2016 Audi A4 (B9 8W) Dimensions, Size & Specs

Production
Model Year:2016
Production Years:2015 - 2018 discontinued in 2018
1427 mm56.2 in4.7 ft
4726 mm186.1 in15.5 ft
1427 mm56.2 in4.7 ft
2022 mm79.6 in6.6 ft
1427 mm56.2 in4.7 ft
2022 mm79.6 in6.6 ft
1427 mm56.2 in4.7 ft
4726 mm186.1 in15.5 ft
1427 mm56.2 in4.7 ft
2022 mm79.6 in6.6 ft
1427 mm56.2 in4.7 ft
2022 mm79.6 in6.6 ft
Length
4726 mm186.1 in15.5 ft
Width
2022 mm79.6 in6.6 ft
Height
1427 mm56.2 in4.7 ft
Trunk Capacity
480 liter17.0 cu ft
Technical Details

Exterior Dimensions

Precise measurements of the 2016 Audi A4, engineered for optimal performance and comfort

Dimensions
Length:4726 mm186.1 in15.5 ft
Width:1842 mm72.5 in6.0 ft
Width (Opened Mirrors):2022 mm79.6 in6.6 ft
Height:1427 mm56.2 in4.7 ft
Trunk Capacity:480 liter17.0 cu ft
Trunk Capacity (Max):965 liter34.1 cu ft
Weight Specifications
Curb Weight:1320 - 1660 kg2910 - 3660 lbs
Maximal permitted Weight:1890 - 2230 kg4167 - 4916 lbs
Roof Load:90 kg198 lbs
Tire Specifications
Rims Sizes:7J x 16, 17, 18, 19, 7.5J x 17, 8J x 18, 8J x 19, 8.5J x 19
Tire Sizes:205/60 R16 (W:205 | H:60 | D:16)
225/50 R17 (W:225 | H:50 | D:17)
245/40 R18 (W:245 | H:40 | D:18)
245/35 R19 (W:245 | H:35 | D:19)
195/65 R16 (W:195 | H:65 | D:16)
225/50 R17 94Y (W:225 | H:50 | D:17)
245/40 R18 93Y (W:245 | H:40 | D:18)
245/35 R19 93Y (W:245 | H:35 | D:19)
Useful Information

About 2016 Audi A4

The Audi A4 (B9 8W) generation, produced between 2015 and 2018 for model years 2016 to 2018, represents a sophisticated mid-size sedan option in Audi's lineup. Measuring 4726 mm (185.9 inches) in length and 1842 mm (72.5 inches) in width, the B9 A4 offers a balanced exterior footprint suitable for both urban and highway driving. With side mirrors opened, the width increases to 2022 mm (79.6 inches), ensuring enhanced visibility and road presence. The vehicle height varies slightly between 1424 mm (56.1 inches) and 1427 mm (56.2 inches), providing a sleek silhouette typical of luxury sedans. The curb weight ranges from 1320 kg (2,910 lbs) to 1660 kg (3,660 lbs) depending on configuration, with a maximum permissible weight from 1890 kg (4,168 lbs) up to 2230 kg (4,919 lbs). This weight distribution allows the Audi A4 to deliver a dynamic yet comfortable driving experience. Storage capacity is practical; the trunk holds up to 480 liters (16.9 cubic feet) with all seats in place, and expands impressively to 965 liters (34.1 cubic feet) when the rear seats are folded down. The roof load capacity is rated at 90 kg (198 lbs), making it suitable for additional cargo like roof boxes or carriers. Wheel options for the B9 cover a range of rim sizes including 16-, 17-, 18-, and 19-inch variants (notably 7J x 16, 7.5J x 17, and up to 8.5J x 19), paired with tire sizes such as 205/60 R16 and 245/35 R19, delivering a blend of performance, comfort, and style. Overall, the Audi A4 B9 (2016-2018) sedan combines elegant dimensions, efficient use of space, and flexible loading capacities, making it a versatile choice for drivers seeking premium German engineering in a size-friendly mid-size sedan.

