2017 Audi S5 Cabriolet (F5) Dimensions, Size & Specs

The Audi S5 Cabriolet (F5) has a curb weight of approximately 1840 kg (4,056 lbs), which accounts for the vehicle with all standard equipment and fluids. Its maximum weight capacity, including passengers and cargo, is 2340 kg (5,157 lbs). This balance between weight and performance ensures that the cabriolet delivers a dynamic driving experience while maintaining stability and safety.

The standard luggage capacity of the Audi S5 Cabriolet (F5) is 320 liters (11.3 cubic feet), which is relatively generous for a convertible. When the rear seats are folded down, the luggage capacity increases to 380 liters (13.4 cubic feet). This additional space allows for more flexible cargo arrangements, making it practical for weekend trips or other activities requiring extra storage.

With a length of 4692 mm (184.7 inches), width of 1846 mm (72.7 inches) excluding mirrors, and a height of 1382 mm (54.4 inches), the Audi S5 Cabriolet (F5) comfortably fits into a standard residential garage. Most standard garage sizes, typically around 2400-2700 mm (94-106 inches) wide and 4800-5400 mm (189-212 inches) deep, offer more than enough space to accommodate the car with room to open doors and mirrors safely. However, care should be taken when opening the side mirrors or maneuvering inside tighter garages.

The Audi S5 Cabriolet (F5) has a width of 1846 mm (72.7 inches) without the mirrors extended, but when the mirrors are opened fully, the width increases to 2029 mm (79.8 inches). This nearly 18-centimeter (7-inch) increase is important for parking and maneuvering in tight spaces where mirror clearance matters. Drivers should be cautious of the wider stance in narrow areas to avoid mirror damage.

Compared to the predecessor Audi S5 Cabriolet (the B8 generation), the F5 model from 2016-2018 is slightly larger. The F5 measures 4692 mm in length versus around 4643 mm of the B8 model, giving it a modest length increase of about 49 mm (1.9 inches). Width and height are also slightly larger for enhanced interior space and road presence. Overall, these modest size increments offer better passenger comfort and modern styling without sacrificing agility.

In comparison to similar luxury convertibles, such as the BMW 4 Series Convertible and Mercedes-Benz C-Class Cabriolet, the Audi S5 Cabriolet (F5) sits competitively in terms of size. Its length of 4692 mm (184.7 inches) and width of 1846 mm (72.7 inches) are on par with competitors, generally offering similar interior and luggage space. The S5’s slightly broader width with mirrors up (2029 mm/79.8 inches) may require more attention in tight parking, but its balance of space, performance, and luxury makes it a strong contender in the premium convertible segment.

The Audi S5 Cabriolet (F5) is designed primarily as a 4-seat convertible with two front seats and two smaller rear seats. The cabin offers a comfortable and premium experience, particularly for front passengers who benefit from ample shoulder and headroom. Rear seats provide adequate space for shorter trips or smaller passengers, but are best suited for occasional use due to slightly limited legroom typical of the convertible body style.

The Audi S5 Cabriolet (F5) featured a powerful 3.0-liter TFSI V6 engine delivering around 354 horsepower and 500 Nm of torque. This engine was paired with a 7-speed S tronic dual-clutch transmission and Audi’s Quattro all-wheel-drive system, ensuring a dynamic and responsive driving experience. This powertrain combination allows for brisk acceleration and confident handling, especially important for an open-top sports convertible.

With a curb weight of approximately 1840 kg (4,056 lbs), the Audi S5 Cabriolet (F5) balances solid build quality, premium features, and performance capabilities. While convertibles often weigh more than their coupe counterparts due to added chassis reinforcement for rigidity without a fixed roof, the S5 Cabriolet’s weight contributes to a stable and composed ride. This weight, combined with the sporty powertrain and Quattro all-wheel drive, delivers confident acceleration, precise handling, and a secure feel on various road conditions.
