargo space.

The ride height or ground clearance of the BMW Z4 (E89 LCI facelift) ranges from 124 mm to 130 mm (4.9 to 5.1 inches). This relatively low ground clearance is typical for sporty roadsters, optimizing aerodynamic performance and handling. While excellent for performance and cornering agility, the lower clearance means drivers should be cautious on uneven roads, speed bumps, and steep driveways to avoid underbody scraping.

The BMW Z4 (E89 LCI facelift) offers a variety of rim sizes, including 8J x 17, 8.5J x 17, 8J x 18, and 8.5J x 18 inches. Corresponding tire sizes include 225/45 R17, 255/40 R17, 225/40 R18, and 255/35 R18. These wheel and tire options contribute to a balance of sporty performance and ride comfort, allowing owners to suit their driving preferences, whether prioritizing grip, agility, or ride quality.

Yes, the BMW Z4 (E89 LCI facelift) can fit into a standard residential garage. With a width of 1790 mm (70.5 inches) and a height of up to 1291 mm (50.8 inches), it is lower and narrower than many SUVs or sedans, easing garage accommodation. The length of up to 4244 mm (167 inches or roughly 13.9 feet) is also manageable for typical garage depths. Drivers should still consider additional space for opening doors and maneuvering, but overall, the Z4’s compact roadster dimensions make garage parking convenient.

The 2013-2016 BMW Z4 (E89 LCI facelift) is a refined update of the original E89 Z4. While the exterior dimensions remain largely consistent with minimal changes—length, width, and height being nearly identical—the facelift primarily focused on styling enhancements, technology upgrades, and improved materials. The facelift version introduced tweaks like restyled headlights, updated bumpers, and enhanced interior features, but maintained the overall size and roadster proportions of the predecessor. This ensures continuity of the sporty, low-profile design, while refreshing the car's aesthetic and driving experience.

In comparison with other roadsters such as the Porsche Boxster or Audi TT from the same era, the BMW Z4 (E89 LCI facelift) is competitively sized. Its length of around 4240 mm (167 inches), width of 1790 mm (70.5 inches), and height just under 1300 mm (51 inches) positions it similarly to these rivals, providing an agile footprint suitable for sporty handling. The BMW's luggage space is somewhat limited compared to the Porsche Boxster but comparable to the Audi TT. Overall, the Z4's size provides excellent balance between sporty dynamics and everyday usability in the compact roadster segment.

The facelifted BMW Z4 E89 continued to offer a range of inline-4 and inline-6 engines, combining efficient performance with dynamic driving. Engine choices included turbocharged and naturally aspirated variants, with power outputs varying depending on the model year and market. Transmission options typically included 6-speed manual and 8-speed automatic gearboxes, catering to both purists and those preferring ease of use. Performance was enhanced by rear-wheel drive layout and precise chassis tuning, delivering an engaging driving experience characteristic of BMW roadsters.

The BMW Z4 (E89 LCI facelift) is a two-seater roadster designed primarily with driver-focused ergonomics and sporty comfort in mind. While it does not offer rear seats, the cabin is spacious enough for two adults, providing ample headroom and legroom thanks to its low roofline and sporty layout. The interior features quality materials and modern design elements refreshed during the facelift, improving comfort and usability. Though limited in passenger capacity, the Z4's interior space is optimized for driving enjoyment and luxury rather than passenger volume.