Exceptional Features

2016 Audi A4 Highlights

Discover the standout features that make the 2016 Audi A4 a leader in its class

Engine Options

The 2016 Audi A4 (B9 8W) offers a range of turbocharged engines, including a 2.0-liter TFSI four-cylinder engine producing between 190 to 252 horsepower, providing a balance of performance and efficiency.

Quattro All-Wheel Drive

Audi's renowned Quattro all-wheel-drive system is available, delivering enhanced traction and stability across various driving conditions for improved safety and handling.

MMI Infotainment System

Featuring the updated Audi MMI (Multi Media Interface) system with a color display, offering navigation, smartphone integration, Bluetooth connectivity, and voice control for an enhanced driving experience.

Advanced Safety Features

Equipped with multiple airbags, electronic stability control, anti-lock brakes, and optional driver assistance systems like adaptive cruise control and lane departure warning to enhance occupant safety.

Elegant Interior Design

The 2016 A4 boasts a high-quality interior with premium materials, comfortable seating, and refined design touches, creating a luxurious and driver-focused cabin environment.
Frequently Asked Questions

FAQ

Have a question? Please check our knowledgebase first.

The Audi A4 (B9 8W) sedan measures 4726 mm (185.9 inches) in length, 1842 mm (72.5 inches) in width, and stands at a height ranging between 1424 and 1427 mm (56.1 to 56.2 inches). These dimensions offer a balanced size for a compact executive sedan, fitting well in urban and suburban driving conditions.

With the side mirrors opened, the Audi A4 (B9 8W) reaches a width of 2022 mm (79.6 inches). This is important to consider in narrow parking spaces or tight garages. The extra mirror width increases the vehicle's footprint, so drivers should ensure enough lateral clearance to avoid damage.

The curb weight of the Audi A4 (B9 8W) ranges from 1320 kg to 1660 kg (approximately 2910 to 3660 lbs), depending on the variant and equipment. A lighter curb weight generally contributes to better acceleration, handling, and fuel efficiency, while heavier models might offer more features and improved soundproofing.

The Audi A4 (B9 8W) has a maximum permissible weight between 1890 kg and 2230 kg (about 4167 to 4918 lbs), which includes the vehicle's curb weight plus passengers, cargo, and fuel. Adhering to this limit ensures safe handling, braking efficiency, and reduces wear on mechanical components.

The luggage capacity behind the rear seats is 480 liters (16.9 cubic feet), which expands to 965 liters (34.1 cubic feet) when the rear seats are folded down. This versatility allows the A4 to handle everyday luggage needs comfortably while accommodating larger cargo when required.

Standing at 1424 to 1427 mm (56.1 to 56.2 inches) tall, the Audi A4 (B9 8W) maintains a low and sleek profile that benefits aerodynamic efficiency and stability at higher speeds. Despite its modest height, the interior is designed to optimize headroom for driver and passengers, balancing comfort with sporty styling.

Yes, the Audi A4 (B9 8W) fits comfortably into a standard home garage. Most domestic garages have interior dimensions around 2400 mm (7 ft 10 in) width and 4800 mm (15 ft 9 in) length. With the A4’s length of 4726 mm and width of 1842 mm (excluding mirrors), it allows enough room for door opening and maneuvering inside garages of typical size.

Compared to the A4 (B8) generation, the B9 model is slightly longer and wider, offering more interior space and improved comfort. The B9 is approximately 33 mm longer and 24 mm wider than the B8. These dimensional increases contribute to enhanced passenger room and a more commanding road presence without significantly increasing overall bulk.

In comparison to similar compact executive sedans like the BMW 3 Series and Mercedes-Benz C-Class, the Audi A4 (B9 8W) holds its own with competitive dimensions. Its length of 4726 mm places it on par or slightly longer than some rivals, while the width and height provide a balanced and roomy interior. This makes the A4 a strong contender for buyers seeking mid-size luxury with practical dimensions.

The Audi A4 (B9 8W) supports a wide variety of rim sizes including 16, 17, 18, and 19-inch wheels with corresponding rim widths from 7J up to 8.5J. Tire sizes available are 205/60 R16, 225/50 R17, 245/40 R18, 245/35 R19 among others. Larger rims and lower-profile tires enhance cornering stability and sporty aesthetics but may reduce ride comfort, while smaller rims offer a smoother ride and better absorption of road imperfections.
